RA42L-BCHDSA (1977)
Toyota Celica
(7708-7802)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-38051 |
20R..RA42..3FC..LT 12V 45A,W/O REGULATOR |
1 | ||
| 27020-28011 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38090 |
20R..RA42..3FC..LT 12V 55A(A TYPE),W/O REGULATOR |
1 | ||
| 27020-28012 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27039-45110 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-34050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27310-38061 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27310-38050 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10115 |
20R..RA42..3FC..LT 12V 45A,55A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27330-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27330-45090 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10116 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27330B - RING, SNAP(FOR ALTERNATOR ROTOR) | ||||
| 90099-07048 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27350-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27350-38051 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27353-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27353-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27356-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27356-45100 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27359-38051 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27359-45111 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45110 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45122 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27359-45121 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27371-44070 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 90099-17114 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27410-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27410-45080 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27441-45110 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27441-34030 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| Common parts | ||||
| 27378-38040 | ||||
| 27378-38051 | ||||
| 27387-45022 | ||||
| 90099-00912 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90099-34006 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 94110-41000 | ||||
| 94511-01400 | ||||
| 94512-01000 | ||||
| 94612-11001 | ||||
(7708-7808)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-38051 |
20R..RA42..3FC..LT 12V 45A,W/O REGULATOR |
1 | ||
| 27020-28011 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38090 |
20R..RA42..3FC..LT 12V 55A(A TYPE),W/O REGULATOR |
1 | ||
| 27020-28012 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27039-45110 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27061 - PLATE, REGULATOR COVER | ||||
| 27062-45050 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-34050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27310-38061 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27310-38050 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10115 |
20R..RA42..3FC..LT 12V 45A,55A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27330-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27330-45090 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10116 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27350-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27350-38051 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27350B - CONDENSER, ALTERNATOR | ||||
| 90099-52064 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27353-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27353-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27356-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27356-45100 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27359-38051 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27359-45111 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45110 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45122 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27359-45121 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27362-38051 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27362-45120 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 60A |
1 | ||
| 27362-70010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27362-41080 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27371-44070 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 90099-17114 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27410-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27410-45080 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27441-45110 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27441-34030 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| Common parts | ||||
| 27063-45020 | ||||
| 27064-45020 | ||||
| 27378-45090 | ||||
| 27387-45022 | ||||
| 27387-45110 | ||||
| 90099-00912 | ||||
| 90099-00916 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90119-08065 | ||||
| 93315-15012 | ||||
| 94110-41000 | ||||
| 94511-01400 | ||||
| 94512-01000 | ||||
| 94612-11001 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(7802-7808)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-38051 |
20R..RA42..3FC..LT 12V 45A,W/O REGULATOR |
1 | ||
| 27020-28011 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38090 |
20R..RA42..3FC..LT 12V 55A(A TYPE),W/O REGULATOR |
1 | ||
| 27020-28012 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27039-45110 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-34050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27310-38061 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27310-38050 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10115 |
20R..RA42..3FC..LT 12V 45A,55A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27330-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27330-45090 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10116 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27350-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27350-38051 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27353-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27353-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27356-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27356-45100 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27359-38051 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27359-45111 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45110 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45122 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27359-45121 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27362-38051 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27362-45120 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 60A |
1 | ||
| 27362-70010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27362-41080 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27371-44070 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 90099-17114 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27410-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27410-45080 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27441-45110 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27441-34030 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| Common parts | ||||
| 27378-38040 | ||||
| 27378-45090 | ||||
| 27387-45022 | ||||
| 90099-00912 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90099-34006 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 94110-41000 | ||||
| 94511-01400 | ||||
| 94512-01000 | ||||
| 94612-11001 | ||||
(7808-7906)20R
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-38051 |
20R..RA42..3FC..LT 12V 45A,W/O REGULATOR |
1 | ||
| 27020-28011 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38090 |
20R..RA42..3FC..LT 12V 55A(A TYPE),W/O REGULATOR |
1 | ||
| 27020-28012 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27039-45110 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27061 - PLATE, REGULATOR COVER | ||||
| 27062-45050 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-34050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27310-38061 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27310-38050 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10115 |
20R..RA42..3FC..LT 12V 45A,55A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27330-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27330-45090 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10116 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27350B - CONDENSER, ALTERNATOR | ||||
| 90099-52064 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27359-38051 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27359-45111 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45110 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45122 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27359-45121 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27362-38051 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27362-45120 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 60A |
1 | ||
| 27362-70010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27362-41080 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27371-44070 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 90099-17114 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27410-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27410-45080 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27441-45110 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27441-34030 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| Common parts | ||||
| 27063-45020 | ||||
| 27064-45020 | ||||
| 27378-45090 | ||||
| 27387-45022 | ||||
| 27387-45110 | ||||
| 90099-00912 | ||||
| 90099-00916 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90119-08051 | ||||
| 93315-15012 | ||||
| 93315-15014 | ||||
| 94110-41000 | ||||
| 94511-01400 | ||||
| 94512-01000 | ||||
| 94612-11001 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(7906- )20R,22R
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-38051 |
20R..RA42..3FC..LT 12V 45A,W/O REGULATOR |
1 | ||
| 27020-28011 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38090 |
20R..RA42..3FC..LT 12V 55A(A TYPE),W/O REGULATOR |
1 | ||
| 27020-28012 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27020-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE),W/O REGULATOR |
1 | ||
| 27061 - PLATE, REGULATOR COVER | ||||
| 27062-45050 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-34050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27310-38061 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27310-38050 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10115 |
20R..RA42..3FC..LT 12V 45A,55A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27330-45020 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27330-45090 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10116 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27350B - CONDENSER, ALTERNATOR | ||||
| 90099-52064 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-38050 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27359-38051 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27359-45111 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45110 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27359-45122 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27359-45121 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-38061 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27362-38051 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27362-45120 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 60A |
1 | ||
| 27362-70010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-28010 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27362-45100 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27362-41080 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE) |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27371-44070 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 90099-17114 |
20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A,60A |
2 | ||
| 27372-31011 |
20R..RA42..3FC..LT 12V 45A,55A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27410-45070 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| 27410-45080 |
20R..RA42..3FC..LT 12V 55A(B TYPE) |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 45A,55A,60A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
20R..RA42..3FC..LT 12V 45A |
1 | ||
| 27441-45110 |
22R..RA43..CP..5F..GT;20R,4ME..MA46,RA42..(3FC,5F)..(LT,SPR) 12V 55A(B TYPE),60A |
1 | ||
| 27441-34030 |
20R..RA42..3FC..LT 12V 55A(A TYPE) |
1 | ||
| Common parts | ||||
| 27063-45020 | ||||
| 27064-45020 | ||||
| 27378-45090 | ||||
| 27387-45022 | ||||
| 27387-45110 | ||||
| 90099-00912 | ||||
| 90099-00933 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90101-10083 | ||||
| 90119-08051 | ||||
| 90170-10015 | ||||
| 90201-10005 | ||||
| 93229-14012 | ||||
| 93315-15014 | ||||
| 94110-41000 | ||||
| 94511-01400 | ||||
| 94512-01000 | ||||
| 94612-11001 | ||||
| Linked diagrams | ||||
| 8401 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
