PZJ70LV-MR (1990)
Toyota Land Cruiser
(9001-9208)1PZ..RHD ; (9208-9401)1PZ
W(PRE FILTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04234 - ELEMENT KIT, FUEL FILTER | ||||
| 04234-68010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23274B - HOSE, FUEL, NO.3 | ||||
| 23274-17010 |
1PZ..PZJ7# |
1 | ||
| 95332-10090 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-17130 |
1PZ..PZJ7# |
1 | ||
| 23301-17060 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23301-17130 |
1PZ..PZJ70,75..LHD W(PRE FILTER) |
1 | ||
| 23301-17060 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23302 - BODY SUB-ASSY, FUEL FILTER, LOWER | ||||
| 23302-17010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23303 - ELEMENT SUB-ASSY, FUEL FILTER | ||||
| 23303-64010 |
1PZ..PZJ7# |
1 | ||
| 23304 - BAIL SUB-ASSY, FILTER BOWL | ||||
| 23304-56010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23311 - BODY, FUEL FILTER UPPER | ||||
| 23311-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23312 - GASKET, FILTER BOWL | ||||
| 23312-68010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23322 - PLUG, DRAIN(FOR FUEL FILTER) | ||||
| 23322-64010 |
1PZ..PZJ7# |
1 | ||
| 23322A - RING, O(FOR DRAIN PLUG) | ||||
| 23344-54010 |
1PZ..PZJ7# |
1 | ||
| 23344-54010 |
1PZ..PZJ7# |
1 | ||
| 23323A - UNION | ||||
| 23323-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23324 - NIPPLE UNION(FOR FUEL FILTER) | ||||
| 23324-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23330 - PREFILTER ASSY, FUEL | ||||
| 23330-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23332 - GASKET, ELEMENT(FOR FUEL FILTER) | ||||
| 23332-68010 |
1PZ..PZJ7#..GEN |
2 | ||
| 23332 - GASKET, ELEMENT(FOR FUEL FILTER) | ||||
| 23332-68010 |
1PZ..PZJ7#..GEN |
2 | ||
| 23333 - SPRING, FILTER ELEMENT SET | ||||
| 23333-48012 |
1PZ..PZJ7#..GEN |
1 | ||
| 23334 - PLATE, SPRING(FOR FILTER ELEMENT) | ||||
| 23334-46010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23338 - GASKET(FOR WARNING SWITCH) | ||||
| 23344-64010 |
1PZ..PZJ7# |
1 | ||
| 23344-64010 |
1PZ..PZJ7# |
1 | ||
| 23344 - GASKET, CLAMPING NUT(FOR FUEL FILTER) | ||||
| 23344-68010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23921 - SUPPORT, FUEL FILTER | ||||
| 23904-17040 |
1PZ..PZJ7#..GEN W(PRE FILTER) |
1 | ||
| 23921-17030 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23904-17040 |
1PZ..PZJ7# W(PRE FILTER) |
1 | ||
| 23921-17030 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23921-58010 |
1PZ..PZJ7# |
1 | ||
| 84461B - SWITCH, LEVEL WARNING | ||||
| 84461-35060 |
PZJ7# |
1 | ||
| Common parts | ||||
| 23347-54010 | ||||
| 90099-18010 | ||||
| 90119-08931 | ||||
| 91651-40816 | ||||
| 91651-40820 | ||||
| 91651-60830 | ||||
| 93319-15008 | ||||
| 96132-31000 | ||||
| Linked diagrams | ||||
| 1703 | ||||
(9001-9208)1PZ..PZJ70,75..LHD
W(PRE FILTER)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04234 - ELEMENT KIT, FUEL FILTER | ||||
| 04234-68010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23271G - HOSE, FUEL | ||||
| 95332-10070 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23274B - HOSE, FUEL, NO.3 | ||||
| 23274-17010 |
1PZ..PZJ7# |
1 | ||
| 95332-10090 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-17130 |
1PZ..PZJ7# |
1 | ||
| 23301-17060 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23301-17130 |
1PZ..PZJ70,75..LHD W(PRE FILTER) |
1 | ||
