TE38LV-HDFA (1974)

Toyota Corolla

Production Aug 1974 - Aug 1979
Engine 2TC
Transmission 3FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(7408-7908)TE3#,51 ; (7708-7908)KE30

Click highlighted areas on diagram

diagram 88300
Part # Description Qty Price
88300 - COOLER & ACCESSORY ASSY
88300-12160

TE3#

 1
88300-12161

TE3#,51

 1
88300-12164

TE38..USA;TE31,37..MTM..USA;TE31..A40..DLX..USA

CAL.& H.A.

 1
88300-12420

TE31..A40..SPL..USA;TE3#..(DLX,SR5)..USA

FEDERAL SPEC.

 1
88300-12162

TE3#..DLX,SPL,SR5

 1
88300-12165

TE38..USA;TE31,37..MTM..USA;TE31..A40..DLX..USA

CAL.& H.A.

 1
88300-12421

TE31..A40..SPL..USA;TE3#..(DLX,SR5)..USA

FEDERAL SPEC.

 1

(7408-7701)

Click highlighted areas on diagram

diagram 87100
Part # Description Qty Price
87100 - HEATER AND ACCESSORY ASSY
87100-12392

TE3#,51

HEAVY DUTY HEATER,W/SIDE DEF.

 1
87100-12390

TE3#

HEAVY DUTY HEATER,W/SIDE DEF.

 1
