ZVW35L-BHXBBA (2012)
Toyota Prius(Plug-In Hbd)
Production
Jan 2012
-
Jun 2015
Engine
2ZRFXE
Transmission
CVFC ATM
Displacement
2500cc
Power
168 HP (125 kW)
ILLUST NO. 1 OF 2(1201- )
Click highlighted areas on diagram
ENGINE ROOM, EXTERIOR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11285A - LABEL, COOLANT SYSTEM NOTICE | ||||
| 11285-37060 |
2ZRFXE..ZVW35 |
1 | ||
| 11293D - LABEL, ENGINE CAUTION | ||||
| 11293-21081 |
2ZRFXE..ZVW35 |
1 | ||
| 11293-36070 |
2ZRFXE..ZVW35 |
1 | ||
| 11298B - LABEL, EMISSION CONTROL INFORMATION | ||||
| 11298-37310 |
2ZRFXE..ZVW35 |
1 | ||
| 11298-37490 |
2ZRFXE..ZVW35 |
1 | ||
| 11298-37510 |
2ZRFXE..ZVW35 |
1 | ||
| 11298-37430 |
2ZRFXE..ZVW35 |
1 | ||
| 16793B - LABEL, COOLING FAN INFORMATION | ||||
| 16793-31040 |
2ZRFXE..ZVW35 |
1 | ||
| 69339C - LABEL, CHILD PROTECTOR INFORMATION | ||||
| 69339-33040 |
ZVW35 |
2 | ||
| 74511F - LABEL, NAME (IDENTIFICATION LASER LABEL) | ||||
| 74514-33010 |
ZVW35..USA *111 |
1 | ||
| 74559B - LABEL, FUEL INFORMATION | ||||
| 74559-48010 |
ZVW35 |
1 | ||
| 74573D - LABEL, ELECTRIC VEHICLE BATTERY CAUTION | ||||
| 74573-47040 |
ZVW35 |
1 | ||
| 74596A - LABEL, SIDE AIR BAG CAUTION | ||||
| 74596-53011 |
ZVW35 |
2 | ||
| 88723E - LABEL, COOLER SERVICE CAUTION | ||||
| 88723-47090 |
ZVW35 |
1 | ||
| G9275 - LABEL, BATTERY CAUTION, NO.1 | ||||
| G9275-47060 |
ZVW35 |
1 | ||
ILLUST NO. 2 OF 2(1201- )
Click highlighted areas on diagram
INTERIOR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 74559A - PLATE, FUEL CAUTION | ||||
| 74559-30070 |
ZVW35 |
1 | ||
| 74572A - LABEL, FUEL INLET OPERATIONAL INFORMATION | ||||
| 74572-48010 |
ZVW35 |
1 | ||
| 74599B - LABEL, DRIVER & PASSENGER AIR BAG INFORMATION | ||||
| 74599-48020 |
ZVW35..USA |
1 | ||
| 82685 - PLATE, CAUTION | ||||
| 82685-47100 |
ZVW35 |
1 | ||
