AE102L-DEMNKA (1992)

Toyota Corolla Nap/Sed

Production Sep 1992 - Aug 1997
Engine 7AFE
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(9209- )NAP

Click highlighted areas on diagram

diagram 74515A 74529 74541 74541E 74559A 74571A 74599B
Part # Description Qty Price
74529 - PLATE, CHILD PROOF OR CHILD PROTECTOR LOCK CAUTION
69339-06010

AE10#..NAP

RH

 1
69349-06010

AE10#..NAP

LH

 1
74541 - PLATE, TIRE PRESSURE CAUTION
42661-02061

AE102..NAP;AE101..NAP..N..USA

 1
42661-02060

AE10#..NAP..(E,N)

 1
74541E - PLATE, COMPACT SPARE TIRE CAUTION
42668-02020

AE10#..NAP..USA

 1
74559A - PLATE, FUEL CAUTION
74559-01010

AE10#..NAP..USA

 1
74571A - FILM, LABEL COVER
74571-32010

AE10#..NAP

 1
74599B - LABEL, DRIVER & PASSENGER AIR BAG INFORMATION
74599-50010

AE10#..NAP..USA

(J)

 1
74599-06010

AE10#..NAP..USA

(L)

 1
