KUN26L-PRMSYG (2005)
Toyota Hilux
(0501- )TGN1#,26,36..DLX,SR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04446 - GASKET KIT, POWER STEERING PUMP | ||||
| 04446-0B040 |
KUN15..DCB;KUN10,16,2#,3#;KUN15..XTR..SR;KUN15..SCB..(GCC,GEN,SA) |
1 | ||
| 04446-06060 |
GGN15,25,TGN1#,26,36 |
1 | ||
| 44305 - CAP SUB-ASSY, VANE PUMP OIL RESERVOIR | ||||
| 44305-0K020 |
KUN15..XTR..SR;KUN35..GEN,LA,SA;KUN15..SCB..(GCC,GEN,SA);GGN15,25,KUN10,16,2#,36,LAN15,25,35;KUN15,35..DCB..(ANCOM,GCC,GEN,PHL,TH) |
1 | ||
| 44305-22040 |
TGN1#,26,36 |
1 | ||
| 44308 - UNION SUB-ASSY, PRESSURE PORT | ||||
| 44308-0K050 |
KUN25..SCB..MA;KUN35..DCB..ANCOM;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN35..DLX..(GEN,LA,SA);KUN36..(DCB,SCB,XTR)..5F;KUN25..ANCOM,GCC,GEN,LA,SA;KUN26..(DCB,SCB,THDCB,XTR)..(ARL,GEN,LA,PHL,TH) |
1 | ||
| 44308-0K050 |
KUN2#,3#..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH |
1 | ||
| 44313 - ROTOR, VANE PUMP | ||||
| 44313-09010 |
KUN16..4FC;TGN16..XTR;KUN15..DCB,SMT;KUN16..SCB,SMT,XTR;TGN16..ARL,GCC,SA,TH;KUN15..SCB..(GCC,GEN,PHL,SA);KUN16,TGN10,15..(DCB,SCB)..(ARL,GCC,GEN,IDN,SA)..CBU;KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH |
1 | ||
| 44313-09010 |
KUN15..DCB;KUN26..THDCB;KUN25..SCB..MA;KUN35..DCB..ANCOM;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;KUN35..DLX..(GEN,LA,SA);KUN15..SCB..(GCC,GEN,PKN,SA);KUN15,16,36,TGN16..XTR..SR..TH;KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN10,16,TGN10,11,15..(DCB,SCB)..(DLX,SR);KUN25,TGN16..5F..(ANCOM,ARL,GCC,GEN,LA,SA) |
1 | ||
| 44320 - PUMP ASSY, VANE | ||||
| 44310-0K040 |
KUN25..SCB..MA;KUN35..DCB..ANCOM;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN35..DLX..(GEN,LA,SA);KUN36..(DCB,SCB,XTR)..5F;KUN25..ANCOM,GCC,GEN,LA,SA;KUN26..(DCB,SCB,THDCB,XTR)..(ARL,GEN,LA,PHL,TH) |
1 | ||
| 44310-0K040 |
KUN2#,3#..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH |
1 | ||
| 44330 - VALVE ASSY, FLOW CONTROL | ||||
| 44330-0K150 |
KUN15..DCB;KUN26..THDCB;KUN25..SCB..MA;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;TGN16..5F..(ARL,GCC,GEN,SA);KUN15..SCB..(GCC,GEN,PKN,SA);KUN15,16,36,TGN16..XTR..SR..TH;KUN25,35..DLX..(ANCOM,GCC,GEN,LA,SA);KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN10,16,TGN10,11,15..(DCB,SCB)..(DLX,SR) MARK C |
1 | ||
| 44330-0K130 |
KUN15..DCB;KUN26..THDCB;KUN25..SCB..MA;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;TGN16..5F..(ARL,GCC,GEN,SA);KUN15..SCB..(GCC,GEN,PKN,SA);KUN15,16,36,TGN16..XTR..SR..TH;KUN25,35..DLX..(ANCOM,GCC,GEN,LA,SA);KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN10,16,TGN10,11,15..(DCB,SCB)..(DLX,SR) MARK A |
1 | ||
| 44330-0K140 |
KUN15..DCB;KUN26..THDCB;KUN25..SCB..MA;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;TGN16..5F..(ARL,GCC,GEN,SA);KUN15..SCB..(GCC,GEN,PKN,SA);KUN15,16,36,TGN16..XTR..SR..TH;KUN25,35..DLX..(ANCOM,GCC,GEN,LA,SA);KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN10,16,TGN10,11,15..(DCB,SCB)..(DLX,SR) MARK B |
