GSL30L-PFZEHA (2016)
Toyota Sienna
(1608- )
UA80E,UA80F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 30500E - BOLT(FOR TRANSAXLE & ENGINE SETTING) | ||||
| 90080-11604 |
GSL30,33;GSL35..LE,XLE *12-1.25PX50-30,NO.2 |
1 | ||
| 90080-11310 |
GSL30,33;GSL35..LE,XLE *12-1.25PX55-30,NO.1 |
6 | ||
| 90080-11310 |
GSL3# *12-1.25PX55-30,NO.1 |
7 | ||
| 90080-10338 |
GSL3# *10-1.25PX41-30,NO.3 |
1 | ||
| 90080-10338 |
GSL30,33;GSL35..LE,XLE *10-1.25PX41-30,NO.3 |
1 | ||
| 30500E - BOLT(FOR TRANSAXLE & ENGINE SETTING) | ||||
| 90080-11604 |
GSL30,33;GSL35..LE,XLE *12-1.25PX50-30,NO.2 |
1 | ||
| 90080-11310 |
GSL30,33;GSL35..LE,XLE *12-1.25PX55-30,NO.1 |
6 | ||
| 90080-11310 |
GSL3# *12-1.25PX55-30,NO.1 |
7 | ||
| 90080-10338 |
GSL3# *10-1.25PX41-30,NO.3 |
1 | ||
| 90080-10338 |
GSL30,33;GSL35..LE,XLE *10-1.25PX41-30,NO.3 |
1 | ||
| 30500E - BOLT(FOR TRANSAXLE & ENGINE SETTING) | ||||
| 90080-11604 |
GSL30,33;GSL35..LE,XLE *12-1.25PX50-30,NO.2 |
1 | ||
| 90080-11310 |
GSL30,33;GSL35..LE,XLE *12-1.25PX55-30,NO.1 |
6 | ||
| 90080-11310 |
GSL3# *12-1.25PX55-30,NO.1 |
7 | ||
| 90080-10338 |
GSL3# *10-1.25PX41-30,NO.3 |
1 | ||
| 90080-10338 |
GSL30,33;GSL35..LE,XLE *10-1.25PX41-30,NO.3 |
1 | ||
| 33197C - CLAMP, TRANSMISSION BREATHER | ||||
| 33197-08010 |
GSL3# NO.1 |
1 | ||
| 33197-08020 |
GSL3# NO.2 |
1 | ||
| 33197C - CLAMP, TRANSMISSION BREATHER | ||||
| 33197-08010 |
GSL3# NO.1 |
1 | ||
| 33197-08020 |
GSL3# NO.2 |
1 | ||
| 35015S - PLUG, STRAIGHT(FOR TRANSMISSION CASE ADAPTER) | ||||
| 90341-A0003 |
GSL30,33 |
1 | ||
| 90341-18064 |
GSL3# |
1 | ||
| 35101E - PIN, STRAIGHT (FOR AUTOMATIC TRANSMISSION CASE) | ||||
| 90250-10021 |
GSL30,33 AISIN:REFER 35-01 |
2 | ||
| 90250-10017 |
GSL30,33 TOYOTA:REFER 35-01 |
2 | ||
| 35101E - PIN, STRAIGHT (FOR AUTOMATIC TRANSMISSION CASE) | ||||
| 90250-10021 |
GSL30,33 AISIN:REFER 35-01 |
2 | ||
| 90250-10017 |
GSL30,33 TOYOTA:REFER 35-01 |
2 | ||
| 35102G - GASKET (FOR TRANSAXLE REAR COVER ) | ||||
| 90430-A0003 |
GSL30,33 |
1 | ||
| 90430-18008 |
GSL3# |
1 | ||
| 35103C - RING, O | ||||
| 90301-06021 |
GSL3# |
1 | ||
| 35104B - PLUG, BREATHER, NO.1 (ATM) | ||||
| 90930-03216 |
GSL3# NO.1 |
1 | ||
| 90930-03230 |
GSL30,33 NO.2 |
1 | ||
| 90930-03149 |
GSL30,33;GSL35..LE,XLE |
1 | ||
| 35104B - PLUG, BREATHER, NO.1 (ATM) | ||||
