SCP90-AHXEK (2008)
Toyota Vitz
(0907- )KSP90,SCP90..B,F,ILL,U
ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀｲﾌﾟ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81496 - GUIDE, REAR COMBINATION LAMP | ||||
| 81496-52020 |
KSP90,NCP9#,SCP90 |
2 | ||
| 81496-52020 |
KSP90,NCP9#,SCP90 |
2 | ||
| 81497 - COVER, REAR COMBINATION LAMP, RH | ||||
| 81497-52020 |
KSP90,NCP9#,SCP90 |
1 | ||
| 81497-52020 |
KSP90,NCP9#,SCP90 |
1 | ||
| 81498 - COVER, REAR COMBINATION LAMP, LH | ||||
| 81497-52020 |
KSP90,NCP9#,SCP90 |
1 | ||
| 81497-52020 |
KSP90,NCP9#,SCP90 |
1 | ||
| 81550 - LAMP ASSY, REAR COMBINATION, RH | ||||
| 81550-52720 |
KSP90,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵),ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀCﾌﾟ |
1 | ||
| 81550-52730 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀｲﾌﾟ |
1 | ||
| 81550-52710 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀｲﾌﾟ |
1 | ||
| 81550-52700 |
KSP90,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵),ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀCﾌﾟ |
1 | ||
| 81550F - BULB, TAIL LAMP | ||||
| 99132-12050 |
KSP90,NCP9#,SCP90..B,F,ILL,U |
2 | ||
| 99132-12050 |
KSP90,NCP9#,SCP90..B,F,ILL,U,X |
2 | ||
| 81550L - BULB, REAR TURN SIGNAL LAMP | ||||
| 90981-15009 |
KSP90,NCP9#,SCP90..B,F,ILL,U,X |
2 | ||
| 99132-11210 |
KSP90,NCP9#,SCP90..B,F,ILL,U |
2 | ||
| 81550N - BULB, BACK UP LAMP | ||||
| 99132-11210 |
KSP90,NCP9#,SCP90..B,F,ILL,U,X ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵) |
1 | ||
| 99132-11210 |
KSP90,NCP9#,SCP90..B,F,ILL,U |
2 | ||
| 99132-11210 |
KSP90,NCP9#,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵) |
1 | ||
| 99132-11210 |
KSP90,NCP9#,SCP90..B,F,ILL,U,X |
2 | ||
| 81550Q - BULB, REAR FOG LAMP, NO.1 | ||||
| 99132-11210 |
KSP90,NCP9#,SCP90..B,F,ILL,U,X ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵) |
1 | ||
| 99132-11210 |
KSP90,NCP9#,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵) |
1 | ||
| 81551 - LENS, REAR COMBINATION LAMP, RH | ||||
| 81551-52540 |
KSP90,NCP9#,SCP90..B,F,U,X ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵) |
1 | ||
| 81551-52530 |
KSP90,NCP9#,SCP90..B,F,U,X |
1 | ||
| 81551-52720 |
KSP90,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵),ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀCﾌﾟ |
1 | ||
| 81551-52710 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀｲﾌﾟ |
1 | ||
| 81551-52700 |
KSP90,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵),ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀCﾌﾟ |
1 | ||
| 81551-52730 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀｲﾌﾟ |
1 | ||
| 81554 - GASKET, REAR COMBINATION LAMP BODY, RH | ||||
| 81554-52530 |
KSP90,NCP9#,SCP90..B,F,U,X |
1 | ||
| 81554-52710 |
KSP90,NCP9#,SCP90..B,F,ILL,U |
1 | ||
| 81552-52710 |
KSP90,NCP9#,SCP90..B,F,ILL,U |
1 | ||
| 81555 - SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, RH | ||||
| 81555-52540 |
KSP90,NCP9#,SCP90..B,F,U,X ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵) |
1 | ||
| 81555-52730 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀｲﾌﾟ |
1 | ||
| 81555-52720 |
KSP90,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵),ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀCﾌﾟ |
1 | ||
| 81555-52530 |
KSP90,NCP9#,SCP90..B,F,U,X |
1 | ||
| 81555-52710 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀｲﾌﾟ |
1 | ||
| 81555-52700 |
KSP90,SCP90..B,F,ILL,U ﾘﾔﾌｫｸﾞﾗﾝﾌﾟ−有り(ﾘﾔｺﾝﾋﾞﾈｰｼｮﾝﾗﾝﾌﾟ内蔵),ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀCﾌﾟ |
1 | ||
| 81560 - LAMP ASSY, REAR COMBINATION, LH | ||||
| 81560-52640 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀｲﾌﾟ |
1 | ||
| 81560-52630 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀｲﾌﾟ |
1 | ||
| 81561 - LENS, REAR COMBINATION LAMP, LH | ||||
| 81561-52630 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀｲﾌﾟ |
1 | ||
| 81561-52640 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀｲﾌﾟ |
1 | ||
| 81561-52470 |
KSP90,NCP9#,SCP90..B,F,U,X |
1 | ||
| 81564 - GASKET, REAR COMBINATION LAMP BODY, LH | ||||
| 81562-52630 |
KSP90,NCP9#,SCP90..B,F,ILL,U |
1 | ||
| 81564-52470 |
KSP90,NCP9#,SCP90..B,F,U,X |
1 | ||
| 81564-52630 |
KSP90,NCP9#,SCP90..B,F,ILL,U |
1 | ||
| 81565 - SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, LH | ||||
| 81565-52470 |
KSP90,NCP9#,SCP90..B,F,U,X |
1 | ||
| 81565-52640 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=ﾊﾞﾙﾌﾞﾀｲﾌﾟ |
1 | ||
| 81565-52630 |
KSP90,SCP90..B,F,ILL,U ｽﾄｯﾌﾟﾗﾝﾌﾟ=LEDﾀｲﾌﾟ |
1 | ||
| Common parts | ||||
| 90179-06115 | ||||
