AL21L-ZHHDCA (1982)
Toyota Tercel
(8208- )WG ; (8208- )5DS
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 67003 - PANEL SUB-ASSY, REAR DOOR, RH | ||||
| 67003-16050 |
AL21..5DS |
1 | ||
| 67004 - PANEL SUB-ASSY, REAR DOOR, LH | ||||
| 67004-16050 |
AL21..5DS |
1 | ||
| 67113 - PANEL, REAR DOOR, OUTER RH | ||||
| 67113-16040 |
AL2#..WG;AL21..5DS |
1 | ||
| 67114 - PANEL, REAR DOOR, OUTER LH | ||||
| 67114-16040 |
AL2#..WG;AL21..5DS |
1 | ||
| 67405 - BAR SUB-ASSY, REAR DOOR WINDOW DIVISION, RH | ||||
| 67407-16020 |
AL21..5DS |
1 | ||
| 67406 - BAR SUB-ASSY, REAR DOOR WINDOW DIVISION, LH | ||||
| 67408-16020 |
AL21..5DS |
1 | ||
| 67603 - BOARD SUB-ASSY, REAR DOOR TRIM, RH | ||||
| 67630-1610003 |
AL21..5DS;AL2#..WG..DLX GRAY,GRAY |
1 | ||
| 67630-1610002 |
AL21..5DS DARK WINE,DARK WINE |
1 | ||
| 67630-1610006 |
AL21..5DS;AL2#..WG..DLX BROWN,BROWN |
1 | ||
| 67630-1616005 |
AL2#..WG..DLX;AL21..5DS..DLX BEIGE,BEIGE |
1 | ||
| 67630-1616002 |
AL21..5DS..DLX DARK WINE,DARK WINE |
1 | ||
| 67630-1616015 |
AL2#..WG..DLX;AL21..5DS..DLX BEIGE,DARK BEIGE |
1 | ||
| 67630-1616003 |
AL2#..WG..DLX;AL21..5DS..DLX GRAY,GRAY |
1 | ||
| 67603A - RETAINER(FOR REAR DOOR TRIM BOARD) | ||||
| 67771-16020 |
AL2#..WG;AL21..5DS |
18 | ||
| 67604 - BOARD SUB-ASSY, REAR DOOR TRIM, LH | ||||
| 67640-1611006 |
AL21..5DS;AL2#..WG..DLX BROWN,BROWN |
1 | ||
| 67640-1611002 |
AL21..5DS DARK WINE,DARK WINE |
1 | ||
| 67640-1617005 |
AL2#..WG..DLX;AL21..5DS..DLX BEIGE,BEIGE |
1 | ||
| 67640-1611003 |
AL21..5DS;AL2#..WG..DLX GRAY,GRAY |
1 | ||
| 67640-1617003 |
AL2#..WG..DLX;AL21..5DS..DLX GRAY,GRAY |
1 | ||
| 67640-1617002 |
AL21..5DS..DLX DARK WINE,DARK WINE |
1 | ||
| 67640-1617015 |
AL2#..WG..DLX;AL21..5DS..DLX BEIGE,DARK BEIGE |
1 | ||
| 67803 - COVER SUB-ASSY, REAR DOOR SERVICE HOLE, RH | ||||
| 67841-16060 |
AL2#..WG;AL21..5DS |
1 | ||
| 67804 - COVER SUB-ASSY, REAR DOOR SERVICE HOLE, LH | ||||
| 67842-16030 |
AL2#..WG;AL21..5DS |
1 | ||
| 67871 - WEATHERSTRIP, REAR DOOR, RH | ||||
| 67871-16050 |
AL21..5DS |
1 | ||
| 67871-16150 |
AL21..5DS |
1 | ||
| 67871A - RETAINER(FOR REAR DOOR WEATHERSTRIP) | ||||
| 67868-30040 |
AL2#..WG;AL21..5DS |
38 | ||
| 67872 - WEATHERSTRIP, REAR DOOR, LH | ||||
| 67872-16050 |
AL21..5DS |
1 | ||
| 67872-16150 |
AL21..5DS |
1 | ||
| 68103 - GLASS SUB-ASSY, REAR DOOR, RH | ||||
| 68113-16040 |
AL21..5DS..DLX *TT,T=3.5 |
1 | ||
| 68104 - GLASS SUB-ASSY, REAR DOOR, LH | ||||
| 68114-16040 |
AL21..5DS..DLX *TT,T=3.5 |
1 | ||
| 68123 - GLASS, REAR DOOR WINDOW, RH | ||||
| 68123-16040 |
AL21..5DS..DLX *TT,T=3.5 |
1 | ||
| 68124 - GLASS, REAR DOOR WINDOW, LH | ||||
| 68124-16040 |
AL21..5DS..DLX *TT,T=3.5 |
1 | ||
| 68142 - RUN, REAR DOOR GLASS | ||||
| 68142-16020 |
AL2#..WG;AL21..5DS |
2 | ||
| 68163 - WEATHERSTRIP, REAR DOOR GLASS, OUTER | ||||
| 68180-16020 |
AL21..5DS;AL2#..WG..DLX RH |
1 | ||
| 68230-16010 |
AL21..5DS;AL2#..WG..DLX LH |
1 | ||
| 68188 - WEATHERSTRIP, REAR DOOR QUARTER WINDOW, RH | ||||
| 68188-16020 |
AL21..5DS |
1 | ||
| 68189 - WEATHERSTRIP, REAR DOOR QUARTER WINDOW, LH | ||||
| 68189-16020 |
AL21..5DS |
1 | ||
| 68190 - WEATHERSTRIP ASSY, REAR DOOR GLASS, INNER | ||||
| 68190-16030 |
AL2#..WG;AL21..5DS RH |
1 | ||
| 68240-16030 |
AL2#..WG;AL21..5DS LH |
1 | ||
| 68190A - CLIP(FOR REAR DOOR GLASS INNER WEATHERSTRIP SET) | ||||
| 68211-10030 |
AL2#..WG;AL21..5DS |
8 | ||
| 68630 - CHECK ASSY, REAR DOOR | ||||
| 68630-16020 |
AL2#..WG;AL21..5DS |
2 | ||
| 68630 - CHECK ASSY, REAR DOOR | ||||
| 68630-16020 |
AL2#..WG;AL21..5DS |
2 | ||
| 68630A - PIN(FOR REAR DOOR CHECK) | ||||
| 68617-22010 |
AL2#..WG;AL21..5DS |
2 | ||
| 68617-12010 |
AL2#..WG;AL21..5DS |
2 | ||
| Common parts | ||||
| 90179-06070 | ||||
| 90333-30002 | ||||
| 91651-40612 | ||||
| 91655-40616 | ||||
| 93229-15008 | ||||
| Linked diagrams | ||||
| 7404 | ||||
(8408- )WG ; (8408- )5DS
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 67603A - RETAINER(FOR REAR DOOR TRIM BOARD) | ||||
| 67771-16020 |
AL2#..WG;AL21..5DS |
18 | ||
