YN85L-TRMRS3 (1990)
Toyota Hilux 2wd
(8808-9108)5F ; (9108-0106)5F
G#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33211 - FORK, REVERSE SHIFT | ||||
| 33211-28010 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33211-28010 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33211-28010 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33212C - FORK, GEAR SHIFT, NO.1 | ||||
| 33212-35023 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33212-35023 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33212-35023 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
YN80..4F;YN85..4F..TH;RN85,90,YN85..MTM..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
3 | ||
| 90254-05001 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
2 | ||
| 90254-05001 |
YN80,85;LN8#,90,RN125,8#,90,YN81,86,87,92..5F |
3 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
YN80..4F;YN85..4F..TH;RN85,90,YN85..MTM..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
3 | ||
| 90254-05001 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
2 | ||
| 90254-05001 |
YN80,85;LN8#,90,RN125,8#,90,YN81,86,87,92..5F |
3 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
YN80..4F;YN85..4F..TH;RN85,90,YN85..MTM..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
3 | ||
| 90254-05001 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
2 | ||
| 90254-05001 |
YN80,85;LN8#,90,RN125,8#,90,YN81,86,87,92..5F |
3 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-06052 |
YN85..5F;LN8#,90,RN8#,90,YN81,86,87,92..MTM |
2 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-06052 |
YN85..5F;LN8#,90,RN8#,90,YN81,86,87,92..MTM |
2 | ||
| 33213G - FORK, GEAR SHIFT, NO.2 | ||||
| 33213-35032 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33213-35033 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33213-35033 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33213-35032 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33214G - FORK, GEAR SHIFT, NO.3 | ||||
| 33214-35020 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 33214-35020 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33221 - ARM, REVERSE SHIFT | ||||
| 33221-28010 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33221-28010 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33221-28010 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33221B - RING, E(FOR REVERSE SHIFT ARM) | ||||
| 96160-01000 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 96160-01000 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 96160-01000 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33225 - SHOE, SHIFT ARM | ||||
| 33225-35030 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33225-35030 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33225-35030 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33225B - RING, E(FOR SHIFT ARM SHOE) | ||||
| 96160-00800 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 96160-00800 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 96160-00800 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33228 - BRACKET, REVERSE SHIFT ARM | ||||
| 33228-28010 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33228-28010 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33228-28010 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33228B - PIN, RING(FOR REVERSE SHIFT ARM BRACKET) | ||||
| 90253-11001 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
2 | ||
| 90253-11001 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
2 | ||
| 90253-11001 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
2 | ||
| 33231 - HEAD, REVERSE SHIFT | ||||
| 33231-35040 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 33231-35040 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33231B - BALL, REVERSE SHIFT RESTRICT | ||||
| 90360-10003 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33231C - RING(FOR REVERSE SHIFT HEAD) | ||||
| 90520-12006 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 90520-12003 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 90520-12006 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33241 - SHAFT, REVERSE SHIFT FORK | ||||
| 33244-35021 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 33244-35021 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33242 - SHAFT, GEAR SHIFT FORK, NO.1 | ||||
| 33242-35022 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33242-35022 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33242-35022 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33243A - SHAFT, GEAR SHIFT FORK, NO.2 | ||||
| 33243-35042 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33243-35042 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33243-35042 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33244B - RING, SHAFT SNAP (FOR SHIFT FORK SHAFT) | ||||
| 90520-12006 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
2 | ||
| 90520-12006 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
2 | ||
| 90520-12006 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
2 | ||
| 90520-12003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
2 | ||
| 33244B - RING, SHAFT SNAP (FOR SHIFT FORK SHAFT) | ||||
| 90520-12006 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
2 | ||
| 90520-12006 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