| 90930-03216 |
GSL3# NO.1 |
1 | ||
| 90930-03230 |
GSL30,33 NO.2 |
1 | ||
| 90930-03149 |
GSL30,33;GSL35..LE,XLE |
1 | ||
| 35104E - CASE SUB-ASSY, AUTOMATIC TRANSAXLE | ||||
| 35141-07011 |
GSL30,33 |
1 | ||
| 35104-48030 |
GSL30,33 TOYOTA:REFER 35-01 |
1 | ||
| 35104-48040 |
GSL30,33 AISIN:REFER 35-01 |
1 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104Q - PLUG, NO.1 (FOR TRANSAXLE CASE) | ||||
| 90341-A0001 |
GSL30,33 |
3 | ||
| 90341-08001 |
GSL3# |
8 | ||
| 35104R - PLUG, NO.2 (FOR TRANSAXLE CASE) | ||||
| 90341-A0005 |
GSL30,33 |
3 | ||
| 90341-14015 |
GSL3# |
6 | ||
| 35104R - PLUG, NO.2 (FOR TRANSAXLE CASE) | ||||
| 90341-A0005 |
GSL30,33 |
3 | ||
| 90341-14015 |
GSL3# |
6 | ||
| 35104R - PLUG, NO.2 (FOR TRANSAXLE CASE) | ||||
| 90341-A0005 |
GSL30,33 |
3 | ||
| 90341-14015 |
GSL3# |
6 | ||
| 35104R - PLUG, NO.2 (FOR TRANSAXLE CASE) | ||||
| 90341-A0005 |
GSL30,33 |
3 | ||
| 90341-14015 |
GSL3# |
6 | ||
| 35104R - PLUG, NO.2 (FOR TRANSAXLE CASE) | ||||
| 90341-A0005 |
GSL30,33 |
3 | ||
| 90341-14015 |
GSL3# |
6 | ||
| 35104R - PLUG, NO.2 (FOR TRANSAXLE CASE) | ||||
| 90341-A0005 |
GSL30,33 |
3 | ||
| 90341-14015 |
GSL3# |
6 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104S - RING, O (FOR TRANSAXLE CASE PLUG NO.1) | ||||
| 90301-06196 |
GSL3# |
8 | ||
| 90080-30105 |
GSL30,33 |
3 | ||
| 35104T - RING, O (FOR TRANSAXLE CASE PLUG NO.2) | ||||
| 90301-A0016 |
GSL30,33 |
4 | ||
| 90430-14008 |
GSL3# |
3 | ||
| 35104T - RING, O (FOR TRANSAXLE CASE PLUG NO.2) | ||||
| 90301-A0016 |
GSL30,33 |
4 | ||
| 90430-14008 |
GSL3# |
3 | ||
| 35104T - RING, O (FOR TRANSAXLE CASE PLUG NO.2) | ||||
| 90301-A0016 |
GSL30,33 |
4 | ||
| 90430-14008 |
GSL3# |
3 | ||
| 35104V - HOSE (FOR BREATHER PLUG) | ||||
| 35121-73010 |
GSL30,33;GSL35..LE,XLE |
1 | ||
| 35121-45020 |
GSL3# |
1 | ||
| 35104Z - GASKET (FOR TRANSAXLE CASE) | ||||
| 90430-14008 |
GSL3# |
3 | ||
| 90430-14008 |
GSL30,33;GSL35..LE,XLE |
3 | ||
| 35104Z - GASKET (FOR TRANSAXLE CASE) | ||||
| 90430-14008 |
GSL3# |
3 | ||
| 90430-14008 |
GSL30,33;GSL35..LE,XLE |
3 | ||
| 35104Z - GASKET (FOR TRANSAXLE CASE) | ||||
| 90430-14008 |
GSL3# |
3 | ||
| 90430-14008 |
GSL30,33;GSL35..LE,XLE |
3 | ||
| 35111F - BOLT (FOR TRANSAXLE HOUSING & TRANSAXLE CASE SETTING) | ||||
| 91551-00835 |
