ST162L-BLPVKK (1986)
Toyota Celica
(8608- )3SFE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16261 - HOSE, WATER BY-PASS | ||||
| 16261-74010 |
3SFE..ST162 |
1 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90467-22003 |
3S#..ST162 |
2 | ||
| 90467-21001 |
2SELC,3SFE..ST16# |
2 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90467-22003 |
3S#..ST162 |
2 | ||
| 90467-21001 |
2SELC,3SFE..ST16# |
2 | ||
| 16268 - PIPE, WATER BY-PASS, NO.1 | ||||
| 16268-74010 |
3SFE..ST162 |
1 | ||
| 16268F - RING, O(FOR WATER BY-PASS PIPE) | ||||
| 96761-24017 |
3S#..ST162 |
1 | ||
| 16321 - INLET, WATER | ||||
| 16321-88360 |
3S#..ST162 |
1 | ||
| 16325 - GASKET, WATER INLET HOUSING, NO.1 | ||||
| 16325-63010 |
2SELC,3S#..ST16# |
1 | ||
| 16331 - OUTLET, WATER | ||||
| 16304-74030 |
3SFE..ST162 |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03046 |
2SELC,3S#..ST16# *WAX 82-95 |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-63010 |
2SELC,3S#..ST16# |
1 | ||
| 16361 - FAN | ||||
| 16361-64010 |
2SELC,3S#..ST16#..4FC |
1 | ||
| 16363 - MOTOR, COOLING FAN | ||||
| 16363-16010 |
2SELC,3S#..ST16#..4FC |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-74070 |
3S#..ST162..4FC |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-74010 |
2SELC,3S#..ST16# |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12078 |
2SELC,3S#..ST16# *H,L=530,NO.1 |
1 | ||
| 90099-33080 |
2SELC,3S#..ST16# *H,L=140,NO.2 |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12078 |
2SELC,3S#..ST16# *H,L=530,NO.1 |
1 | ||
| 90099-33080 |
2SELC,3S#..ST16# *H,L=140,NO.2 |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
2SELC,3S#..ST16# |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
2SELC,3S#..ST16# |
2 | ||
| 16470C - BRACKET(FOR RADIATOR RESERVE TANK) | ||||
| 16611-74010 |
2SELC,3S#..ST16# |
1 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-74010 |
2SELC,3S#..ST16# |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 85338-14030 |
2SELC,3S#..ST16# |
1 | ||
| 16533 - SUPPORT, RADIATOR, UPPER | ||||
| 16533-74010 |
2SELC,3S#..ST16# |
2 | ||
| 16535 - SUPPORT, RADIATOR, LOWER | ||||
| 16535-74010 |
2SELC,3S#..ST16# |
2 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-74030 |
3S#..ST162 |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-33002 |
2SELC,3S#..ST16# |
2 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-33002 |
2SELC,3S#..ST16# |
2 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-74030 |
2SELC,3S#..ST16# |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90467-33002 |
2SELC,3S#..ST16# |
2 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90467-33002 |
2SELC,3S#..ST16# |
2 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16711-74030 |
2SELC,3S#..ST16#..4FC |
1 | ||
| Common parts | ||||
| 90099-00183 | ||||
| 90099-05164 | ||||
| 90179-06007 | ||||
| 90179-06045 | ||||
| 90179-08044 | ||||
| 91611-60814 | ||||
| 91651-40612 | ||||
| 91651-40816 | ||||
| 91651-60612 | ||||
| 92122-60825 | ||||