2 | ||
| 90520-12006 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
2 | ||
| 90520-12003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
2 | ||
| 33245G - SHAFT, GEAR SHIFT FORK, NO.4 | ||||
| 33245-35040 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33245-35040 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 33246C - SHAFT, GEAR SHIFT FORK, NO.5 | ||||
| 33246-35020 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33246-35020 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33246-35020 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33251 - LEVER, SHIFT & SELECT | ||||
| 33251-35060 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33251-35060 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33251-35060 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F OD=9.52,STEEL,BALL |
1 | ||
| 90361-10002 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM L=21.6,PIN |
1 | ||
| 90361-10002 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=21.6,PIN |
1 | ||
| 90361-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM L=13.6,OD=9.5 |
1 | ||
| 90361-10003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=13.6,OD=9.5 |
1 | ||
| 90360-10003 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F OD=9.52,STEEL,BALL |
1 | ||
| 90361-10002 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) L=21.6,PIN |
1 | ||
| 90361-10003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) L=13.6,OD=9.5 |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F OD=9.52,STEEL,BALL |
1 | ||
| 90361-10002 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM L=21.6,PIN |
1 | ||
| 90361-10002 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=21.6,PIN |
1 | ||
| 90361-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM L=13.6,OD=9.5 |
1 | ||
| 90361-10003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=13.6,OD=9.5 |
1 | ||
| 90360-10003 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F OD=9.52,STEEL,BALL |
1 | ||
| 90361-10002 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) L=21.6,PIN |
1 | ||
| 90361-10003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) L=13.6,OD=9.5 |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F OD=9.52,STEEL,BALL |
1 | ||
| 90361-10002 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM L=21.6,PIN |
1 | ||
| 90361-10002 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=21.6,PIN |
1 | ||
| 90361-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM L=13.6,OD=9.5 |
1 | ||
| 90361-10003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=13.6,OD=9.5 |
1 | ||
| 90360-10003 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F OD=9.52,STEEL,BALL |
1 | ||
| 90361-10002 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) L=21.6,PIN |
1 | ||
| 90361-10003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) L=13.6,OD=9.5 |
1 | ||
| 33265 - PIN, SHIFT INTER LOCK, NO.2 | ||||
| 90250-05020 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=11.1,OD=4.8 |
2 | ||
| 90250-05020 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F L=11.1,OD=4.8 |
2 | ||
| 33265 - PIN, SHIFT INTER LOCK, NO.2 | ||||
| 90250-05020 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=11.1,OD=4.8 |
2 | ||
| 90250-05020 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F L=11.1,OD=4.8 |
2 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12008 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM OD=18 |
4 | ||
| 90341-12008 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) OD=18 |
4 | ||
| 90341-12008 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM OD=18 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12008 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM OD=18 |
4 | ||
| 90341-12008 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) OD=18 |
4 | ||
| 90341-12008 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM OD=18 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12008 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM OD=18 |
4 | ||
| 90341-12008 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) OD=18 |
4 | ||
| 90341-12008 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM OD=18 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12008 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM OD=18 |
4 | ||
| 90341-12008 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) OD=18 |
4 | ||
| 90341-12008 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM OD=18 |
4 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=30.6,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14123 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=20.2,SHIFT HEAD SIDE |
1 | ||
| 90501-14132 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14132 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14061 |
LN8#,90,RN8#,90,YN85,86,87,92..5F L=18.3,SHIFT HEAD SIDE |
1 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=30.6,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14123 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=20.2,SHIFT HEAD SIDE |
1 | ||
| 90501-14132 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14132 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14061 |
LN8#,90,RN8#,90,YN85,86,87,92..5F L=18.3,SHIFT HEAD SIDE |
