RT135LG-TWHDSA (1980)
Toyota Corona
(8008- )4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 35601B - RING, O (FOR FRONT CLUTCH DRUM) | ||||
| 90301-57188 |
RT13#..ATM |
1 | ||
| 35602 - PISTON SUB-ASSY, FRONT CLUTCH | ||||
| 35602-12031 |
RT135..4FC |
1 | ||
| 35602-12030 |
RT135..4FC |
1 | ||
| 35605 - DRUM SUB-ASSY, REAR CLUTCH W/2ND SUN GEAR | ||||
| 35605-22011 |
RT135..4FC |
1 | ||
| 35605-22010 |
RT13#..ATM |
1 | ||
| 35606 - PISTON SUB-ASSY, REAR CLUTCH | ||||
| 35606-22010 |
RT13#..ATM |
1 | ||
| 35606B - RING (FOR REAR CLUTCH PISTON INNER) | ||||
| 90301-57188 |
RT13#..ATM |
1 | ||
| 35610B - SPRING, COMPRESSION (FOR FRONT CLUTCH PISTON RETURN) | ||||
| 90501-10671 |
RT135..4FC |
18 | ||
| 35610C - RING, SHAFT SNAP (FOR FRONT CLUTCH PISTON RETURN SPRING | ||||
| 90520-39261 |
RT13#..ATM |
1 | ||
| 35610D - RING, HOLE SNAP (FOR FRONT MULTIPLE DISC CLUTCH) | ||||
| 90521-99139 |
RT13#..ATM |
1 | ||
| 35613 - RING, CLUTCH PISTON OIL SEAL, OUTER | ||||
| 90301-99192 |
RT13#..ATM ID=122 |
1 | ||
| 90301-99016 |
RT135..4FC ID=117 |
1 | ||
| 35615 - SEAT, CLUTCH PISTON RETURN SPRING | ||||
| 35615-30020 |
RT135..4FC |
1 | ||
| 35631 - HUB, CLUTCH(FOR MULTIPLE DISC CLUTCH) | ||||
| 35631-22010 |
RT13#..ATM |
1 | ||
| 35631B - BEARING, THRUST(FOR FRONT CLUTCH HUB) | ||||
| 90374-28014 |
RT13#..ATM |
1 | ||
| 35631C - RACE, THRUST BEARING(FOR FRONT CLUTCH HUB FRONT) | ||||
| 35789-22050 |
RT13#..ATM |
1 | ||
| 35631D - RACE, THRUST BEARING(FOR FRONT CLUTCH HUB REAR) | ||||
| 35789-22020 |
RT13#..ATM |
1 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-22020 |
RT13#..ATM NSK-WARNER |
3 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-22020 |
RT13#..ATM NSK-WARNER |
3 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-22020 |
RT13#..ATM NSK-WARNER |
3 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
RT13#..ATM T=1.8,NSK-WARNER |
4 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
RT13#..ATM T=1.8,NSK-WARNER |
4 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
RT13#..ATM T=1.8,NSK-WARNER |
4 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
RT13#..ATM T=1.8,NSK-WARNER |
4 | ||
| 35650A - RING, SHAFT SNAP (FOR REAR CLUTCH PISTON RETURN SPRING) | ||||
| 90520-39261 |
RT13#..ATM |
1 | ||
| 35650B - SPRING, COMPRESSION (FOR REAR CLUTCH PISTON RETURN) | ||||
| 90501-10671 |
RT135..4FC |
18 | ||
| 35650D - RING, HOLE SNAP (FOR REAR MULTIPLE DISC CLUTCH) | ||||
| 90521-99139 |
RT13#..ATM |
1 | ||
| 35652 - PISTON, REAR CLUTCH, NO.2 | ||||
| 35607-20021 |
RT135..4FC |
1 | ||
| 35607-20020 |
RT135..4FC |
1 | ||
| 35652A - RING (FOR REAR CLUTCH OUTER) | ||||
| 90301-99016 |
RT135..4FC |
1 | ||
| 90301-99192 |
RT13#..ATM |
1 | ||
| 35652B - RING (FOR REAR CLUTCH PISTON INNER) | ||||
| 90301-57188 |
RT13#..ATM |
1 | ||
| 35653 - RING, REAR CLUTCH OIL SEAL, OUTER | ||||
| 90301-84184 |
RT13#..ATM |
1 | ||
| 35654 - HUB, REAR CLUTCH | ||||
| 35654-22010 |
RT13#..ATM |
1 | ||
| 35654A - RING, HOLE SNAP (FOR REAR CLUTCH HUB) | ||||
| 90521-99146 |
RT13#..ATM |
1 | ||
| 35655 - SEAT, REAR CLUTCH PISTON RETURN SPRING | ||||
| 35615-30020 |
RT135..4FC |
1 | ||
| 35673 - DISC, REAR CLUTCH | ||||
| 35677-22020 |
RT13#..ATM NSK-WARNER |
3 | ||
| 35673 - DISC, REAR CLUTCH | ||||
| 35677-22020 |
RT13#..ATM NSK-WARNER |
3 | ||
| 35673 - DISC, REAR CLUTCH | ||||
| 35677-22020 |
RT13#..ATM NSK-WARNER |
3 | ||
| 35674 - PLATE, REAR CLUTCH | ||||
| 35634-22040 |
RT13#..ATM NSK-WARNER,T=1.8 |
3 | ||
| 35634-30070 |
RT135..4FC T=2.0 |
3 | ||
| 35674 - PLATE, REAR CLUTCH | ||||
| 35634-22040 |
RT13#..ATM NSK-WARNER,T=1.8 |
3 | ||
| 35634-30070 |
RT135..4FC T=2.0 |
3 | ||
| 35674 - PLATE, REAR CLUTCH | ||||
| 35634-22040 |
RT13#..ATM NSK-WARNER,T=1.8 |
3 | ||
| 35634-30070 |
RT135..4FC T=2.0 |
3 | ||
| 35675 - FLANGE, REAR CLUTCH | ||||
| 35675-30030 |
RT135..4FC T=3.6,T=3.4 |
1 | ||
| 35675-30020 |
RT135..4FC T=3.8,T=3.6 |
1 | ||
| 35701 - SHAFT SUB-ASSY, INPUT | ||||
| 35701-30020 |
RT135..4FC |
1 | ||
| 35701-22021 |
RT135..4FC |
1 | ||
| 35701-22020 |
RT135..4FC |
1 | ||
| 35701B - BEARING, THRUST NEEDLE ROLLER (FOR INPUT SHAFT REAR) | ||||
| 90374-23012 |
RT13#..ATM |
1 | ||
| 35701C - RACE, THRUST BEARING (FOR INPUT SHAFT REAR) | ||||
| 35789-22010 |
RT13#..ATM |
1 | ||
| 35706 - GEAR SUB-ASSY, PLANETARY SUN | ||||
| 35706-30030 |
RT135..4FC |
1 | ||
| 35706D - RACE, THRUST BEARING (FOR SUN GEAR FRONT) | ||||
| 35789-22030 |
RT13#..ATM |
1 | ||
| 35706E - RING, SHAFT SNAP (FOR SUN GEAR FRONT) | ||||
| 90520-34260 |
RT13#..ATM |
1 | ||
| 90520-34001 |
RT135..4FC |
1 | ||
| 35749 - RING, SUN GEAR SHAFT OIL SEAL | ||||
| 35749-22010 |
RT13#..ATM |
2 | ||
| 35749 - RING, SUN GEAR SHAFT OIL SEAL | ||||
| 35749-22010 |
RT13#..ATM |
2 | ||
