MA70L-BJMVZA (1988)
Toyota Supra
(8808- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90999-92002 | ||||
| 90999-92003 | ||||
| 90999-92004 | ||||
| 90999-92006 | ||||
| 90999-92007 | ||||
| 90999-92008 | ||||
(8808- )7MGTE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-42020 |
7MG#..MA70 |
1 | ||
| 17303-42020 |
7MG#..MA70 |
1 | ||
| 17303-42020 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 17341D - HOSE, NO.1(FOR IDLE-UP) | ||||
| 90910-05186 |
7MG#..MA70 |
1 | ||
| 90910-05186 |
7MG#..MA70 |
1 | ||
| 90910-05186 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 17341E - CLIP, NO.1(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 17341E - CLIP, NO.1(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 17342B - HOSE, NO.2(FOR IDLE-UP) | ||||
| 90445-10022 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 90445-10022 |
7MG#..MA70 |
1 | ||
| 90445-10022 |
7MG#..MA70 |
1 | ||
| 17342C - CLIP, NO.2(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 17342C - CLIP, NO.2(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 17343B - HOSE, NO.3(FOR IDLE-UP) | ||||
| 90910-05185 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 90910-05185 |
7MG#..MA70 |
1 | ||
| 90910-05185 |
7MG#..MA70 |
1 | ||
| 17343C - CLIP, NO.3(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 17343C - CLIP, NO.3(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 96132-30400 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 96132-30400 |
7MG#..MA70 |
2 | ||
| 17344C - HOSE, NO.4(FOR IDLE-UP) | ||||
| 90910-05190 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 90910-05190 |
7MG#..MA70 |
1 | ||
| 90910-05190 |
7MG#..MA70 |
1 | ||
| 17344D - CLIP, NO.4(FOR IDLE-UP HOSE) | ||||
| 96132-41300 |
7MG#..MA70 |
2 | ||
| 96132-41300 |
7MG#..MA70 |
2 | ||
| 96132-41300 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 96132-40800 |
7MG#..MA70 |
2 | ||
| 17344D - CLIP, NO.4(FOR IDLE-UP HOSE) | ||||
| 96132-41300 |
7MG#..MA70 |
2 | ||
| 96132-41300 |
7MG#..MA70 |
2 | ||
| 96132-41300 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
2 | ||
| 96132-40800 |
7MG#..MA70 |
2 | ||
| 17630 - VALVE ASSY, AIR CONTROL | ||||
| 17630-70010 |
7MG#..MA70 |
1 | ||
| 17630-70010 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 17630-70010 |
7MG#..MA70 |
1 | ||
| 17650 - VALVE ASSY, VACUUM SWITCHING | ||||
| 90910-12024 |
7MGTE..MA70 |
1 | ||
| 90910-12024 |
7MGTE..MA70 |
1 | ||
| 90910-12024 |
7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 17810A - FILTER ASSY, AIR | ||||
| 90925-06006 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 90925-06006 |
7MG#..MA70 |
1 | ||
| 90925-06006 |
7MG#..MA70 |
1 | ||
| 23262 - VALVE, BIMETAL VACUUM SWITCHING, NO.1 | ||||
| 90925-05068 |
7MG#..MA70 |
1 | ||
| 90925-05068 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 90925-05068 |
7MG#..MA70 |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01014 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 90925-01014 |
7MG#..MA70 |
1 | ||
| 90925-01014 |
7MG#..MA70 |
1 | ||
| 25706 - PIPE SUB-ASSY, VACUUM TRANSMITTING, NO.1 | ||||
| 25706-42021 |
7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 25706-42021 |
7MGTE..MA70 |
1 | ||
| 25706-42021 |
7MGTE..MA70 |
1 | ||
| 25707 - PIPE SUB-ASSY, VACUUM TRANSMITTING, NO.2 | ||||
| 25707-42010 |
7MG#..MA70 |
1 | ||
| 25707-42010 |
7MGE..MA70;7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| 25707-42010 |
7MG#..MA70 |
1 | ||
| 25860 - VALVE ASSY, VACUUM SWITCHING, NO.1 | ||||
| 25860-42020 |
7MGTE..MA70 |
1 | ||
| 25860-42020 |
7MGTE..MA70 |
1 | ||
| 25860-42020 |
7MGTE..MA70..4FC;7MGTE..MA70..SPR..5F;7MGTE..MA70..LB..5F..USA |
1 | ||
| Common parts | ||||
| 90464-00074 | ||||
| 90464-00084 | ||||
| 90929-01162 | ||||
| 90999-92002 | ||||
| 90999-92003 | ||||
| 91611-60612 | ||||
