HZJ75LV-KR (1990)
Toyota Land Cruiser
(9001-9201)FJ7#,HZJ75,PZJ7#..STD..GEN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04494 - SHOE KIT, FRONT BRAKE | ||||
| 04494-60030 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
1 | ||
| 04905 - CUP KIT, FRONT WHEEL CYLINDER | ||||
| 04905-36070 |
FJ75,HZJ75,PZJ75..GEN |
1 | ||
| 47041 - PLATE SUB-ASSY, BRAKE BACKING, FRONT RH | ||||
| 47041-60050 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
1 | ||
| 47041D - BOLT(FOR BACKING PLATE TO STEERING KNUCKLE SETTING) | ||||
| 90101-10166 |
FJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN |
16 | ||
| 90101-10439 |
FJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN |
16 | ||
| 47042 - PLATE SUB-ASSY, BRAKE BACKING, FRONT LH | ||||
| 47042-60010 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
1 | ||
| 47410C - SPRING(FOR FRONT BRAKE SHOE HOLD DOWN) | ||||
| 90501-23002 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
4 | ||
| 47410D - SPRING, TENSION(FOR FRONT BRAKE SHOE RETURN) | ||||
| 90506-29006 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| 47410E - SPRING, TENSION(FOR FRONT BRAKE SHOE RETURN) | ||||
| 90506-29006 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| 47419 - PLUG, HOLE(FOR FRONT BRAKE) | ||||
| 47419-35011 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
4 | ||
| 47447 - PIN, SHOE HOLD DOWN SPRING(FOR FRONT BRAKE) | ||||
| 47447-60010 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
4 | ||
| 47449 - CUP, SHOE HOLD DOWN SPRING(FOR FRONT BRAKE) | ||||
| 47449-30020 |
FJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN |
8 | ||
| 47449 - CUP, SHOE HOLD DOWN SPRING(FOR FRONT BRAKE) | ||||
| 47449-30020 |
FJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN |
8 | ||
| 47491 - PLUG, HOLE(FOR FRONT BRAKE) | ||||
| 47491-36010 |
FJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN |
4 | ||
| 47510 - CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR FRONT OR UPPER | ||||
| 47520-36090 |
FJ75,HZJ75,PZJ75..GEN |
1 | ||
| 47510C - SPRING, COMPRESSION(FOR FRONT WHEEL BRAKE CYLINDER) | ||||
| 90501-08122 |
FJ75,HZJ75,PZJ75..GEN |
4 | ||
| 47510C - SPRING, COMPRESSION(FOR FRONT WHEEL BRAKE CYLINDER) | ||||
| 90501-08122 |
FJ75,HZJ75,PZJ75..GEN |
4 | ||
| 47520 - CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR REAR OR LOWER) | ||||
| 47510-36090 |
FJ75,HZJ75,PZJ75..GEN |
1 | ||
| 47530 - CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR FRONT OR UPPER | ||||
| 47540-36090 |
FJ75,HZJ75,PZJ75..GEN |
1 | ||
| 47533 - SEAT, WHEEL CYLINDER PISTON SPRING(FOR FRONT BRAKE) | ||||
| 47533-30011 |
FJ75,HZJ75,PZJ75..GEN |
4 | ||
| 47533 - SEAT, WHEEL CYLINDER PISTON SPRING(FOR FRONT BRAKE) | ||||
| 47533-30011 |
FJ75,HZJ75,PZJ75..GEN |
4 | ||
| 47540 - CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR REAR OR LOWER) | ||||
| 47530-36090 |
FJ75,HZJ75,PZJ75..GEN |
1 | ||
| 47547 - PLUG, BLEEDER(FOR FRONT DRUM BRAKE) | ||||
| 47547-12010 |
FJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN |
2 | ||
| 47548 - CAP, BLEEDER PLUG(FOR DRUM BRAKE, FRONT) | ||||
| 31478-30010 |
FJ7#,HZJ75,LJ72,PZJ7#,RJ70..STD..GEN |
2 | ||
| 47551 - NUT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE | ||||
| 47551-36120 |
FJ75,HZJ75,PZJ75..GEN |
2 | ||
| 47551 - NUT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE | ||||
| 47551-36120 |
FJ75,HZJ75,PZJ75..GEN |
2 | ||
| 47552 - NUT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE | ||||
| 47552-36120 |
FJ75,HZJ75,PZJ75..GEN |
2 | ||
| 47552 - NUT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE | ||||
| 47552-36120 |
FJ75,HZJ75,PZJ75..GEN |
2 | ||
| 47553 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAK | ||||
| 47553-36050 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| 47553 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAK | ||||
| 47553-36050 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| 47554 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAK | ||||
| 47554-36050 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| 47554 - BOLT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAK | ||||
| 47554-36050 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| 47555 - SPRING, ADJUSTER LOCK(FOR FRONT BRAKE) | ||||
| 47555-36040 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
4 | ||
| 47555 - SPRING, ADJUSTER LOCK(FOR FRONT BRAKE) | ||||
| 47555-36040 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
4 | ||
| 47651 - LINING, FRONT BRAKE SHOE(FOR FRONT OR UPPER) | ||||
| 47651-60020 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| 47652 - LINING, FRONT BRAKE SHOE(FOR REAR OR LOWER) | ||||
| 47651-60020 |
FJ7#,HZJ75,PZJ7#..STD..GEN |
2 | ||
| Common parts | ||||
| 90101-08043 | ||||
| 90159-50146 | ||||
| 94512-00800 | ||||
| 94512-01000 | ||||
