RN50L-TRA (1987)
Toyota 4-Runner Truck
(8308- )LN56,65,RN6#..G ; (8708-8808)G
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33211 - FORK, REVERSE SHIFT | ||||
| 33211-28010 |
RN50..CND;RN5#,70..G |
1 | ||
| 33213 - FORK, 1ST & 2ND SHIFT | ||||
| 33212-20050 |
RN5#..MTM |
1 | ||
| 33212-35023 |
RN50..CND;RN5#,70..G |
1 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
LN5#,65,RN5#,6# |
5 | ||
| 90254-05001 |
RN50..CND;RN5#,70..G |
3 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
LN5#,65,RN5#,6# |
5 | ||
| 90254-05001 |
RN50..CND;RN5#,70..G |
3 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
LN5#,65,RN5#,6# |
5 | ||
| 90254-05001 |
RN50..CND;RN5#,70..G |
3 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
LN5#,65,RN5#,6# |
5 | ||
| 90254-05001 |
RN50..CND;RN5#,70..G |
3 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-06052 |
RN50..CND;RN5#,70..G |
2 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-06052 |
RN50..CND;RN5#,70..G |
2 | ||
| 33215 - FORK, 3RD & 4TH SHIFT | ||||
| 33213-35032 |
RN50..CND;RN5#,70..G |
1 | ||
| 33213-31010 |
RN5#..MTM |
1 | ||
| 33221 - ARM, REVERSE SHIFT | ||||
| 33221-28010 |
RN50..CND;RN5#,70..G |
1 | ||
| 33225 - SHOE, SHIFT ARM | ||||
| 33225-35030 |
RN50..CND;RN5#,70..G |
1 | ||
| 33225A - RING, SHAFT SNAP(FOR SHIFT ARM SHOE) | ||||
| 96160-00800 |
RN50..CND;RN5#,70..G |
1 | ||
| 33228 - BRACKET, REVERSE SHIFT ARM | ||||
| 33228-28010 |
RN50..CND;RN5#,70..G |
1 | ||
| 33228B - PIN, RING(FOR REVERSE SHIFT ARM BRACKET) | ||||
| 90253-11001 |
RN50..CND;RN5#,70..G |
2 | ||
| 33231 - HEAD, REVERSE SHIFT | ||||
| 33231-35050 |
RN50..CND;RN50..4F..G |
1 | ||
| 33241 - SHAFT, REVERSE SHIFT FORK | ||||
| 33244-30030 |
RN5#..4F |
1 | ||
| 33244-35030 |
RN50..CND;RN50..4F..G |
1 | ||
| 33243 - SHAFT, 1ST & 2ND SHIFT FORK | ||||
| 33242-20060 |
RN5#..MTM |
1 | ||
| 33244B - RING, SHAFT SNAP (FOR SHIFT FORK SHAFT) | ||||
| 90520-12003 |
RN50..CND;RN5#,70..G |
2 | ||
| 90523-12001 |
RN50..CND;RN5#,70..G |
2 | ||
| 33244B - RING, SHAFT SNAP (FOR SHIFT FORK SHAFT) | ||||
| 90520-12003 |
RN50..CND;RN5#,70..G |
2 | ||
| 90523-12001 |
RN50..CND;RN5#,70..G |
2 | ||
| 33245 - SHAFT, 3RD & 4TH SHIFT FORK | ||||
| 33243-20031 |
RN5#..MTM |
1 | ||
| 33243-35041 |
RN50..CND;RN5#,70..G |
1 | ||
| 33243-35042 |
RN50..CND;RN5#,70..G |
1 | ||
| 33245A - SHAFT, 5TH SHIFT ARM | ||||
| 33246-35020 |
RN50..CND;RN5#,70..G |
1 | ||
| 33251 - LEVER, SHIFT & SELECT | ||||
| 33251-20040 |
RN5#..4F |
1 | ||
| 33251-35060 |
RN50..CND;LN5#,RN5#,70..G |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 33264-31010 |
RN5#..MTM |
2 | ||
| 90361-10002 |
RN50..CND;RN5#,70..G L=21.6,PIN,PIN,L=21.6 |
1 | ||
| 90361-10003 |
RN50..CND;RN5#,70..G L=13.6,OD=9.5,PIN,L=13.6 |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 33264-31010 |
RN5#..MTM |
2 | ||
| 90361-10002 |
RN50..CND;RN5#,70..G L=21.6,PIN,PIN,L=21.6 |
1 | ||
| 90361-10003 |
RN50..CND;RN5#,70..G L=13.6,OD=9.5,PIN,L=13.6 |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 33264-31010 |
RN5#..MTM |
2 | ||
| 90361-10002 |
RN50..CND;RN5#,70..G L=21.6,PIN,PIN,L=21.6 |
1 | ||
| 90361-10003 |
RN50..CND;RN5#,70..G L=13.6,OD=9.5,PIN,L=13.6 |
1 | ||
| 33265 - PIN, SHIFT INTER LOCK, NO.2 | ||||
