Toyota Avanza F654 BRAKE TUBE & CLAMP

Part #	Description	Period	Qty
44510 - ACTUATOR ASSY, BRAKE
44050-B0090	F654..5F..(GCC,SA)	09/2016 - 04/2019	1
44050-BZ040	F654..5F..SA PAKISTAN	04/2019 - 12/2999	1
44050-B0090	F654..5F..(GCC,SA)	04/2019 - 12/2999	1
44050-BZ040	F654..5F..SA PAKISTAN	09/2016 - 04/2019	1
44050-BZ040	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	04/2019 - 12/2999	1
44050-BZ040	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	09/2016 - 04/2019	1
44547B - CUSHION, BRAKE ACTUATOR BRACKET
44547-BZ030	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	09/2016 - 04/2019	3
44546-12110	F65#..GCC,SA	09/2016 - 10/2017	3
44546-BZ020	F65#..GCC,SA	11/2017 - 04/2019	3
44546-BZ020	F65#..GCC,SA	04/2019 - 12/2999	3
44547-BZ030	F654..5F..SA PAKISTAN	09/2016 - 04/2019	3
44547-BZ030	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	04/2019 - 12/2999	3
44547-BZ030	F654..5F..SA PAKISTAN	04/2019 - 12/2999	3
44547B - CUSHION, BRAKE ACTUATOR BRACKET
44547-BZ030	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	09/2016 - 04/2019	3
44546-12110	F65#..GCC,SA	09/2016 - 10/2017	3
44546-BZ020	F65#..GCC,SA	11/2017 - 04/2019	3
44546-BZ020	F65#..GCC,SA	04/2019 - 12/2999	3
44547-BZ030	F654..5F..SA PAKISTAN	09/2016 - 04/2019	3
44547-BZ030	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	04/2019 - 12/2999	3
44547-BZ030	F654..5F..SA PAKISTAN	04/2019 - 12/2999	3
44547B - CUSHION, BRAKE ACTUATOR BRACKET
44547-BZ030	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	09/2016 - 04/2019	3
44546-12110	F65#..GCC,SA	09/2016 - 10/2017	3
44546-BZ020	F65#..GCC,SA	11/2017 - 04/2019	3
44546-BZ020	F65#..GCC,SA	04/2019 - 12/2999	3
44547-BZ030	F654..5F..SA PAKISTAN	09/2016 - 04/2019	3
44547-BZ030	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	04/2019 - 12/2999	3
44547-BZ030	F654..5F..SA PAKISTAN	04/2019 - 12/2999	3
44547C - SPACER(FOR BRAKE ACTUATOR BRACKET)
44521-B1010	F65#..GCC,SA	09/2016 - 04/2019	3
44521-B1010	F65#..GCC,SA	04/2019 - 12/2999	3
44547C - SPACER(FOR BRAKE ACTUATOR BRACKET)
44521-B1010	F65#..GCC,SA	09/2016 - 04/2019	3
44521-B1010	F65#..GCC,SA	04/2019 - 12/2999	3
44547C - SPACER(FOR BRAKE ACTUATOR BRACKET)
44521-B1010	F65#..GCC,SA	09/2016 - 04/2019	3
44521-B1010	F65#..GCC,SA	04/2019 - 12/2999	3
44591 - BRACKET, BRAKE ACTUATOR, NO.1
44590-BZ040	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	09/2016 - 11/2016	1
44590-BZ041	F654..5F..SA PAKISTAN	12/2016 - 05/2017	1
44590-BZ070	F65#..GCC,SA	09/2016 - 11/2016	1
44590-BZ041	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	12/2016 - 05/2017	1
44590-BZ090	F65#..GCC,SA	11/2017 - 04/2019	1
44590-BZ040	F654..5F..SA PAKISTAN	09/2016 - 11/2016	1
44590-BZ120	F654..5F..SA PAKISTAN	05/2017 - 04/2019	1
44590-BZ120	F654..5F..SA PAKISTAN	04/2019 - 12/2999	1
44590-BZ120	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	04/2019 - 12/2999	1
44590-BZ071	F65#..GCC,SA	12/2016 - 05/2017	1
44590-BZ120	F65#..(MID,STD,VB)..SA S.AFRICA FOR GENERAL EXP	05/2017 - 04/2019	1
44590-BZ130	F65#..GCC,SA	05/2017 - 10/2017	1
44590-BZ090	F65#..GCC,SA	04/2019 - 12/2999	1
Common parts
9004A-10217
90119-06834

F654RM-GMMFN (2015)

(1609- )GCC,SA