1 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=30.6,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14123 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=20.2,SHIFT HEAD SIDE |
1 | ||
| 90501-14132 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14132 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14061 |
LN8#,90,RN8#,90,YN85,86,87,92..5F L=18.3,SHIFT HEAD SIDE |
1 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM L=30.6,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14123 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=20.2,SHIFT HEAD SIDE |
1 | ||
| 90501-14132 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14132 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F L=31,SHIFTFORK SHAFT SIDE |
3 | ||
| 90501-14061 |
LN8#,90,RN8#,90,YN85,86,87,92..5F L=18.3,SHIFT HEAD SIDE |
1 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
4 | ||
| 90360-10003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
4 | ||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
4 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
4 | ||
| 90360-10003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
4 | ||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
4 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
4 | ||
| 90360-10003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
4 | ||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
4 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
4 | ||
| 90360-10003 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
4 | ||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
4 | ||
| 33276 - SEAT, SHIFT DETENT BALL SPRING, NO.2 | ||||
| 90341-12008 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 90341-12008 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 90341-12008 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33276A - SPRING, COMPRESSION, NO.2 (FOR SHIFT DETENT BALL) | ||||
| 90501-10061 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 90501-10061 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 90501-10061 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33276B - BALL, SHIFT DETENT, NO.2 | ||||
| 90360-10003 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 90360-10003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33280 - PIN ASSY, REVERSE RESTRICT | ||||
| 33280-35020 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM RH |
1 | ||
| 33280-35030 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM LH |
1 | ||
| 33280-35030 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..MTM LH |
1 | ||
| 33280-35020 |
YN80..4F;YN85..4F..TH;RN85,90,YN85..MTM..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM RH |
1 | ||
| 33280-35030 |
YN80..4F;YN85..4F..TH;RN85,90,YN85..MTM..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM LH |
1 | ||
| 33280-35031 |
LN8#,90,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) LH |
1 | ||
| 33280-35021 |
LN8#,90,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) RH |
1 | ||
| 33280-35020 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..MTM RH |
1 | ||
| 33280 - PIN ASSY, REVERSE RESTRICT | ||||
| 33280-35020 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM RH |
1 | ||
| 33280-35030 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM LH |
1 | ||
| 33280-35030 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..MTM LH |
1 | ||
| 33280-35020 |
YN80..4F;YN85..4F..TH;RN85,90,YN85..MTM..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM RH |
1 | ||
| 33280-35030 |
YN80..4F;YN85..4F..TH;RN85,90,YN85..MTM..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM LH |
1 | ||
| 33280-35031 |
LN8#,90,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) LH |
1 | ||
| 33280-35021 |
LN8#,90,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) RH |
1 | ||
| 33280-35020 |
RN85,90..5F..(ARL,GEN);LN8#,90,RN125,YN8#,9#..MTM RH |
1 | ||
| 33283F - PIN, REVERSE RESTRICT | ||||
| 33280-35040 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33280-35040 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 33283G - PIN, SLOTTED SPRING (FOR REVERSE RESTRICT PIN) | ||||
| 90254-05001 |
LN8#,90,RN125,8#,90,YN81,85,86,87,92..5F |
1 | ||
| 90254-05001 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..5F |
1 | ||
| 33521 - HOUSING, SHIFT LEVER | ||||
| 33521-35070 |
YN85..5F;LN8#,90,RN125,8#,90,YN81,86,87,92..MTM |
1 | ||
| 33521-35070 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 33521-35070 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 33521F - PIN OR BOLT (FOR SHIFT LEVER HOUSING) | ||||
| 90113-08001 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| 90113-08001 |
LN8#,90,RN125,8#,90,YN85,86,87,92..5F |
1 | ||
| 90113-08001 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 90113-08001 |
LN8#,90,YN8#,9#..MTM;RN85,90..5F..(ARL,GEN) |
1 | ||
| 33521P - WASHER, LOCK (FOR SHIFT LEVER HOUSING) | ||||
| 90215-09003 |
LN8#,90,YN8#,9#..MTM;RN85,90..5F..(ARL,GEN) |
1 | ||
| 90215-09003 |
LN8#,90,RN125,YN81,86,9#..MTM;RN85,90,YN80,85..5F..(ARL,GEN,TH) |
1 | ||
| 90215-09003 |
LN8#,90,RN125,8#,90,YN85,86,87,92..5F |
1 | ||
| 90215-09003 |
RN85,90,YN85..5F..(ARL,GEN);LN8#,90,RN125,YN81,86,92..MTM |
1 | ||
| Common parts | ||||
| 91611-60850 | ||||
| Linked diagrams | ||||
| 3312 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
