FZJ73L-MRU (1992)
Toyota Land Cruiser
(9201- )1FZ#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 13506 - CHAIN SUB-ASSY | ||||
| 13506-66010 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13511 - CAMSHAFT | ||||
| 13501-66020 |
1FZ#..FZJ7# |
1 | ||
| 13512 - CAMSHAFT, NO.2 | ||||
| 13502-66010 |
1FZ#..FZJ7# |
1 | ||
| 13515 - GEAR, DISTRIBUTOR DRIVE | ||||
| 13515-75010 |
1FZ#..FZJ7# |
1 | ||
| 13516 - JET, OIL | ||||
| 13516-66010 |
1FZ#..FZJ7# |
1 | ||
| 13516-66010 |
1FZ#..FZJ7# |
1 | ||
| 13523 - GEAR OR SPROCKET, CAMSHAFT TIMING | ||||
| 13523-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13529 - GEAR, CAMSHAFT SUB | ||||
| 13529-62901 |
1FZF..FZJ73;1FZFE..FZJ75;1FZF..FZJ75..LHD..IV;1FZF..FZJ70,75..(HT,PIC)..CBU |
1 | ||
| 13529-62900 |
1FZ#..FZJ7# |
1 | ||
| 13529A - WASHER, WAVE(FOR CAMSHAFT SUB GEAR) | ||||
| 90206-42001 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13529B - RING, SHAFT SNAP(FOR CAMSHAFT SUB GEAR) | ||||
| 90520-47002 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13529E - RING, SHAFT SNAP(FOR CAMSHAFT SUB GEAR, NO.3) | ||||
| 90520-41004 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13540 - TENSIONER ASSY, CHAIN, NO.1 | ||||
| 13540-66010 |
1FZ#..FZJ7# |
1 | ||
| 13540-66010 |
1FZ#..FZJ7# |
1 | ||
| 13540C - GASKET(FOR CHAIN TENSIONER) | ||||
| 13552-66010 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13559 - SLIPPER, CHAIN TENSIONER | ||||
| 13559-66010 |
1FZ#..FZJ7# |
1 | ||
| 13559-66010 |
1FZ#..FZJ7# |
1 | ||
| 13561 - DAMPER, CHAIN VIBRATION, NO.1 | ||||
| 13561-66010 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13579 - WASHER, CAMSHAFT TIMING GEAR BOLT | ||||
| 13579-50020 |
1FZF..FZJ7# TOGO |
1 | ||
| 13579-62010 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
1 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ71,74,78,79..GCC,GEN |
12 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02096 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 INTAKE SIDE |
12 | ||
| 90913-02097 |
1FZ#..FZJ7# EXHAUST SIDE |
12 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02096 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 INTAKE SIDE |
12 | ||
| 90913-02097 |
1FZ#..FZJ7# EXHAUST SIDE |
12 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90501-38006 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90501-38006 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ71,74,78,79..GCC,GEN |
12 | ||
| 13734 - SEAT, VALVE SPRING | ||||
| 13734-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13734 - SEAT, VALVE SPRING | ||||
| 13734-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03027 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
48 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03027 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
48 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13753 - SHIM, VALVE ADJUSTING | ||||
| 13753-66080 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.65 |
1 | ||
| 13753-66040 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.55 |
1 | ||
| 13753-66060 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.60 |
1 | ||
| 13753-66120 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.75 |
1 | ||
| 13753-66160 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.85 |
1 | ||
| 13753-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.50 |
1 | ||
| 13753-66200 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.95 |
1 | ||
| 13753-66240 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.05 |
1 | ||
| 13753-66100 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.70 |
1 | ||
| 13753-66140 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.80 |
1 | ||
| 13753-66180 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.90 |
1 | ||
| 13753-66220 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.00 |
1 | ||
| 13753-66260 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.10 |
1 | ||
| 13753-66300 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.20 |
1 | ||
| 13753-66280 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.15 |
1 | ||
| 13753-66340 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.30 |
1 | ||
| 13753-66320 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.25 |
1 | ||
| 13753 - SHIM, VALVE ADJUSTING | ||||
| 13753-66080 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.65 |
1 | ||
| 13753-66040 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.55 |
1 | ||
| 13753-66060 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.60 |
1 | ||
| 13753-66120 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.75 |
1 | ||
| 13753-66160 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.85 |
1 | ||
| 13753-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.50 |
1 | ||
| 13753-66200 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.95 |
1 | ||
| 13753-66240 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.05 |
1 | ||
| 13753-66100 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.70 |
1 | ||
| 13753-66140 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.80 |
1 | ||
| 13753-66180 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.90 |
1 | ||
| 13753-66220 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.00 |
1 | ||
| 13753-66260 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.10 |
1 | ||
| 13753-66300 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.20 |
1 | ||
| 13753-66280 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.15 |
1 | ||
| 13753-66340 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.30 |
1 | ||
| 13753-66320 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.25 |
1 | ||
| Common parts | ||||
| 90109-12057 | ||||
| 90119-12328 | ||||
| 90179-08040 | ||||
| 90250-05027 | ||||
| 90250-05030 | ||||
| 90910-02093 | ||||
| 91511-B0816 | ||||
| 92122-60818 | ||||
(9001-9305)2LT ; (9004-9604)3L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 13511 - CAMSHAFT | ||||
| 13501-66020 |
1FZ#..FZJ7# |
1 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ71,74,78,79..GCC,GEN |
12 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02096 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 INTAKE SIDE |
12 | ||
| 90913-02097 |
1FZ#..FZJ7# EXHAUST SIDE |
12 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90501-38006 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ71,74,78,79..GCC,GEN |
12 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03027 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
48 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 |
24 | ||
| 13753 - SHIM, VALVE ADJUSTING | ||||
| 13753-66080 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.65 |
1 | ||
| 13753-66040 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.55 |
1 | ||
| 13753-66060 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.60 |
1 | ||
| 13753-66120 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.75 |
1 | ||
| 13753-66160 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.85 |
1 | ||
| 13753-66020 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.50 |
1 | ||
| 13753-66200 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.95 |
1 | ||
| 13753-66240 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.05 |
1 | ||
| 13753-66100 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.70 |
1 | ||
| 13753-66140 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.80 |
1 | ||
| 13753-66180 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=2.90 |
1 | ||
| 13753-66220 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.00 |
1 | ||
| 13753-66260 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.10 |
1 | ||
| 13753-66300 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.20 |
1 | ||
| 13753-66280 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.15 |
1 | ||
| 13753-66340 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.30 |
1 | ||
| 13753-66320 |
1FZF..FZJ70,73,75;1FZFE..FZJ70,75..ARL;1FZFE..FZJ71,74,78,79 T=3.25 |
1 | ||
| Common parts | ||||
| 90099-05166 | ||||
| 90105-08169 | ||||
| 90105-10235 | ||||
| 90109-08171 | ||||
| 90109-08172 | ||||
| 90119-14005 | ||||
| 90560-12041 | ||||
| Linked diagrams | ||||
| 1708 | ||||
