YR22LG-MDEA (1985)
Toyota Van
(8508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16261 - HOSE, WATER BY-PASS | ||||
| 16261-73070 |
4YEC..YR2#,3# |
1 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16264 - HOSE, WATER BY-PASS, NO.2 | ||||
| 16264-73021 |
4YEC..YR2#,3# |
1 | ||
| 16264A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16264A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16267 - HOSE, WATER BY-PASS, NO.3 | ||||
| 16267-73010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16267A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.3) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16267A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.3) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16268 - PIPE, WATER BY-PASS, NO.1 | ||||
| 16268-73011 |
4YEC..YR2# |
1 | ||
| 16268A - HOSE(FOR WATER BY-PASS PIPE) | ||||
| 99556-10110 |
3YEC,4YEC..YR2#,3# *H,L=110 |
2 | ||
| 16268A - HOSE(FOR WATER BY-PASS PIPE) | ||||
| 99556-10110 |
3YEC,4YEC..YR2#,3# *H,L=110 |
2 | ||
| 16268B - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS PIPE) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
4 | ||
| 16268B - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS PIPE) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
4 | ||
| 16268B - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS PIPE) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
4 | ||
| 16268B - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS PIPE) | ||||
| 90467-13001 |
3YEC,4YEC..YR2#,3# |
4 | ||
| 16269 - SUPPORT, WATER BY-PASS PIPE | ||||
| 16269-73011 |
4YEC..YR2#,3# |
1 | ||
| 16278 - PIPE, WATER BY-PASS, NO.2 | ||||
| 16278-73011 |
4YEC..YR2#,3# |
1 | ||
| 16278A - GASKET, WATER BY-PASS | ||||
| 17175-72010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16321 - INLET, WATER | ||||
| 16321-71010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16325 - GASKET, WATER INLET HOUSING, NO.1 | ||||
| 16325-63010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16331 - OUTLET, WATER | ||||
| 16304-73010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16331F - CAP SUB-ASSY(FOR WATER OUTLET) | ||||
| 16401-15210 |
4YEC..YR2#,3# TOYO RADIATOR |
1 | ||
| 16401-63010 |
3YEC,4YEC..YR2#,3# DENS0 |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-71010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16361 - FAN | ||||
| 16361-38010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16361-73030 |
4YEC..YR2#,3# |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-73011 |
4YEC..YR2#,3# |
1 | ||
| 16385 - SLIDER, FAN BELT ADJUSTING | ||||
| 16385-71010 |
3YEC,4YEC..YR2#,3# |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-73150 |
4YEC..YR2#..5F |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 90910-09054 |
4YEC..YR2# |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 96711-19007 |
4YEC..YR2# |
1 | ||
| 16400G - HOSE(FOR RADIATOR BREATHER) | ||||
| 99555-10400 |
4YEC..YR2# *H,L=400 |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-73010 |
4YEC..YR2#,3# |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 85338-73010 |
4YEC..YR2#,3# NO.1 |
1 | ||
| 85338-73030 |
4YEC..YR2#,3# L=400,NO.2 |
1 | ||
| 90445-12078 |
4YEC..YR2#,3# *H,L=105,NO.3 |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 85338-73010 |
4YEC..YR2#,3# NO.1 |
1 | ||
| 85338-73030 |
4YEC..YR2#,3# L=400,NO.2 |
1 | ||
| 90445-12078 |
4YEC..YR2#,3# *H,L=105,NO.3 |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 85338-73010 |
4YEC..YR2#,3# NO.1 |
1 | ||
| 85338-73030 |
4YEC..YR2#,3# L=400,NO.2 |
1 | ||
| 90445-12078 |
4YEC..YR2#,3# *H,L=105,NO.3 |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16471-73010 |
4YEC..YR2#,3# |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 85338-30010 |
4YEC..YR2#,3# |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-71010 |
3YEC,4YEC..YR2# |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90467-37001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90467-37001 |
3YEC,4YEC..YR2#,3# |
2 | ||
| 16584 - INSULATOR, RADIATOR MOUNTING | ||||
| 17853-38010 |
3YEC,4YEC..YR2# |
2 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16711-73020 |
3YEC,4YEC..YR2# |
1 | ||
| 16712 - SHROUD, FAN, NO.2 | ||||
| 16712-71010 |
3YEC,4YEC..YR2# |
1 | ||
| Common parts | ||||
| 90119-10180 | ||||
| 90122-08012 | ||||
| 90179-06070 | ||||
| 90179-08123 | ||||
| 90179-08146 | ||||
| 90430-16004 | ||||
| 91611-60825 | ||||
| 91621-40835 | ||||
| 91651-40610 | ||||
| 91651-40814 | ||||
| 91655-60825 | ||||
| 91661-60616 | ||||
| Linked diagrams | ||||
| 1605 | ||||
| 2211 | ||||
| 8401 | ||||
