ZRE142L-DEPNKK (2010)
Toyota Corolla Nap
(0801- )NAP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45020 - BRACKET ASSY, STEERING COLUMN UPPER W/SWITCH | ||||
| 45020-02290 |
AZE141,ZRE142..NAP..ATM |
1 | ||
| 45020-02290 |
AZE141,ZRE142..NAP..ATM |
1 | ||
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45025-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45221 - SHAFT, STEERING INTERMEDIATE | ||||
| 45221-02070 |
AZE141,ZRE142..NAP |
1 | ||
| 45221-02070 |
AZE141,ZRE142..NAP |
1 | ||
| 45250 - COLUMN ASSY, STEERING | ||||
| 45250-02820 |
ZRE142..NAP |
1 | ||
| 45250-02840 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(WITH/SMART) |
1 | ||
| 45250-02840 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(W/SMART) |
1 | ||
| 45250-02820 |
ZRE142..NAP |
1 | ||
| 45259A - SHEET, COLUMN HOLE COVER SILENCER | ||||
| 45259-02100 |
AZE141,ZRE142..NAP |
1 | ||
| 45259-02100 |
AZE141,ZRE142..NAP |
1 | ||
| 45260 - SHAFT ASSY, STEERING INTERMEDIATE, NO.2 | ||||
| 45260-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45260-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45286B - COVER, STEERING COLUMN, UPR | ||||
| 45286-12520B0 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(WITH/SMART),DK.GRAY,TRIM1#,4# |
1 | ||
| 45286-02310B0 |
ZRE142..NAP..(CE,LE,STD) DK.GRAY,TRIM1#,4# |
1 | ||
| 45286-02310E0 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),ASH BROWN,TRIM4# |
1 | ||
| 45286-02310E0 |
ZRE142..NAP..(CE,LE,STD) ASH BROWN,TRIM4# |
1 | ||
| 45286-02310B1 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),MD.GRAY,TRIM1# |
1 | ||
| 45286-02310B1 |
ZRE142..NAP..(CE,LE,STD) MD.GRAY,TRIM1# |
1 | ||
| 45287 - COVER, STEERING COLUMN, LWR | ||||
| 45287-02300E0 |
ZRE142..NAP..(CE,LE,STD) ASH BROWN,TRIM4# |
1 | ||
| 45287-12590B2 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(WITH/SMART),DK.GRAY,TRIM1#,4# |
1 | ||
| 45287-02300E0 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),ASH BROWN,TRIM4# |
1 | ||
| 45287-02300B0 |
ZRE142..NAP..(CE,LE,STD) DK.GRAY,TRIM1#,4# |
1 | ||
| 45287-02300B1 |
ZRE142..NAP..(CE,LE,STD) MD.GRAY,TRIM1# |
1 | ||
| 45287-02300B1 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),MD.GRAY,TRIM1# |
1 | ||
| 45832 - CABLE, TILT STEERING SUPPORT BOND | ||||
| 45832-02030 |
AZE141,ZRE142..NAP |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AZE141,ZRE142..NAP |
1 | ||
| 45897-12020 |
AZE141,ZRE142..NAP |
1 | ||
| 45897A - BOLT, TILT STEERING PAWL SET | ||||
| 45897-42010 |
AZE141,ZRE142..NAP |
1 | ||
| 45897-42010 |
AZE141,ZRE142..NAP |
1 | ||
| 90119-10981 |
AZE141,ZRE142..NAP |
1 | ||
| Common parts | ||||
| 90080-11555 | ||||
| 90178-A0024 | ||||
| 90467-06188 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(0801- )NAP..LE ; (1108- )NAP..S..CND
STARTING SYSTEM-PUSH BUTTON
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45020A - ACTUATOR ASSY, STEERING LOCK | ||||
| 45020-02330 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(WITH/SMART) |
1 | ||
| 45020-02330 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(W/SMART) |
1 | ||
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45025-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45221 - SHAFT, STEERING INTERMEDIATE | ||||
| 45221-02070 |
AZE141,ZRE142..NAP |
1 | ||
| 45221-02070 |
AZE141,ZRE142..NAP |
1 | ||
| 45250 - COLUMN ASSY, STEERING | ||||
| 45250-02820 |
ZRE142..NAP |
1 | ||
| 45250-02840 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(WITH/SMART) |
1 | ||
| 45250-02840 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(W/SMART) |
1 | ||
| 45250-02820 |
ZRE142..NAP |
1 | ||
| 45259A - SHEET, COLUMN HOLE COVER SILENCER | ||||
| 45259-02100 |
AZE141,ZRE142..NAP |
1 | ||
| 45259-02100 |
AZE141,ZRE142..NAP |
1 | ||
| 45260 - SHAFT ASSY, STEERING INTERMEDIATE, NO.2 | ||||
| 45260-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45260-02110 |
AZE141,ZRE142..NAP |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-12993B1 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(W/SMART),MD.GRAY,TRIM1# |
1 | ||
| 45286-12975E1 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(W/SMART),ASH BROWN,TRIM4# |
1 | ||
| 45286B - COVER, STEERING COLUMN, UPR | ||||
| 45286-02310B1 |
ZRE142..NAP..(CE,LE,STD) MD.GRAY,TRIM1# |
1 | ||
| 45286-12520B0 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(WITH/SMART),DK.GRAY,TRIM1#,4# |
1 | ||
| 45286-02310B0 |
ZRE142..NAP..(CE,LE,STD) DK.GRAY,TRIM1#,4# |
1 | ||
| 45286-02310E0 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),ASH BROWN,TRIM4# |
1 | ||
| 45286-02310E0 |
ZRE142..NAP..(CE,LE,STD) ASH BROWN,TRIM4# |
1 | ||
| 45286-02310B1 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),MD.GRAY,TRIM1# |
1 | ||
| 45287 - COVER, STEERING COLUMN, LWR | ||||
| 45287-02300E0 |
ZRE142..NAP..(CE,LE,STD) ASH BROWN,TRIM4# |
1 | ||
| 45287-12590B2 |
ZRE142..NAP..LE..CND STARTING SYSTEM-PUSH(WITH/SMART),DK.GRAY,TRIM1#,4# |
1 | ||
| 45287-02300E0 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),ASH BROWN,TRIM4# |
1 | ||
| 45287-02300B0 |
ZRE142..NAP..(CE,LE,STD) DK.GRAY,TRIM1#,4# |
1 | ||
| 45287-02300B1 |
ZRE142..NAP..(CE,LE,STD) MD.GRAY,TRIM1# |
1 | ||
| 45287-02300B1 |
ZRE142..NAP..LE STARTING SYSTEM-PUSH(W/SMART),MD.GRAY,TRIM1# |
1 | ||
| 45832 - CABLE, TILT STEERING SUPPORT BOND | ||||
| 45832-02030 |
AZE141,ZRE142..NAP |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AZE141,ZRE142..NAP |
1 | ||
| 45897-12020 |
AZE141,ZRE142..NAP |
1 | ||
| 45897A - BOLT, TILT STEERING PAWL SET | ||||
| 45897-42010 |
AZE141,ZRE142..NAP |
1 | ||
| 45897-42010 |
AZE141,ZRE142..NAP |
1 | ||
| 90119-10981 |
AZE141,ZRE142..NAP |
1 | ||
| Common parts | ||||
| 90080-11555 | ||||
| 90178-A0024 | ||||
| 90467-06188 | ||||
