F654RM-GMMFN (2015)
Toyota Avanza
(1111-1901)MID,STD..IDN ; (1111-1904)LO,MID,STD,VB..GCC,GEN,MA,MXC,PHL,SA,TH ; (190
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52135 - GROMMET, REAR BUMPER STAY | ||||
| 9004A-18034 |
F65# |
2 | ||
| 9004A-18034 |
F65# |
2 | ||
| 52135 - GROMMET, REAR BUMPER STAY | ||||
| 9004A-18034 |
F65# |
2 | ||
| 9004A-18034 |
F65# |
2 | ||
| 52151C - BOLT, ROUND HEAD SQUARE NECK(FOR REAR BUMPER) | ||||
| 55394-60050 |
F65# |
2 | ||
| 55394-60050 |
F65# |
2 | ||
| 52151C - BOLT, ROUND HEAD SQUARE NECK(FOR REAR BUMPER) | ||||
| 55394-60050 |
F65# |
2 | ||
| 55394-60050 |
F65# |
2 | ||
| 52152C - CLIP, REAR BUMPER SIDE | ||||
| 9004A-46334 |
F65# |
2 | ||
| 9004A-46334 |
F65# |
2 | ||
| 9004A-46334 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
2 | ||
| 9004A-46334 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
2 | ||
| 52152C - CLIP, REAR BUMPER SIDE | ||||
| 9004A-46334 |
F65# |
2 | ||
| 9004A-46334 |
F65# |
2 | ||
| 9004A-46334 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
2 | ||
| 9004A-46334 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
2 | ||
| 52155A - SUPPORT, REAR BUMPER SIDE, RH | ||||
| 52155-BZ120 |
F65# |
1 | ||
| 52155-BZ120 |
F65# |
1 | ||
| 52156A - SUPPORT, REAR BUMPER SIDE, LH | ||||
| 52156-BZ120 |
F65# |
1 | ||
| 52156-BZ120 |
F65# |
1 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-BZJ60 |
F653..MID..GEN;F654..STD..(GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(IDN,MXC,PHL,SA,TH) L/RR FOG LAMP |
1 | ||
| 52159-BZJ60 |
F653..MID..GEN;F654..STD..(GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(IDN,MXC,PHL,SA,TH) L/RR FOG LAMP |
1 | ||
| 52159-BZ141 |
F653..GEN,PHL,SA;F654..RHD..4AT..STD;F654..5F..(GEN,MXC,PHL,SA);F654..4AT..MID..(GEN,MXC,PHL) L/RR FOG LAMP |
1 | ||
| 52159-BZ141 |
F653..GEN,PHL,SA;F654..RHD..4AT..STD;F654..5F..(GEN,MXC,PHL,SA);F654..4AT..MID..(GEN,MXC,PHL) L/RR FOG LAMP |
1 | ||
| 52164A - PLATE, REAR BUMPER, LH | ||||
| 52164-BZ230 |
F653..MID..GEN;F654..STD..(GCC,GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(GCC,IDN,MXC,PHL,SA,TH) |
1 | ||
| 52164-BZ230 |
F653..MID..GEN;F654..STD..(GCC,GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(GCC,IDN,MXC,PHL,SA,TH) |
1 | ||
| 52562B - RETAINER, REAR BUMPER, UPPER RH | ||||
| 52562-BZ010 |
F65# |
1 | ||
| 52562-BZ010 |
F65# |
1 | ||
| 52563A - RETAINER, REAR BUMPER, UPPER LH | ||||
| 52563-BZ010 |
F65# |
1 | ||
| 52563-BZ010 |
F65# |
1 | ||
| 52599 - STOPPER, REAR BUMPER, UPPER | ||||
| 9004A-46356 |
F65# |
3 | ||
| 9004A-46356 |
F65# |
3 | ||
| 9004A-46356 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
3 | ||
| 9004A-46356 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
3 | ||
| Common parts | ||||
| 90041-05546 | ||||
| 9004A-10209 | ||||
| 9004A-16084 | ||||
| Linked diagrams | ||||
| 8115 | ||||
| 8417 | ||||
(1901- )MID,STD..IDN ; (1904- )STD..PHL ;(1904- )F654..STD..GCC,GEN,TH ;
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52135 - GROMMET, REAR BUMPER STAY | ||||
| 9004A-18034 |
F65# |
2 | ||
| 52135 - GROMMET, REAR BUMPER STAY | ||||
| 9004A-18034 |
F65# |
2 | ||
| 52151C - BOLT, ROUND HEAD SQUARE NECK(FOR REAR BUMPER) | ||||
| 55394-60050 |
F65# |
2 | ||
| 52151C - BOLT, ROUND HEAD SQUARE NECK(FOR REAR BUMPER) | ||||
| 55394-60050 |
F65# |
2 | ||
| 52152C - CLIP, REAR BUMPER SIDE | ||||
| 9004A-46334 |
F65# |
2 | ||
| 9004A-46334 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
2 | ||
| 52152C - CLIP, REAR BUMPER SIDE | ||||
| 9004A-46334 |
F65# |
2 | ||
| 9004A-46334 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
2 | ||
| 52155A - SUPPORT, REAR BUMPER SIDE, RH | ||||
| 52155-BZ120 |
F65# |
1 | ||
| 52156A - SUPPORT, REAR BUMPER SIDE, LH | ||||
| 52156-BZ120 |
F65# |
1 | ||
| 52159 - COVER, REAR BUMPER | ||||
| 52159-BZJ60 |
F653..MID..GEN;F654..STD..(GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(IDN,MXC,PHL,SA,TH) L/RR FOG LAMP |
1 | ||
| 52159-BZ141 |
F653..GEN,PHL,SA;F654..RHD..4AT..STD;F654..5F..(GEN,MXC,PHL,SA);F654..4AT..MID..(GEN,MXC,PHL) L/RR FOG LAMP |
1 | ||
| 52164A - PLATE, REAR BUMPER, LH | ||||
| 52164-BZ230 |
F653..MID..GEN;F654..STD..(GCC,GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(GCC,IDN,MXC,PHL,SA,TH) |
1 | ||
| 52562B - RETAINER, REAR BUMPER, UPPER RH | ||||
| 52562-BZ010 |
F65# |
1 | ||
| 52563A - RETAINER, REAR BUMPER, UPPER LH | ||||
| 52563-BZ010 |
F65# |
1 | ||
| 52599 - STOPPER, REAR BUMPER, UPPER | ||||
| 9004A-46356 |
F65# |
3 | ||
| 9004A-46356 |
F653..GEN,PHL,SA;F654..4AT..STD..TH;F654..MID..(GCC,GEN,MXC,PHL,SA,TH);F654..(SPO,STD)..(GCC,GEN,MA,PHL,SA) |
3 | ||
| 52752 - MOULDING, REAR BUMPER SIDE, RH | ||||
| 52752-BZ030 |
F653..MID..GEN;F654..STD..(GCC,GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(GCC,IDN,MXC,PHL,SA,TH) |
1 | ||
| 52753 - MOULDING, REAR BUMPER SIDE, LH | ||||
| 52753-BZ030 |
F653..MID..GEN;F654..STD..(GCC,GEN,TH);F653..(MID,STD)..(IDN,PHL);F654..MID..(GCC,IDN,MXC,PHL,SA,TH) |
1 | ||
| Common parts | ||||
| 90041-05546 | ||||
| 9004A-16084 | ||||
| Linked diagrams | ||||
| 8115 | ||||
| 8417 | ||||