1 | ||
| 44330-0K160 |
KUN15..DCB;KUN26..THDCB;KUN25..SCB..MA;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;TGN16..5F..(ARL,GCC,GEN,SA);KUN15..SCB..(GCC,GEN,PKN,SA);KUN15,16,36,TGN16..XTR..SR..TH;KUN25,35..DLX..(ANCOM,GCC,GEN,LA,SA);KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN10,16,TGN10,11,15..(DCB,SCB)..(DLX,SR) MARK D |
1 | ||
| 44330-0K180 |
KUN15..DCB;KUN26..THDCB;KUN25..SCB..MA;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;TGN16..5F..(ARL,GCC,GEN,SA);KUN15..SCB..(GCC,GEN,PKN,SA);KUN15,16,36,TGN16..XTR..SR..TH;KUN25,35..DLX..(ANCOM,GCC,GEN,LA,SA);KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN10,16,TGN10,11,15..(DCB,SCB)..(DLX,SR) MARK F |
1 | ||
| 44330-0K170 |
KUN15..DCB;KUN26..THDCB;KUN25..SCB..MA;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;TGN16..5F..(ARL,GCC,GEN,SA);KUN15..SCB..(GCC,GEN,PKN,SA);KUN15,16,36,TGN16..XTR..SR..TH;KUN25,35..DLX..(ANCOM,GCC,GEN,LA,SA);KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN10,16,TGN10,11,15..(DCB,SCB)..(DLX,SR) MARK E |
1 | ||
| 44330-0K180 |
KUN16..4FC;TGN16..XTR;KUN15..DCB,SMT;KUN16..SCB,SMT,XTR;TGN16..ARL,GCC,SA,TH;KUN15..SCB..(GCC,GEN,PHL,SA);KUN16,TGN10,15..(DCB,SCB)..(ARL,GCC,GEN,IDN,SA)..CBU;KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH MARK F |
1 | ||
| 44330-0K150 |
KUN16..4FC;TGN16..XTR;KUN15..DCB,SMT;KUN16..SCB,SMT,XTR;TGN16..ARL,GCC,SA,TH;KUN15..SCB..(GCC,GEN,PHL,SA);KUN16,TGN10,15..(DCB,SCB)..(ARL,GCC,GEN,IDN,SA)..CBU;KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH MARK C |
1 | ||
| 44330-0K170 |
KUN16..4FC;TGN16..XTR;KUN15..DCB,SMT;KUN16..SCB,SMT,XTR;TGN16..ARL,GCC,SA,TH;KUN15..SCB..(GCC,GEN,PHL,SA);KUN16,TGN10,15..(DCB,SCB)..(ARL,GCC,GEN,IDN,SA)..CBU;KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH MARK E |
1 | ||
| 44330-0K140 |
KUN16..4FC;TGN16..XTR;KUN15..DCB,SMT;KUN16..SCB,SMT,XTR;TGN16..ARL,GCC,SA,TH;KUN15..SCB..(GCC,GEN,PHL,SA);KUN16,TGN10,15..(DCB,SCB)..(ARL,GCC,GEN,IDN,SA)..CBU;KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH MARK B |
1 | ||
| 44330-0K160 |
KUN16..4FC;TGN16..XTR;KUN15..DCB,SMT;KUN16..SCB,SMT,XTR;TGN16..ARL,GCC,SA,TH;KUN15..SCB..(GCC,GEN,PHL,SA);KUN16,TGN10,15..(DCB,SCB)..(ARL,GCC,GEN,IDN,SA)..CBU;KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH MARK D |
1 | ||
| 44330-0K130 |
KUN16..4FC;TGN16..XTR;KUN15..DCB,SMT;KUN16..SCB,SMT,XTR;TGN16..ARL,GCC,SA,TH;KUN15..SCB..(GCC,GEN,PHL,SA);KUN16,TGN10,15..(DCB,SCB)..(ARL,GCC,GEN,IDN,SA)..CBU;KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH MARK A |
1 | ||
| 44330A - SPRING, COMPRESSION(FOR FLOW CONTROL VALVE) | ||||
| 90501-T0001 |
