MX62L-XEPMEA (1980)

Toyota Cressida

Production Sep 1980 - Aug 1982
Engine 5ME
Transmission ATM
Displacement 2500cc
Power 168 HP (125 kW)

(8009- )

Click highlighted areas on diagram

diagram 11289 11291 11294 11298 17700D 17792
Part # Description Qty Price
11291 - PLATE, ENGINE NAME
11291-43020

5ME..MX62

 1
11294 - PLATE, ENGINE CAUTION, NO.2
11294-34020

5ME..MX62

 1
11298 - PLATE, EMISSION CONTROL INFORMATION
11298-43030

5ME..MX62..USA

CALIFORNIA SPEC

 1
11298-43090

5ME..MX62

 1
11298-43010

5ME..MX62

 1
11298-43070

5ME..MX62..USA

CALIFORNIA SPEC

 1
17700D - PLATE, ENGINE CAUTION
11293-28040

5M#..MX6#

 1
17792 - PLATE, ENGINE VACUUM HOSE INFORMATION
17792-43010

5ME..MX62

 1
