AE102L-DEMEKA (1992)

Toyota Corolla Nap/Sed

Production Sep 1992 - Aug 1997
Engine 7AFE
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 1 OF 2(9209- )NAP..5F

Click highlighted areas on diagram

diagram 31126 31204 31210 31230 31232A 31236B 31250 9011908026
Part # Description Qty Price
31126 - BOOT, CLUTCH RELEASE FORK
31126-12051

AE10#..NAP..5F

 1
31204 - FORK SUB-ASSY, CLUTCH RELEASE
31204-17010

AE10#..NAP..5F

 1
31210 - COVER ASSY, CLUTCH
31210-12220

AE102..NAP..5F

 1
31210-12151

AE102..NAP..5F

 1
31210-12152

AE102..NAP..5F

 1
31230 - BEARING ASSY, CLUTCH RELEASE
31230-12170

AE10#..NAP..5F

 1
31232A - CLIP, RELEASE BEARING HUB
31232-12070

AE10#..NAP..5F

TYPE 3

 1
31232-12060

AE10#..NAP..5F

TYPE 2

 1
31232-12050

AE10#..NAP..5F

TYPE 1

 1
31236B - SUPPORT, RELEASE FORK
31236-12020

AE10#..NAP..5F

 1
31250 - DISC ASSY, CLUTCH
31250-12320

AE102..NAP..5F

 1
31250-12360

AE102..NAP..5F

 1
Common parts
90119-08026

ILLUST NO. 2 OF 2(9209- )NAP..5F

Click highlighted areas on diagram

diagram 31232A
Part # Description Qty Price
31232A - CLIP, RELEASE BEARING HUB
31232-12070

AE10#..NAP..5F

TYPE 3

 1
31232-12060

AE10#..NAP..5F

TYPE 2

 1
31232-12050

AE10#..NAP..5F

TYPE 1

 1
