UPK60L-GKTSKA (2009)
Toyota Sequoia
(0904- )UPK6#
A760E,A760F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 34360B - CLUTCH ASSY, UNDERDRIVE 1 WAY | ||||
| 34360-0C030 |
UPK6# |
1 | ||
| 35047 - SPRING SUB-ASSY, REVERSE CLUTCH RETURN | ||||
| 35047-0C010 |
UPK6# |
1 | ||
| 35048 - PISTON SUB-ASSY, REVERSE CLUTCH | ||||
| 35048-0C010 |
UPK6# |
1 | ||
| 35048B - RING, O (FOR REVERSE CLUTCH PISTON) | ||||
| 90301-99140 |
UPK6# |
1 | ||
| 35048C - RING, O(FOR REVERSE CLUTCH PISTON INNER) | ||||
| 90301-99147 |
UPK6# |
1 | ||
| 35048D - RING, O(FOR DIRECT CLUTCH PISTON OUTER) | ||||
| 90301-99141 |
UPK6# |
1 | ||
| 35049 - HUB SUB-ASSY, REVERSE CLUTCH | ||||
| 35049-0C040 |
UPK6# |
1 | ||
| 35061 - HUB SUB-ASSY, FORWARD CLUTCH | ||||
| 35061-0C010 |
UPK6# |
1 | ||
| 35064 - HUB SUB-ASSY, COAST CLUTCH | ||||
| 35064-50010 |
UPK6# |
1 | ||
| 35601 - DRUM SUB-ASSY, CLUTCH | ||||
| 35601-0C010 |
UPK6# |
1 | ||
| 35602A - PISTON SUB-ASSY, FORWARD CLUTCH | ||||
| 35602-34020 |
UPK6# |
1 | ||
| 35602D - RING, SHAFT SNAP(FOR FORWARD CLUTCH PISTON RETURN SPRIN | ||||
| 90520-35003 |
UPK6# |
1 | ||
| 35602K - RING, O(FOR FORWARD CLUTCH PISTON INNER) | ||||
| 90301-33017 |
UPK6# |
1 | ||
| 35603A - SPRING SUB-ASSY, FORWARD CLUTCH RETURN | ||||
| 35603-0C040 |
UPK6# |
1 | ||
| 35604 - SPRING SUB-ASSY, DIRECT CLUTCH RETURN | ||||
| 35604-0C010 |
UPK6# |
1 | ||
| 35606A - PISTON SUB-ASSY, DIRECT CLUTCH | ||||
| 35652-60031 |
UPK6# |
1 | ||
| 35606E - RING, SHAFT SNAP (FOR DIRECT CLUTCH PISTON RETURN SPRIN | ||||
| 90520-64003 |
UPK6# |
1 | ||
| 35606K - RING, O(FOR DIRECT CLUTCH PISTON INNER) | ||||
| 90301-74002 |
UPK6# |
1 | ||
| 35606L - RING, O(FOR DIRECT CLUTCH PISTON OUTER) | ||||
| 90301-99149 |
UPK6# |
1 | ||
| 35613 - RING, CLUTCH PISTON OIL SEAL, OUTER | ||||
| 35613-50011 |
UPK6# |
1 | ||
| 35613-50010 |
UPK6# |
1 | ||
| 35617G - RING, CLUTCH DRUM OIL SEAL | ||||
| 35614-50010 |
UPK6# |
1 | ||
| 35621Y - PISTON, COAST CLUTCH | ||||
| 35621-50010 |
UPK6# |
1 | ||
| 35631 - HUB, CLUTCH(FOR MULTIPLE DISC CLUTCH) | ||||
| 35631-34020 |
UPK6# |
1 | ||
| 35633B - DISC, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35633-0C030 |
UPK6# |
5 | ||
| 35633B - DISC, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35633-0C030 |
UPK6# |
5 | ||
| 35633B - DISC, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35633-0C030 |
