LFA10L-FCRAFA (2010)
Toyota Lexus Lfa
Production
Dec 2010
-
Dec 2012
Engine
1LRGUE
Transmission
6F ASG
Displacement
2500cc
Power
168 HP (125 kW)
(1012- )
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 51965F - RETAINER, REAR HOOK, RH | ||||
| 51965-77010 |
LFA10 |
1 | ||
| 51966C - RETAINER, REAR HOOK, LH | ||||
| 51966-77010 |
LFA10 |
1 | ||
| 52023 - REINFORCEMENT SUB-ASSY, REAR BUMPER | ||||
| 52023-77010 |
LFA10 |
1 | ||
| 52108B - EXTENSION SUB-ASSY, REAR BUMPER SIDE, RH | ||||
| 52106-77010 |
LFA10 |
1 | ||
| 52108C - EXTENSION SUB-ASSY, REAR BUMPER, CENTER | ||||
| 52108-77010 |
LFA10 |
1 | ||
| 52109C - EXTENSION SUB-ASSY, REAR BUMPER SIDE, LH | ||||
| 52107-77010 |
LFA10 |
1 | ||
| 52115H - SUPPORT, REAR BUMPER SIDE | ||||
| 52115-77010 |
LFA10 |
12 | ||
| 52151G - EXTENSION, REAR BUMPER | ||||
| 52151-77030B1 |
LFA10 NURBURGRING PACKAGE&AUDIO-MARK LEVINSON 12SPEAKER,GRAY |
1 | ||
| 52151-77040B1 |
LFA10 GRAY |
1 | ||
| 52151-77030B1 |
LFA10 AUDIO-MARK LEVINSON 12SPEAKER,GRAY |
1 | ||
| 52155A - SUPPORT, REAR BUMPER SIDE, RH | ||||
| 52155-77010 |
LFA10 |
1 | ||
| 52156A - SUPPORT, REAR BUMPER SIDE, LH | ||||
| 52156-77010 |
LFA10 |
1 | ||
| 52156D - SUPPORT, REAR BUMPER SIDE, LWR | ||||
| 52117-77010 |
LFA10 |
4 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-77020 |
LFA10 PAINT REQ. |
1 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-77010 |
LFA10 |
14 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-77010 |
LFA10 |
14 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-77010 |
LFA10 |
14 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-77010 |
LFA10 |
14 | ||
| 52175A - BRACKET, REAR BUMPER ARM MOUNTING, RH | ||||
| 52175-77010 |
LFA10 |
1 | ||
| 52176A - BRACKET, REAR BUMPER ARM MOUNTING, LH | ||||
| 52176-77010 |
LFA10 |
1 | ||
| 52179B - PLATE, REAR BUMPER BAR | ||||
| 52179-77010 |
LFA10 |
1 | ||
| 52185F - BRACKET, REAR BUMPER SIDE MOUNTING | ||||
| 52185-77010 |
LFA10 |
2 | ||
| 52193A - PLATE, BUMPER MOULDING MOUNTING, RH | ||||
| 52193-77020 |
LFA10 |
1 | ||
| 52197A - BRACKET, REAR BUMPER SEAL, RH | ||||
| 52197-30040 |
LFA10 |
1 | ||
| 52197B - BRACKET, REAR BUMPER SEAL, LH | ||||
| 52197-30040 |
LFA10 |
1 | ||
| 52561 - RETAINER, REAR BUMPER, UPPER CENTER | ||||
| 52561-77010 |
LFA10 |
1 | ||
| 52587 - RETAINER, REAR BUMPER END, RH | ||||
| 52587-77020 |
LFA10 |
1 | ||
| 52588 - RETAINER, REAR BUMPER END, LH | ||||
| 52588-77020 |
LFA10 |
1 | ||
| 52589 - RETAINER, REAR BUMPER END, NO.2 | ||||
| 52589-77020 |
LFA10 |
1 | ||
| 52591A - SEAL, REAR BUMPER | ||||
| 53883-77010 |
LFA10 |
2 | ||
| 52591A - SEAL, REAR BUMPER | ||||
| 53883-77010 |
LFA10 |
2 | ||
| 52723 - MOULDING, REAR BUMPER EXTENSION, RH | ||||
| 52723-77010 |
LFA10 |
1 | ||
| 52724 - MOULDING, REAR BUMPER EXTENSION, LH | ||||
| 52724-77010 |
LFA10 |
1 | ||
| 52791 - BOLT, BUMPER MOULDING SET, NO.1 | ||||
| 52791-77010 |
LFA10 |
8 | ||
| 52791 - BOLT, BUMPER MOULDING SET, NO.1 | ||||
| 52791-77010 |
LFA10 |
8 | ||
| 52791 - BOLT, BUMPER MOULDING SET, NO.1 | ||||
| 52791-77010 |
LFA10 |
8 | ||
| 53103B - GRILLE SUB-ASSY, RADIATOR, LOWER RH | ||||
| 53103-77010 |
LFA10 |
1 | ||
| 53104B - GRILLE SUB-ASSY, RADIATOR, LOWER LH | ||||
| 53104-77010 |
LFA10 |
1 | ||
| 53127C - GRILLE, RADIATOR, LOWER RH | ||||
| 53127-77010 |
LFA10 |
1 | ||
| 53128D - GRILLE, RADIATOR, LOWER LH | ||||
| 53128-77010 |
LFA10 |
1 | ||
| 64189C - BOLT, REAR BODY MOUNTING | ||||
| 64189-77020 |
LFA10 |
16 | ||
| 64189C - BOLT, REAR BODY MOUNTING | ||||
| 64189-77020 |
LFA10 |
16 | ||
| 64189C - BOLT, REAR BODY MOUNTING | ||||
| 64189-77020 |
LFA10 |
16 | ||
| 64726M - CLIP, LUGGAGE TRIM, REAR | ||||
| 64726-77010 |
LFA10 |
4 | ||
| 64726M - CLIP, LUGGAGE TRIM, REAR | ||||
| 64726-77010 |
LFA10 |
4 | ||
| 75129A - CUSHION, REAR LICENCE PLATE | ||||
| 75129-13020 |
LFA10 |
2 | ||
| 75392 - RETAINER, OUTSIDE MOULDING | ||||
| 75392-35200 |
LFA10 |
5 | ||
| 81481L - COVER, FOG LAMP, RH | ||||
| 81481-77010 |
LFA10 |
1 | ||
| 81482H - COVER, FOG LAMP, LH | ||||
| 81482-77010 |
LFA10 |
1 | ||
| Common parts | ||||
| 90105-08264 | ||||
| 90119-06451 | ||||
| 90119-06773 | ||||
| 90119-06932 | ||||
| 90119-08C90 | ||||
| 90159-60498 | ||||
| 90159-60500 | ||||
| 90179-05078 | ||||
| 90183-06030 | ||||
| 90189-06193 | ||||
| 90201-06023 | ||||
| 90467-09230 | ||||
| 91551-A0620 | ||||
| 91551-A0622 | ||||
| 93540-A4012 | ||||
| 93560-A4016 | ||||
| 94151-80841 | ||||
| Linked diagrams | ||||
| 0901 | ||||
| 6101 | ||||
| 7501 | ||||
| 8112 | ||||
| 8116 | ||||
