UCK30L-ASSLKA (2002)
Toyota Tundra
(0208-0408)4HC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 35207 - SPRING SUB-ASSY, B-0 ACCUMULATOR | ||||
| 35207-22010 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35207-22010 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 35207A - RING, HOLE SNAP (FOR B-0 ACCUMULATOR SPRING) | ||||
| 90521-22004 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 90521-22004 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 35208 - SPRING SUB-ASSY, B-2 ACCUMULATOR | ||||
| 35208-30010 |
UCK3#,4# |
1 | ||
| 35208-30010 |
UCK30,40 |
1 | ||
| 35208A - RING, HOLE SNAP (FOR B-2 ACCUMULATOR SPRING) | ||||
| 90521-22004 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 90521-22004 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 35209 - SPRING SUB-ASSY, C-2 ACCUMULATOR | ||||
| 35209-50020 |
UCK30,40 |
1 | ||
| 35209-30010 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35209A - RING, HOLE SNAP (FOR C-2 ACCUMULATOR SPRING) | ||||
| 90521-22004 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 90521-22004 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35251 - BODY, CHECK BALL | ||||
| 35251-30020 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 35251-30020 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35251A - SPRING, COMPRESSION (FOR CHECK BALL BODY) | ||||
| 90501-03005 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 90501-03005 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 35285 - PLATE, SOLENOID LOCK | ||||
| 35285-24020 |
UCK30,40 NO.2 |
1 | ||
| 35285-24010 |
UCK30,40 NO.1 |
1 | ||
| 35285-24020 |
UCK3#,4#,VCK40..4HC |
1 | ||
| 35290 - SOLENOID ASSY, LINE PRESSURE CONTROL | ||||
| 35290-60020 |
UCK30,40 |
1 | ||
| 35290-60020 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35330 - STRAINER ASSY, VALVE BODY OIL | ||||
| 35330-60030 |
UCK30,40 |
1 | ||
| 35330-60030 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35410 - BODY ASSY, TRANSMISSION VALVE | ||||
| 35410-34052 |
UCK30 |
1 | ||
| 35410-34070 |
UCK3# |
1 | ||
| 35423 - PISTON, B-2 ACCUMULATOR | ||||
| 35423-30030 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 35423-30030 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35423A - SPRING, COMPRESSION (FOR B-2 ACCUMULATOR PISTON) | ||||
| 90501-28015 |
UCK30,40 |
1 | ||
| 90501-28011 |
UCK3#,4# |
1 | ||
| 35423B - RING, O (FOR B-2 ACCUMULATOR PISTON) | ||||
| 90301-31010 |
UCK3#,4#,VCK30,40..4HC LOWER |
1 | ||
| 90301-23010 |
UCK3#,4#,VCK30,40..4HC UPPER |
1 | ||
| 90301-31010 |
UCK30,40,VCK30,40..4HC LOWER |
1 | ||
| 90301-23010 |
UCK30,40,VCK30,40..4HC UPPER |
1 | ||
| 35423B - RING, O (FOR B-2 ACCUMULATOR PISTON) | ||||
| 90301-31010 |
UCK3#,4#,VCK30,40..4HC LOWER |
1 | ||
| 90301-23010 |
UCK3#,4#,VCK30,40..4HC UPPER |
1 | ||
| 90301-31010 |
UCK30,40,VCK30,40..4HC LOWER |
1 | ||
| 90301-23010 |
UCK30,40,VCK30,40..4HC UPPER |
1 | ||
| 35425A - PISTON, C-2 ACCUMULATOR | ||||
| 35425-30020 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35425-30020 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 35425B - SPRING, COMPRESSION (FOR C-2 ACCUMULATOR PISTON) | ||||