UPK6# |
5 | ||
| 35633B - DISC, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35633-0C030 |
UPK6# |
5 | ||
| 35633B - DISC, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35633-0C030 |
UPK6# |
5 | ||
| 35634A - PLATE, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35634-0C010 |
UPK6# T=1.8 |
5 | ||
| 35634A - PLATE, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35634-0C010 |
UPK6# T=1.8 |
5 | ||
| 35634A - PLATE, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35634-0C010 |
UPK6# T=1.8 |
5 | ||
| 35634A - PLATE, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35634-0C010 |
UPK6# T=1.8 |
5 | ||
| 35634A - PLATE, CLUTCH (FOR FORWARD MULTIPLE DISC CLUTCH) | ||||
| 35634-0C010 |
UPK6# T=1.8 |
5 | ||
| 35635 - FLANGE, FORWARD CLUTCH | ||||
| 35635-0C050 |
UPK6# T=3.4,MARK 4 |
1 | ||
| 35635-0C070 |
UPK6# T=3.6,MARK 6 |
1 | ||
| 35635-0C080 |
UPK6# T=3.7,MARK 7 |
1 | ||
| 35635-0C010 |
UPK6# T=3.0,MARK 0 |
1 | ||
| 35635-0C020 |
UPK6# T=3.1,MARK 1 |
1 | ||
| 35635-0C060 |
UPK6# T=3.5,MARK 5 |
1 | ||
| 35635-0C090 |
UPK6# T=3.8,MARK 8 |
1 | ||
| 35635-0C030 |
UPK6# T=3.2,MARK 2 |
1 | ||
| 35635-0C110 |
UPK6# T=4.0,MARK A |
1 | ||
| 35635-0C100 |
UPK6# T=3.9,MARK 9 |
1 | ||
| 35635-0C040 |
UPK6# T=3.3,MARK 3 |
1 | ||
| 35647A - PLATE, CLUTCH (FOR DIRECT MULTIPLE DISC CLUTCH) | ||||
| 35647-0C010 |
UPK6# |
6 | ||
| 35647A - PLATE, CLUTCH (FOR DIRECT MULTIPLE DISC CLUTCH) | ||||
| 35647-0C010 |
UPK6# |
6 | ||
| 35647A - PLATE, CLUTCH (FOR DIRECT MULTIPLE DISC CLUTCH) | ||||
| 35647-0C010 |
UPK6# |
6 | ||
| 35647A - PLATE, CLUTCH (FOR DIRECT MULTIPLE DISC CLUTCH) | ||||
| 35647-0C010 |
UPK6# |
6 | ||
| 35647A - PLATE, CLUTCH (FOR DIRECT MULTIPLE DISC CLUTCH) | ||||
| 35647-0C010 |
UPK6# |
6 | ||
| 35647A - PLATE, CLUTCH (FOR DIRECT MULTIPLE DISC CLUTCH) | ||||
| 35647-0C010 |
UPK6# |
6 | ||
| 35648D - PLATE, CLUTCH, NO.3 | ||||
| 35648-0C030 |
UPK6# |
4 | ||
| 35648D - PLATE, CLUTCH, NO.3 | ||||
| 35648-0C030 |
UPK6# |
4 | ||
| 35648D - PLATE, CLUTCH, NO.3 | ||||
| 35648-0C030 |
UPK6# |
4 | ||
| 35648D - PLATE, CLUTCH, NO.3 | ||||
| 35648-0C030 |
UPK6# |
4 | ||
| 35649 - FLANGE, REVERSE CLUTCH | ||||
| 35649-0C040 |
UPK6# T=3.1,MARK 3,T=3.1 |
1 | ||
| 35649-0C060 |
UPK6# T=3.3,MARK 5,T=3.3 |
1 | ||
| 35649-0C110 |
UPK6# T=3.8,MARK A,T=3.8 |
1 | ||
| 35649-0C080 |
UPK6# T=3.5,MARK 7,T=3.5 |
1 | ||