KUN26..THDCB;KUN25..SCB..MA;KUN16..DCB,SCB;KUN35..DCB..ANCOM;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;KUN35..DLX..(GEN,LA,SA);KUN25..ANCOM,GCC,GEN,LA,SA;TGN26..ANCOM,GCC,GEN,SA,TH;TGN26,36..DCB..5F..DLX..LA;KUN15,16,36,TGN16..XTR..SR..TH;KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN15,TGN36..SCB..(ANCOM,GCC,GEN,LA,PKN,SA);KUN15,TGN36..DCB..(ANCOM,GCC,GEN,PHL,SA,TH);GGN15,25,KUN10,TGN1#..(5F,5FC)..(DLX,SR)..(ANCOM,ARL,GCC,GEN,IDN,SA) |
1 | ||
| 90501-T0001 |
TGN16..XTR;KUN15..DCB,SMT;GGN25..5FC..SA;GGN15..DCB..DLX;TGN26..ANCOM..CBU;TGN36..ANCOM..IV3;TGN16..ARL,GCC,SA,TH;GGN15,KUN16..SCB,SMT,XTR;GGN25..DCB..(ANCOM,ARL,LA);TGN26..LHD..(GCC,GEN,LA,SA);KUN15..SCB..(GCC,GEN,PHL,SA);GGN15,KUN16..DCB..(4FC,5FC)..SR;GGN35,KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH;KUN16,TGN10,15,36..(DCB,SCB)..(ANCOM,ARL,GCC,GEN,IDN,LA,SA)..CBU |
1 | ||
| 44341 - PLATE, VANE PUMP SIDE, FRONT | ||||
| 44341-06010 |
KUN26..THDCB;KUN25..SCB..MA;KUN16..DCB,SCB;KUN35..DCB..ANCOM;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;KUN35..DLX..(GEN,LA,SA);KUN25..ANCOM,GCC,GEN,LA,SA;TGN26..ANCOM,GCC,GEN,SA,TH;TGN26,36..DCB..5F..DLX..LA;KUN15,16,36,TGN16..XTR..SR..TH;KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN15,TGN36..SCB..(ANCOM,GCC,GEN,LA,PKN,SA);KUN15,TGN36..DCB..(ANCOM,GCC,GEN,PHL,SA,TH);GGN15,25,KUN10,TGN1#..(5F,5FC)..(DLX,SR)..(ANCOM,ARL,GCC,GEN,IDN,SA) |
1 | ||
| 44341-06010 |
TGN16..XTR;KUN15..DCB,SMT;GGN25..5FC..SA;GGN15..DCB..DLX;TGN26..ANCOM..CBU;TGN36..ANCOM..IV3;TGN16..ARL,GCC,SA,TH;GGN15,KUN16..SCB,SMT,XTR;GGN25..DCB..(ANCOM,ARL,LA);TGN26..LHD..(GCC,GEN,LA,SA);KUN15..SCB..(GCC,GEN,PHL,SA);GGN15,KUN16..DCB..(4FC,5FC)..SR;GGN35,KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH;KUN16,TGN10,15,36..(DCB,SCB)..(ANCOM,ARL,GCC,GEN,IDN,LA,SA)..CBU |
1 | ||
| 44362A - RING, O(FOR VANE PUMP OIL RESERVOIR) | ||||
| 90080-30093 |
KUN26..THDCB;KUN25..SCB..MA;KUN16..DCB,SCB;KUN35..DCB..ANCOM;KUN26..DCB..5F..SA;KUN25..(DCB,XTR)..SR;KUN36..(DCB,SCB)..5F;KUN35..DLX..(GEN,LA,SA);KUN25..ANCOM,GCC,GEN,LA,SA;TGN26..ANCOM,GCC,GEN,SA,TH;TGN26,36..DCB..5F..DLX..LA;KUN15,16,36,TGN16..XTR..SR..TH;KUN26..(DCB,SCB,XTR)..(ARL,LA,PHL,TH);KUN15,TGN36..SCB..(ANCOM,GCC,GEN,LA,PKN,SA);KUN15,TGN36..DCB..(ANCOM,GCC,GEN,PHL,SA,TH);GGN15,25,KUN10,TGN1#..(5F,5FC)..(DLX,SR)..(ANCOM,ARL,GCC,GEN,IDN,SA) |
1 | ||
| 90080-30093 |
TGN16..XTR;KUN15..DCB,SMT;GGN25..5FC..SA;GGN15..DCB..DLX;TGN26..ANCOM..CBU;TGN36..ANCOM..IV3;TGN16..ARL,GCC,SA,TH;GGN15,KUN16..SCB,SMT,XTR;GGN25..DCB..(ANCOM,ARL,LA);TGN26..LHD..(GCC,GEN,LA,SA);KUN15..SCB..(GCC,GEN,PHL,SA);GGN15,KUN16..DCB..(4FC,5FC)..SR;GGN35,KUN10,2#,3#,TGN11..ANCOM,ARL,GCC,GEN,LA,MA,PHL,PKN,SA,TH;KUN16,TGN10,15,36..(DCB,SCB)..(ANCOM,ARL,GCC,GEN,IDN,LA,SA)..CBU |
1 | ||
| Common parts | ||||
| 90080-10265 | ||||
| 90080-11552 | ||||
| 90119-T0196 | ||||
| Linked diagrams | ||||
| 8404 | ||||