| 90501-22015 |
UCK3#,4# OUTER |
1 | ||
| 90501-25027 |
UCK30,40,VCK30,40..4HC INNER |
1 | ||
| 90501-25027 |
UCK3#,4#,VCK30,40..4HC INNER |
1 | ||
| 90501-23093 |
UCK30,40 OUTER |
1 | ||
| 35425B - SPRING, COMPRESSION (FOR C-2 ACCUMULATOR PISTON) | ||||
| 90501-22015 |
UCK3#,4# OUTER |
1 | ||
| 90501-25027 |
UCK30,40,VCK30,40..4HC INNER |
1 | ||
| 90501-25027 |
UCK3#,4#,VCK30,40..4HC INNER |
1 | ||
| 90501-23093 |
UCK30,40 OUTER |
1 | ||
| 35425C - RING, O (FOR C-2 ACCUMULATOR PISTON) | ||||
| 90301-25010 |
UCK30,40,VCK30,40..4HC UPPER |
1 | ||
| 90301-31010 |
UCK3#,4#,VCK30,40..4HC LOWER |
1 | ||
| 90301-31010 |
UCK30,40,VCK30,40..4HC LOWER |
1 | ||
| 90301-25010 |
UCK3#,4#,VCK30,40..4HC UPPER |
1 | ||
| 35425C - RING, O (FOR C-2 ACCUMULATOR PISTON) | ||||
| 90301-25010 |
UCK30,40,VCK30,40..4HC UPPER |
1 | ||
| 90301-31010 |
UCK3#,4#,VCK30,40..4HC LOWER |
1 | ||
| 90301-31010 |
UCK30,40,VCK30,40..4HC LOWER |
1 | ||
| 90301-25010 |
UCK3#,4#,VCK30,40..4HC UPPER |
1 | ||
| 35426A - PISTON, C-0 ACCUMULATOR | ||||
| 35426-50010 |
UCK30,40 |
1 | ||
| 35426-50010 |
UCK3#,4# |
1 | ||
| 35426B - RING, O (FOR C-0 ACCUMULATOR PISTON) | ||||
| 90301-24010 |
UCK30,40,VCK30,40..4HC |
1 | ||
| 90301-24010 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35426C - SPRING, COMPRESSION (FOR C-0 ACCUMULATOR PISTON) | ||||
| 90501-22043 |
UCK3#,4# OUTER |
1 | ||
| 90501-19030 |
UCK30,40 INNER |
1 | ||
| 90501-19030 |
UCK3#,4# INNER |
1 | ||
| 90501-22043 |
UCK30,40 OUTER |
1 | ||
| 35426C - SPRING, COMPRESSION (FOR C-0 ACCUMULATOR PISTON) | ||||
| 90501-22043 |
UCK3#,4# OUTER |
1 | ||
| 90501-19030 |
UCK30,40 INNER |
1 | ||
| 90501-19030 |
UCK3#,4# INNER |
1 | ||
| 90501-22043 |
UCK30,40 OUTER |
1 | ||
| 35427E - PISTON, B-0 ACCUMULATOR | ||||
| 35427-30040 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 35427-30040 |
UCK30,40 |
1 | ||
| 35427F - SPRING, COMPRESSION (FOR B-0 ACCUMULATOR PISTON) | ||||
| 90501-21006 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| 90501-22019 |
UCK30,40 |
1 | ||
| 35427G - RING, O (FOR B-0 ACCUMULATOR PISTON) | ||||
| 90301-26011 |
UCK30,40,VCK30,40..4HC LOWER |
1 | ||
| 90301-20008 |
UCK3#,4#,VCK30,40..4HC UPPER |
1 | ||
| 90301-26011 |
UCK3#,4#,VCK30,40..4HC LOWER |
1 | ||
| 90301-20008 |
UCK30,40,VCK30,40..4HC UPPER |
1 | ||
| 35427G - RING, O (FOR B-0 ACCUMULATOR PISTON) | ||||
| 90301-26011 |
UCK30,40,VCK30,40..4HC LOWER |
1 | ||
| 90301-20008 |
UCK3#,4#,VCK30,40..4HC UPPER |
1 | ||
| 90301-26011 |
UCK3#,4#,VCK30,40..4HC LOWER |
1 | ||
| 90301-20008 |
UCK30,40,VCK30,40..4HC UPPER |
1 | ||
| 35481B - CLAMP, VALVE BODY WIRE HARNESS | ||||
| 35481-24010 |
UCK30,40,VCK40..4HC |
1 | ||
| 35481-24010 |
UCK3#,4#,VCK30,40..4HC |
1 | ||
| Common parts | ||||
| 90080-10162 | ||||
| 90080-11273 | ||||
| 90105-05009 | ||||
| 90105-06018 | ||||
| 90105-06025 | ||||
| 90105-06075 | ||||
| 91511-H0620 | ||||
| 91631-60614 | ||||
| 91661-60616 | ||||
| Linked diagrams | ||||
| 8410 | ||||
