MXPJ15-BHXNB (2020)
Toyota Yaris Cross
(2008- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69050A - LOCK ASSY, REAR DOOR W/MOTOR, RH | ||||
| 69050-K0010 |
MXPB1#,MXPJ1# |
1 | ||
| 69060A - LOCK ASSY, REAR DOOR W/MOTOR, LH | ||||
| 69060-K0010 |
MXPB1#,MXPJ1# |
1 | ||
| 69203A - FRAME SUB-ASSY, REAR DOOR OUTSIDE HANDLE, RH | ||||
| 69203-52110 |
MXPB1#,MXPJ1# |
1 | ||
| 69204A - FRAME SUB-ASSY, REAR DOOR OUTSIDE HANDLE, LH | ||||
| 69204-52120 |
MXPB1#,MXPJ1# |
1 | ||
| 69205A - HANDLE SUB-ASSY, REAR DOOR INSIDE, RH | ||||
| 69205-K0040C0 |
MXPB1#,MXPJ1#..G,HBDG BLACK,TRIM4#,6# |
1 | ||
| 69205-K0040C0 |
MXPB1#,MXPJ1#..HBDX,X BLACK,TRIM2# |
1 | ||
| 69206C - HANDLE SUB-ASSY, REAR DOOR INSIDE, LH | ||||
| 69206-K0040C0 |
MXPB1#,MXPJ1#..G,HBDG BLACK,TRIM4#,6# |
1 | ||
| 69206-K0040C0 |
MXPB1#,MXPJ1#..HBDX,X BLACK,TRIM2# |
1 | ||
| 69227J - COVER, REAR DOOR OUTSIDE HANDLE, RH | ||||
| 69227-47020 |
MXPB1#,MXPJ1# |
1 | ||
| 69227L - COVER, REAR DOOR OUTSIDE HANDLE, LH | ||||
| 69227-47020 |
MXPB1#,MXPJ1# |
1 | ||
| 69230 - HANDLE ASSY, REAR DOOR OUTSIDE, RH | ||||
| 69211-47021F1 |
MXPB1#,MXPJ1# BRASS GOLD ME.,2TY ,5C2 |
1 | ||
| 69211-47021E8 |
MXPB1#,MXPJ1# BEIGE,2KP ,2SG ,2TV ,4V6 |
1 | ||
| 69211-47021A1 |
MXPB1#,MXPJ1# WHITE PEARL CS.,070 ,2KR |
1 | ||
| 69211-47021C2 |
MXPB1#,MXPJ1# BLACK MC.,209 ,2UB |
1 | ||
| 69211-47021D1 |
MXPB1#,MXPJ1# RED MC.,2PN ,3T3 |
1 | ||
| 69211-47021J0 |
MXPB1#,MXPJ1# DK.BLUE M.M.,8W7 |
1 | ||
| 69211-47021R0 |
MXPB1#,MXPJ1# GRAYISH BLUE,2TU ,2UR ,8W2 |
1 | ||
| 69211-47021P0 |
MXPB1#,MXPJ1# SILVER ME.,1L0 ,2TX |
1 | ||
| 69237B - NUT, REAR DOOR HANDLE | ||||
| 69237-62010 |
MXPB1#,MXPJ1# |
2 | ||
| 69239D - BUSH, REAR DOOR HANDLE | ||||
| 69239-47010 |
MXPB1#,MXPJ1# |
2 | ||
| 69240 - HANDLE ASSY, REAR DOOR OUTSIDE, LH | ||||
| 69211-47021D1 |
MXPB1#,MXPJ1# RED MC.,2PN ,3T3 |
1 | ||
| 69211-47021E8 |
MXPB1#,MXPJ1# BEIGE,2KP ,2SG ,2TV ,4V6 |
1 | ||
| 69211-47021A1 |
MXPB1#,MXPJ1# WHITE PEARL CS.,070 ,2KR |
1 | ||
| 69211-47021P0 |
MXPB1#,MXPJ1# SILVER ME.,1L0 ,2TX |
1 | ||
| 69211-47021F1 |
MXPB1#,MXPJ1# BRASS GOLD ME.,2TY ,5C2 |
1 | ||
| 69211-47021C2 |
MXPB1#,MXPJ1# BLACK MC.,209 ,2UB |
1 | ||
| 69211-47021J0 |
MXPB1#,MXPJ1# DK.BLUE M.M.,8W7 |
1 | ||
| 69211-47021R0 |
MXPB1#,MXPJ1# GRAYISH BLUE,2TU ,2UR ,8W2 |
1 | ||
| 69241G - PAD, REAR DOOR OUTSIDE HANDLE, FRONT | ||||
| 69241-47020 |
MXPB1#,MXPJ1# |
2 | ||
| 69242G - PAD, REAR DOOR OUTSIDE HANDLE, REAR | ||||
| 69242-47030 |
MXPB1#,MXPJ1# |
2 | ||
| 69283A - PLUG, REAR DOOR INSIDE HANDLE BEZEL, RH | ||||
| 69283-52010C1 |
MXPB1#,MXPJ1#..G,HBDG BLACK,TRIM4#,6# |
1 | ||
| 69283-52010C1 |
MXPB1#,MXPJ1#..HBDX,X BLACK,TRIM2# |
1 | ||
| 69284D - PLUG, REAR DOOR INSIDE HANDLE BEZEL, LH | ||||
| 69283-52010C1 |
MXPB1#,MXPJ1#..HBDX,X BLACK,TRIM2# |
1 | ||
| 69283-52010C1 |
MXPB1#,MXPJ1#..G,HBDG BLACK,TRIM4#,6# |
1 | ||
| 69318D - SEAL, DOOR LOCK WIRING HARNESS | ||||
| 69318-47010 |
MXPB1#,MXPJ1# |
2 | ||
| 69410B - PLATE ASSY, REAR DOOR LOCK STRIKER | ||||
| 69410-47010 |
MXPB1#,MXPJ1# |
2 | ||
| 69730M - CABLE, REAR DOOR LOCK REMOTE CONTROL, RH(FOR OPEN LEVER | ||||
| 69730-52271 |
MXPB1#,MXPJ1# |
1 | ||
| 69730-52270 |
MXPB1#,MXPJ1# |
1 | ||
| 69740E - CABLE, REAR DOOR LOCK REMOTE CONTROL, LH(FOR OPEN LEVER | ||||
| 69730-52271 |
MXPB1#,MXPJ1# |
1 | ||
| 69730-52270 |
MXPB1#,MXPJ1# |
1 | ||
| 69770E - CABLE, REAR DOOR INSIDE LOCKING, RH(FOR LOCK / UNLOCK K | ||||
| 69770-52151 |
MXPB1#,MXPJ1# |
1 | ||
| 69770-52150 |
MXPB1#,MXPJ1# |
1 | ||
| 69780E - CABLE, REAR DOOR INSIDE LOCKING, LH(FOR LOCK / UNLOCK K | ||||
| 69770-52150 |
MXPB1#,MXPJ1# |
1 | ||
| 69770-52151 |
MXPB1#,MXPJ1# |
1 | ||
| Common parts | ||||
| 69296-30010 | ||||
| 90148-50003 | ||||
| 90148-60083 | ||||
| 90148-80066 | ||||
| 90189-05003 | ||||
| 93567-55020 | ||||
