NCP15-AGMGK (1999)
Toyota Vitz
(9901-0112)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69051 - CYLINDER & KEY SET, DOOR LOCK, RH | ||||
| 69051-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69051-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69052 - CYLINDER & KEY SET, DOOR LOCK, LH | ||||
| 69052-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69052-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69054 - CYLINDER & KEY SET, BACK DOOR LOCK | ||||
| 69055-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69055-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69057A - CYLINDER & KEY SET, IGNITION SWITCH LOCK | ||||
| 69057-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69057-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69503 - CYLINDER SET, LOCK | ||||
| 69005-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69005-52380 |
NCP10..RS,U;NCP15,SCP10..F |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
(9901-0112)
ｱﾘ(ﾜｲﾔﾚｽﾄﾞｱﾛｯｸ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69051 - CYLINDER & KEY SET, DOOR LOCK, RH | ||||
| 69051-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69051-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69052 - CYLINDER & KEY SET, DOOR LOCK, LH | ||||
| 69052-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69052-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69054 - CYLINDER & KEY SET, BACK DOOR LOCK | ||||
| 69055-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69055-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69057A - CYLINDER & KEY SET, IGNITION SWITCH LOCK | ||||
| 69057-52020 |
NCP1#,SCP10..CLA,F,RS,U ｱﾘ(ﾜｲﾔﾚｽ ﾄﾞｱ ﾛﾂｸ) |
1 | ||
| 69057-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| Linked diagrams | ||||
| 8420 | ||||
(0112- )4FC,5F..B,F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69503 - CYLINDER SET, LOCK | ||||
| 69005-52010 |
NCP10,15,SCP10..B,F,RS |
1 | ||
| 69005-52380 |
NCP10..RS,U;NCP15,SCP10..F |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69510 - CYLINDER ASSY, FRONT DOOR LOCK, RH | ||||
| 69510-52120 |
NCP1#,SCP10 |
1 | ||
| 69520 - CYLINDER ASSY, FRONT DOOR LOCK, LH | ||||
| 69520-52120 |
NCP1#,SCP10 |
1 | ||
| 69560 - CYLINDER ASSY, BACK DOOR LOCK | ||||
| 69560-52170 |
NCP1#,SCP10..CLA,F,RS,U |
1 | ||
| 69570 - CYLINDER ASSY, IGNITION SWITCH LOCK | ||||
| 69570-12180 |
NCP1#,SCP10 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
(0112- )4HC ; (0112- )CLA,RS,U
ｱﾘ(ﾜｲﾔﾚｽﾄﾞｱﾛｯｸ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00167 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00166 |
NCP10,15,SCP10..B,F,RS ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00186 |
NCP1#,SCP10 ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00186 |
NCP13;NCP10,15,SCP10..B,CLA,F,U ﾏｽﾀｰｷｰ |
2 | ||
| 90999-00167 |
NCP15,SCP10..F ﾏｽﾀｰｷｰ,10 MILLION ｾﾚｸｼﾖﾝ *(T) |
2 | ||
| 90999-00199 |
NCP10..RS,U;NCP15,SCP10..B,F ﾏｽﾀｰｷｰ,*68付き |
2 | ||
| 69510 - CYLINDER ASSY, FRONT DOOR LOCK, RH | ||||
| 69510-52120 |
NCP1#,SCP10 |
1 | ||
| 69520 - CYLINDER ASSY, FRONT DOOR LOCK, LH | ||||
| 69520-52120 |
NCP1#,SCP10 |
1 | ||
| 69560 - CYLINDER ASSY, BACK DOOR LOCK | ||||
| 69560-52170 |
NCP1#,SCP10..CLA,F,RS,U |
1 | ||
| 69570 - CYLINDER ASSY, IGNITION SWITCH LOCK | ||||
| 69570-12180 |
NCP1#,SCP10 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759R - SNAP, FRONT DOOR LOCK CYLINDER | ||||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32090 |
NCP1#,SCP10 右側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| 69759-32100 |
NCP1#,SCP10 左側 |
1 | ||
| Linked diagrams | ||||
| 8420 | ||||