| 35649-0C030 |
UPK6# T=3.0,MARK 2,T=3.0 |
1 | ||
| 35649-0C070 |
UPK6# T=3.4,MARK 6,T=3.4 |
1 | ||
| 35649-0C100 |
UPK6# T=3.7,MARK 9,T=3.7 |
1 | ||
| 35649-0C050 |
UPK6# T=3.2,MARK 4,T=3.2 |
1 | ||
| 35649-0C090 |
UPK6# T=3.6,MARK 8,T=3.6 |
1 | ||
| 35649A - RING, HOLE SNAP(FOR REVERSE CLUTCH FLANGE) | ||||
| 90520-99074 |
UPK6# |
2 | ||
| 35649A - RING, HOLE SNAP(FOR REVERSE CLUTCH FLANGE) | ||||
| 90520-99074 |
UPK6# |
2 | ||
| 35649B - FLANGE, REVERSE CLUTCH | ||||
| 35649-0C030 |
UPK6# T=3.0,MARK 2 |
1 | ||
| 35649C - FLANGE, REVERSE CLUTCH | ||||
| 35649-0C050 |
UPK6# T=3.2,MARK 4 |
1 | ||
| 35649-0C020 |
UPK6# T=2.9,MARK 1 |
1 | ||
| 35649-0C040 |
UPK6# T=3.1,MARK 3 |
1 | ||
| 35649-0C030 |
UPK6# T=3.0,MARK 2 |
1 | ||
| 35649-0C080 |
UPK6# T=3.5,MARK 7 |
1 | ||
| 35649-0C010 |
UPK6# T=2.8,MARK 0 |
1 | ||
| 35649-0C070 |
UPK6# T=3.4,MARK 6 |
1 | ||
| 35649-0C090 |
UPK6# T=3.6,MARK 8 |
1 | ||
| 35649-0C100 |
UPK6# T=3.7,MARK 9 |
1 | ||
| 35649-0C060 |
UPK6# T=3.3,MARK 5 |
1 | ||
| 35649-0C110 |
UPK6# T=3.8,MARK A |
1 | ||
| 35659 - SLEEVE, REVERSE CLUTCH REACTION | ||||
| 35659-60020 |
UPK6# |
1 | ||
| 35659A - RING, SNAP (FOR REVERSE CLUTCH REACTION SLEEVE) | ||||
| 90520-99083 |
UPK6# |
1 | ||
| 35667A - DISK, DIRECT CLUTCH | ||||
| 35667-0C010 |
UPK6# |
6 | ||
| 35667A - DISK, DIRECT CLUTCH | ||||
| 35667-0C010 |
UPK6# |
6 | ||
| 35667A - DISK, DIRECT CLUTCH | ||||
| 35667-0C010 |
UPK6# |
6 | ||
| 35667A - DISK, DIRECT CLUTCH | ||||
| 35667-0C010 |
UPK6# |
6 | ||
| 35667A - DISK, DIRECT CLUTCH | ||||
| 35667-0C010 |
UPK6# |
6 | ||
| 35667A - DISK, DIRECT CLUTCH | ||||
| 35667-0C010 |
UPK6# |
6 | ||
| 35668 - BALANCER, CLUTCH, NO.1 | ||||
| 35668-50010 |
UPK6# |
1 | ||
| 35668B - RING, O(FOR CLUTCH BALANCER) | ||||
| 90301-98004 |
UPK6# |
1 | ||
| 35669 - BALANCER, CLUTCH, NO.2 | ||||
| 35669-0C010 |
UPK6# |
1 | ||
| 35672A - PLATE, CLUTCH CUSHION (FOR DIRECT MULTIPLE DISC CLUTCH) | ||||
| 35672-60020 |
UPK6# |
1 | ||
| 35675B - RING, HOLE SNAP (FOR FORWARD CLUTCH FLANGE) | ||||
| 90520-99082 |
UPK6# |
1 | ||
| 35675J - FLANGE, COAST CLUTCH | ||||
| 35675-0C220 |
UPK6# T=3.1,MARK 1 |
1 | ||
| 35675-0C210 |
UPK6# T=3.0,MARK 0 |
1 | ||
| 35675-0C250 |
UPK6# T=3.4,MARK 4 |
1 | ||
| 35675-0C280 |
UPK6# T=3.7,MARK 7 |
1 | ||
| 35675-0C270 |
UPK6# T=3.6,MARK 6 |
1 | ||
| 35675-0C230 |
UPK6# T=3.2,MARK 2 |
1 | ||