| 23301-17060 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23302 - BODY SUB-ASSY, FUEL FILTER, LOWER | ||||
| 23302-17010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23303 - ELEMENT SUB-ASSY, FUEL FILTER | ||||
| 23303-64010 |
1PZ..PZJ7# |
1 | ||
| 23304 - BAIL SUB-ASSY, FILTER BOWL | ||||
| 23304-56010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23311 - BODY, FUEL FILTER UPPER | ||||
| 23311-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23312 - GASKET, FILTER BOWL | ||||
| 23312-68010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23322 - PLUG, DRAIN(FOR FUEL FILTER) | ||||
| 23322-64010 |
1PZ..PZJ7# |
1 | ||
| 23322A - RING, O(FOR DRAIN PLUG) | ||||
| 23344-54010 |
1PZ..PZJ7# |
1 | ||
| 23344-54010 |
1PZ..PZJ7# |
1 | ||
| 23323A - UNION | ||||
| 23323-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23324 - NIPPLE UNION(FOR FUEL FILTER) | ||||
| 23324-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23330 - PREFILTER ASSY, FUEL | ||||
| 23330-17020 |
1PZ..PZJ7#..GEN |
1 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23330A - GASKET | ||||
| 90430-14002 |
1PZ..PZJ7#..GEN |
4 | ||
| 23332 - GASKET, ELEMENT(FOR FUEL FILTER) | ||||
| 23332-68010 |
1PZ..PZJ7#..GEN |
2 | ||
| 23332 - GASKET, ELEMENT(FOR FUEL FILTER) | ||||
| 23332-68010 |
1PZ..PZJ7#..GEN |
2 | ||
| 23333 - SPRING, FILTER ELEMENT SET | ||||
| 23333-48012 |
1PZ..PZJ7#..GEN |
1 | ||
| 23334 - PLATE, SPRING(FOR FILTER ELEMENT) | ||||
| 23334-46010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23338 - GASKET(FOR WARNING SWITCH) | ||||
| 23344-64010 |
1PZ..PZJ7# |
1 | ||
| 23344-64010 |
1PZ..PZJ7# |
1 | ||
| 23344 - GASKET, CLAMPING NUT(FOR FUEL FILTER) | ||||
| 23344-68010 |
1PZ..PZJ7#..GEN |
1 | ||
| 23921 - SUPPORT, FUEL FILTER | ||||
| 23904-17040 |
1PZ..PZJ7#..GEN W(PRE FILTER) |
1 | ||
| 23921-17030 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23904-17040 |
1PZ..PZJ7# W(PRE FILTER) |
1 | ||
| 23921-17030 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23921-58010 |
1PZ..PZJ7# |
1 | ||
| 84461B - SWITCH, LEVEL WARNING | ||||
| 84461-35060 |
PZJ7# |
1 | ||
| Common parts | ||||
| 23347-54010 | ||||
| 90099-18010 | ||||
| 90119-08931 | ||||
| 90464-00311 | ||||
| 90464-00500 | ||||
| 91651-40820 | ||||
| 93319-15008 | ||||
| 96132-31000 | ||||
| Linked diagrams | ||||
| 2202 | ||||
(9001-9401)1PZ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-17130 |
1PZ..PZJ7# |
1 | ||
| 23301-17060 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23301-17130 |
1PZ..PZJ70,75..LHD W(PRE FILTER) |
1 | ||
| 23301-17060 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23303 - ELEMENT SUB-ASSY, FUEL FILTER | ||||
| 23303-64010 |
1PZ..PZJ7# |
1 | ||
| 23322 - PLUG, DRAIN(FOR FUEL FILTER) | ||||
| 23322-64010 |
1PZ..PZJ7# |
1 | ||
| 23322A - RING, O(FOR DRAIN PLUG) | ||||
| 23344-54010 |
1PZ..PZJ7# |
1 | ||
| 23344-54010 |
1PZ..PZJ7# |
1 | ||
| 23338 - GASKET(FOR WARNING SWITCH) | ||||
| 23344-64010 |
1PZ..PZJ7# |
1 | ||
| 23344-64010 |
1PZ..PZJ7# |
1 | ||
| 23921 - SUPPORT, FUEL FILTER | ||||
| 23904-17040 |
1PZ..PZJ7#..GEN W(PRE FILTER) |
1 | ||
| 23921-17030 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23904-17040 |
1PZ..PZJ7# W(PRE FILTER) |
1 | ||
| 23921-17030 |
1PZ..PZJ70,75..LHD |
1 | ||
| 23921-58010 |
1PZ..PZJ7# |
1 | ||
| 84461B - SWITCH, LEVEL WARNING | ||||
| 84461-35060 |
PZJ7# |
1 | ||
| Common parts | ||||
| 23347-54010 | ||||
| 91651-40816 | ||||
| 91651-60830 | ||||
| 93319-15008 | ||||
