AXAP54L-ANXGBK (2020)

Toyota Rav4

Production Jun 2020 - Sep 9999
Engine A25AFXS
Transmission CVT
Displacement 2500cc
Power 168 HP (125 kW)

(2006- )

Click highlighted areas on diagram

diagram 42601 42601A 42601C 42603 42607 42607D 42611G 42611J
Part # Description Qty Price
42601 - WHEEL, DISC
42611-42580

AXAP54..SE

18X7J,#,TYPE A:REFER ILLUST.

 4
42611-42590

AXAP54..XSE

19X7.5J,#,TYPE B:REFER ILLUST.

 4
42601A - WHEEL, DISC (FOR SPARE)
42611-42780

AXAP54..XSE

18X4T,TYPE C:REFER ILLUST.

 1
42611-33E70

AXAP54..SE

17X4T,TYPE C:REFER ILLUST.

 1
42601C - NUT, HUB (FOR AXLE)
90942-01033

AXAP54

 20
42603 - ORNAMENT SUB-ASSY, WHEEL HUB
42603-42130

AXAP54

*ALU,TYPE A:REFER ILLUST.

 4
42607 - VALVE SUB-ASSY, TIRE PRESSURE MONITOR
42607-12010

AXAP54..CND

TIRE INFLATION PRESSURE WARNING-W(315MHZ, RESET SWITCH & AUTO LOCATION)

 4
42607D - VALVE, TIRE PRESSURE MONITOR
90942-05043

AXAP54..CND

TIRE INFLATION PRESSURE WARNING-W(315MHZ, RESET SWITCH & AUTO LOCATION)

 4
42611G - VALVE (FOR TUBELESS TIRE)
90942-05009

AXAP54..CND

 4
42611J - VALVE (FOR TUBELESS TIRE SPARE)
90942-05009

AXAP54

 1