GSL3# *8-1.25PX35-22,NO.2 |
12 | ||
| 90105-A0110 |
GSL30,33 *8-1.25PX45-22,NO.1 |
3 | ||
| 90105-A0111 |
GSL30,33 *8-1.25PX45-22,NO.2 |
17 | ||
| 91551-00840 |
GSL3# *8-1.25PX40-22,NO.1 |
6 | ||
| 35111F - BOLT (FOR TRANSAXLE HOUSING & TRANSAXLE CASE SETTING) | ||||
| 91551-00835 |
GSL3# *8-1.25PX35-22,NO.2 |
12 | ||
| 90105-A0110 |
GSL30,33 *8-1.25PX45-22,NO.1 |
3 | ||
| 90105-A0111 |
GSL30,33 *8-1.25PX45-22,NO.2 |
17 | ||
| 91551-00840 |
GSL3# *8-1.25PX40-22,NO.1 |
6 | ||
| 35111K - BOLT (FOR TRANSMISSION HOUSING & CASE SETTING) | ||||
| 91551-00840 |
GSL3# *8-1.25PX40-22 |
3 | ||
| 35125C - TUBE, TRANSMISSION OIL FILLER, NO.1 | ||||
| 35125-07020 |
GSL30,33 |
1 | ||
| 35125-48090 |
GSL3# |
1 | ||
| 35141G - RING, O (FOR AUTOMATIC TRANSMISSION CASE) | ||||
| 90301-10018 |
GSL3# |
1 | ||
| 35145C - GASKET, TRANSAXLE CASE | ||||
| 35145-07010 |
GSL30,33 |
1 | ||
| 35145-33010 |
GSL3# |
3 | ||
| 35145C - GASKET, TRANSAXLE CASE | ||||
| 35145-07010 |
GSL30,33 |
1 | ||
| 35145-33010 |
GSL3# |
3 | ||
| 35145C - GASKET, TRANSAXLE CASE | ||||
| 35145-07010 |
GSL30,33 |
1 | ||
| 35145-33010 |
GSL3# |
3 | ||
| 35150 - PLUG ASSY, TRANSMISSION CASE | ||||
| 35150-45010 |
GSL3# |
1 | ||
| 35151F - COVER, TRANSMISSION CASE, SIDE | ||||
| 35151-48100 |
GSL30,33 |
1 | ||
| 35151-33160 |
GSL3# |
1 | ||
| 35394 - MAGNET, OIL CLEANER (FOR TRANSMISSION) | ||||
| 35394-48010 |
GSL3# |
3 | ||
| 35394-08010 |
GSL30,33 |
2 | ||
| 35394 - MAGNET, OIL CLEANER (FOR TRANSMISSION) | ||||
| 35394-48010 |
GSL3# |
3 | ||
| 35394-08010 |
GSL30,33 |
2 | ||
| 35394 - MAGNET, OIL CLEANER (FOR TRANSMISSION) | ||||
| 35394-48010 |
GSL3# |
3 | ||
| 35394-08010 |
GSL30,33 |
2 | ||
| 35405C - PLUG SUB-ASSY, W/HEAD STRAIGHT SCREW | ||||
| 90341-18016 |
GSL3# |
1 | ||
| 35405D - RING, O (FOR STRAIGHT SCREW PLUG) | ||||
| 90430-18008 |
GSL3# |
1 | ||
| 35847C - TUBE, TRANSMISSION LUBE APPLY | ||||
| 35847-48020 |
GSL30,33 TOYOTA:REFER 35-01 |
1 | ||
| 35847-48030 |
GSL30,33 AISIN:REFER 35-01 |
1 | ||
| 35882C - TUBE, DIFFERENTIAL GEAR LUBE APPLY | ||||
| 35882-48030 |
GSL30,33 AISIN:REFER 35-01 |
1 | ||
| 35882-48020 |
GSL30,33 TOYOTA:REFER 35-01 |
1 | ||
| Common parts | ||||
| 90105-10587 | ||||
| 90110-08045 | ||||
| 90364-51004 | ||||
| 90462-12105 | ||||
| 91551-80625 | ||||
| 91621-40614 | ||||