| 90250-05020 |
RN50..CND;RN5#,70..G L=11.1,OD=4.8 |
2 | ||
| 33265 - PIN, SHIFT INTER LOCK, NO.2 | ||||
| 90250-05020 |
RN50..CND;RN5#,70..G L=11.1,OD=4.8 |
2 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-10004 |
RN5#..MTM |
1 | ||
| 90341-12008 |
RN50..CND;RN5#,70..G OD=18 |
5 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-10004 |
RN5#..MTM |
1 | ||
| 90341-12008 |
RN50..CND;RN5#,70..G OD=18 |
5 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-10004 |
RN5#..MTM |
1 | ||
| 90341-12008 |
RN50..CND;RN5#,70..G OD=18 |
5 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-10004 |
RN5#..MTM |
1 | ||
| 90341-12008 |
RN50..CND;RN5#,70..G OD=18 |
5 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-10004 |
RN5#..MTM |
1 | ||
| 90341-12008 |
RN50..CND;RN5#,70..G OD=18 |
5 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-13001 |
RN5#..MTM L=16.5 |
1 | ||
| 90501-10061 |
RN50..CND;RN5#,70..G L=22.1,L=22.1 |
1 | ||
| 90501-14062 |
RN50..CND;RN5#,70..G L=30.6,L=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-13001 |
RN5#..MTM L=16.5 |
1 | ||
| 90501-10061 |
RN50..CND;RN5#,70..G L=22.1,L=22.1 |
1 | ||
| 90501-14062 |
RN50..CND;RN5#,70..G L=30.6,L=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-13001 |
RN5#..MTM L=16.5 |
1 | ||
| 90501-10061 |
RN50..CND;RN5#,70..G L=22.1,L=22.1 |
1 | ||
| 90501-14062 |
RN50..CND;RN5#,70..G L=30.6,L=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-13001 |
RN5#..MTM L=16.5 |
1 | ||
| 90501-10061 |
RN50..CND;RN5#,70..G L=22.1,L=22.1 |
1 | ||
| 90501-14062 |
RN50..CND;RN5#,70..G L=30.6,L=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-13001 |
RN5#..MTM L=16.5 |
1 | ||
| 90501-10061 |
RN50..CND;RN5#,70..G L=22.1,L=22.1 |
1 | ||
| 90501-14062 |
RN50..CND;RN5#,70..G L=30.6,L=30.6 |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-08009 |
RN5#..MTM |
1 | ||
| 90360-10003 |
RN50..CND;RN5#,70..G |
5 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-08009 |
RN5#..MTM |
1 | ||
| 90360-10003 |
RN50..CND;RN5#,70..G |
5 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-08009 |
RN5#..MTM |
1 | ||
| 90360-10003 |
RN50..CND;RN5#,70..G |
5 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-08009 |
RN5#..MTM |
1 | ||
| 90360-10003 |
RN50..CND;RN5#,70..G |
5 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-08009 |
RN5#..MTM |
1 | ||
| 90360-10003 |
RN50..CND;RN5#,70..G |
5 | ||
| 33280 - PIN ASSY, REVERSE RESTRICT | ||||
| 33280-35030 |
RN50..CND;RN5#,70..G LH |
1 | ||
| 33280-35020 |
RN50..CND;RN5#,70..G RH |
1 | ||
| 33280 - PIN ASSY, REVERSE RESTRICT | ||||
| 33280-35030 |
RN50..CND;RN5#,70..G LH |
1 | ||
| 33280-35020 |
RN50..CND;RN5#,70..G RH |
1 | ||
| 33521 - HOUSING, SHIFT LEVER | ||||
| 33521-14040 |
RN5#..MTM |
1 | ||
| 33521-35070 |
RN50..CND;LN5#,RN5#,70..G |
1 | ||
| 33521 - HOUSING, SHIFT LEVER | ||||
| 33521-14040 |
RN5#..MTM |
1 | ||
| 33521-35070 |
RN50..CND;LN5#,RN5#,70..G |
1 | ||
| 33521F - PIN OR BOLT (FOR SHIFT LEVER HOUSING) | ||||
| 90113-08001 |
RN50..CND;RN5#,70..G |
1 | ||
| 90254-05016 |
RN5#..MTM |
1 | ||
| 33521P - WASHER, LOCK (FOR SHIFT LEVER HOUSING) | ||||
| 90215-09003 |
RN50..CND;RN5#,70..G |
1 | ||
| Common parts | ||||
| 90119-08597 | ||||
| Linked diagrams | ||||
| 3312 | ||||
