KUN25R-TRMDHP (2014)
Toyota Hilux
(0408- )KUN2# ; (0501- )TGN26..4FC ; (0502- )GGN25..5FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08336 | ||||
(1107- )KUN2# ; (1107- )GGN25,TGN26..4FC,5FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33556M - SEAT, TRANSFER SHIFT LEVER BALL | ||||
| 33556-14020 |
KUN25..PKN NO.2 |
1 | ||
| 33556-14010 |
KUN25..PKN NO.1 |
1 | ||
| 33556M - SEAT, TRANSFER SHIFT LEVER BALL | ||||
| 33556-14020 |
KUN25..PKN NO.2 |
1 | ||
| 33556-14010 |
KUN25..PKN NO.1 |
1 | ||
| 36264 - PIN OR ROLLER, SHIFT INTER-LOCK | ||||
| 90250-10020 |
KUN25..PKN L=25.7,OD=9.53,TYPE A:REFER 36-08 |
1 | ||
| 36275 - PLUG, SHIFT DETENT BALL SPRING | ||||
| 90341-12014 |
KUN25..PKN TYPE A:REFER 36-08 |
2 | ||
| 36275 - PLUG, SHIFT DETENT BALL SPRING | ||||
| 90341-12014 |
KUN25..PKN TYPE A:REFER 36-08 |
2 | ||
| 36275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL) | ||||
| 90501-16116 |
KUN25..PKN L=23,TYPE A:REFER 36-08 |
2 | ||
| 36275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL) | ||||
| 90501-16116 |
KUN25..PKN L=23,TYPE A:REFER 36-08 |
2 | ||
| 36275B - BALL, SHIFT DETENT | ||||
| 90360-10003 |
KUN25..PKN OD=9.52,STEEL,TYPE A:REFER 36-08 |
2 | ||
| 36275B - BALL, SHIFT DETENT | ||||
| 90360-10003 |
KUN25..PKN OD=9.52,STEEL,TYPE A:REFER 36-08 |
2 | ||
| 36304 - RETAINER SUB-ASSY, TRANSFER CONTROL SHIFT LEVER | ||||
| 36304-35051 |
KUN25..5F..PKN;GGN25,KUN2#,TGN26..4FC,5FC |
1 | ||
| 36311B - PIN, SLOTTED SPRING (FOR TRANSFER SHIFT FORK) | ||||
| 90254-05001 |
KUN25..PKN L=22,TYPE A:REFER 36-08 |
4 | ||
| 36311B - PIN, SLOTTED SPRING (FOR TRANSFER SHIFT FORK) | ||||
| 90254-05001 |
KUN25..PKN L=22,TYPE A:REFER 36-08 |
4 | ||
| 36311B - PIN, SLOTTED SPRING (FOR TRANSFER SHIFT FORK) | ||||
| 90254-05001 |
KUN25..PKN L=22,TYPE A:REFER 36-08 |
4 | ||
| 36311B - PIN, SLOTTED SPRING (FOR TRANSFER SHIFT FORK) | ||||
| 90254-05001 |
KUN25..PKN L=22,TYPE A:REFER 36-08 |
4 | ||
| 36311C - SPRING, COMPRESION (FOR SHIFT FORK) | ||||
| 90501-20088 |
KUN25..PKN TYPE A:REFER 36-08 |
1 | ||
| 36311F - FORK, TRANSFER GEAR SHIFT, NO.1 | ||||
| 36311-35020 |
KUN25..SCB..MA;KUN26..4FC..DLX;LAN25..LHD..SCB;GGN25,KUN25..DLX..(ARL,CO,GCC,GEN,LA,PKN);KUN26,TGN26..5F..DLX..(HTWC,IART)..(GCC,GEN,LA) TYPE B:REFER 36-08 |
1 | ||
| 36311-35020 |
KUN25..SCB..MA;KUN26..4FC..DLX;LAN25..LHD..SCB;TGN26..5F..DLX..HTWC..(GCC,GEN,LA);GGN25,KUN2#..(4FC,5F)..DLX..(HDCR,HTWC,IART)..(ARL,CO,GCC,GEN,LA,PKN) TYPE A:REFER 36-08 |
1 | ||
| 36311G - RING, SHAFT SNAP (FOR TRANSFER GEAR SHIFT FORK) | ||||
| 90520-13002 |
KUN25..PKN TYPE A:REFER 36-08 |
1 | ||
| 36312F - FORK, TRANSFER GEAR SHIFT, NO.2 | ||||
| 36312-35040 |
KUN25..PKN TYPE B:REFER 36-08,TYPE A:REFER 36-08 |
1 | ||
| 36313F - SHAFT, TRANSFER FRONT DRIVE SHIFT FORK | ||||
| 36313-35080 |
TGN26..4FC;KUN2#..4FC,5F TYPE A:REFER 36-08 |
1 | ||
| 36314 - SHAFT, TRANSFER HIGH AND LOW SHIFT FORK | ||||
| 36314-35110 |
TGN26..4FC;KUN2#..4FC,5F TYPE A:REFER 36-08 |
1 | ||
| 36315D - HEAD, TRANSFER GEAR SHIFT, NO.1 | ||||
| 36315-35010 |
KUN25..PKN TYPE A:REFER 36-08 |
1 | ||
| 36316 - HEAD, TRANSFER GEAR SHIFT, NO.2 | ||||
| 36316-35020 |
KUN25..PKN TYPE A:REFER 36-08 |
1 | ||
| 36317C - STOPPER, TRANSFER SHIFT SHAFT | ||||
| 36317-35020 |
KUN25..PKN TYPE B:REFER 36-08,TYPE A:REFER 36-08 |
1 | ||
| 36317D - STOPPER, NO.2, TRANSFER SHIFT SHAFT | ||||
| 36317-35030 |
KUN25..PKN TYPE A:REFER 36-08 |
1 | ||
| 36318 - BOOT, TRANSFER FRONT DRIVE SHIFT | ||||
| 33555-35190 |
KUN25..PKN |
1 | ||
| 36321B - RING, HOLE SNAP (FOR TRANSFER FRONT DRIVE SHIFT LEVER) | ||||
| 90521-49003 |
KUN25..PKN |
1 | ||
| 36345 - GASKET, TRANSFER CONTROL SHIFT LEVER RETAINER | ||||
| 36345-35040 |
KUN25..PKN |
1 | ||
| 36349 - SPRING, TRANSFER SELECT RETURN | ||||
| 36349-35020 |
KUN2#;GGN25,TGN26..4FC,5FC |
1 | ||
| 36360G - LEVER ASSY, TRANSFER HIGH & LOW SHIFT | ||||
| 36360-71120 |
KUN2#..RHD..5F |
1 | ||
| Common parts | ||||
| 90119-08336 | ||||
| 90119-T0412 | ||||