| 35675-0C240 |
UPK6# T=3.3,MARK 3 |
1 | ||
| 35675-0C300 |
UPK6# T=3.9,MARK A |
1 | ||
| 35675-0C260 |
UPK6# T=3.5,MARK 5 |
1 | ||
| 35675-0C290 |
UPK6# T=3.8,MARK 8 |
1 | ||
| 35675K - RING, SNAP (FOR COAST CLUTCH FLANGE) | ||||
| 90520-99089 |
UPK6# |
1 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-0C030 |
UPK6# |
5 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-0C030 |
UPK6# |
5 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-0C030 |
UPK6# |
5 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-0C030 |
UPK6# |
5 | ||
| 35677C - DISC, REAR CLUTCH | ||||
| 35677-0C030 |
UPK6# |
5 | ||
| 35685 - DISC, COAST CLUTCH | ||||
| 35685-0C020 |
UPK6# |
3 | ||
| 35685 - DISC, COAST CLUTCH | ||||
| 35685-0C020 |
UPK6# |
3 | ||
| 35685 - DISC, COAST CLUTCH | ||||
| 35685-0C020 |
UPK6# |
3 | ||
| 35688 - BALANCER, CLUTCH, NO.3 | ||||
| 35688-50010 |
UPK6# |
1 | ||
| 35688A - RING, SNAP (FOR REVERSE CLUTCH RETURN SPRING) | ||||
| 90520-79001 |
UPK6# |
1 | ||
| 35695A - PLATE, COAST CLUTCH | ||||
| 35695-0C020 |
UPK6# |
3 | ||
| 35695A - PLATE, COAST CLUTCH | ||||
| 35695-0C020 |
UPK6# |
3 | ||
| 35695A - PLATE, COAST CLUTCH | ||||
| 35695-0C020 |
UPK6# |
3 | ||
| 35701 - SHAFT SUB-ASSY, INPUT | ||||
| 35701-0C040 |
UPK6# |
1 | ||
| 35701J - BEARING, THRUST NEEDLE ROLLER (FOR INPUT SHAFT FRONT) | ||||
| 90374-A0009 |
UPK6# |
1 | ||
| 35712A - RING, INPUT SHAFT OIL SEAL | ||||
| 35712-60010 |
UPK6# |
4 | ||
| 35712A - RING, INPUT SHAFT OIL SEAL | ||||
| 35712-60010 |
UPK6# |
4 | ||
| 35712A - RING, INPUT SHAFT OIL SEAL | ||||
| 35712-60010 |
UPK6# |
4 | ||
| 35712A - RING, INPUT SHAFT OIL SEAL | ||||
| 35712-60010 |
UPK6# |
4 | ||
| 35786A - RACE, THRUST BEARING, NO.1 | ||||
| 35786-0C010 |
UPK6# |
1 | ||
| 35786G - BEARING,THRUST NEEDLE ROLLER | ||||
| 90374-A0001 |
UPK6# |
1 | ||
| 35787D - BEARING, THRUST NEEDLE ROLLER | ||||
| 90374-A0034 |
UPK6# |
1 | ||
| 35787E - BEARING, THRUST NEEDLE ROLLER | ||||
| 90374-A0004 |
UPK6# |
1 | ||
| 35789T - RACE, THRUST BEARING (INPUT SHAFT REAR) | ||||
| 35789-0C440 |
UPK6# NO.1 |
1 | ||
| 35789-0C450 |
UPK6# NO.2 |
1 | ||
| 35789T - RACE, THRUST BEARING (INPUT SHAFT REAR) | ||||
| 35789-0C440 |
UPK6# NO.1 |
1 | ||
| 35789-0C450 |
UPK6# NO.2 |
1 | ||
| 35789Z - BEARING, THRUST NEEDLE ROLLER | ||||
| 90374-A0002 |
UPK6# |
1 | ||
| Common parts | ||||
| 90520-84003 | ||||
