NCP131-AHXVK (2010)
Toyota Vitz
(1012-1205)NCP131,NSP130
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71017 - FRAME SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52621 |
NCP131,NSP13#..CBU |
1 | ||
| 71018 - FRAME SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52501 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52490 |
NCP131,NSP13#..CBU |
1 | ||
| 71305A - HINGE SUB-ASSY, REAR SEAT BACK, CENTER | ||||
| 71305-52100 |
NCP131,NSP130..CBU |
1 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71601A - PAD SUB-ASSY, REAR SEAT CUSHION W/COVER | ||||
| 71601-52P00B1 |
NCP131,NSP130..U..CBU GRAY,TRIM1# |
1 | ||
| 71601-52P20C1 |
NCP131..CVT..RS BLACK,TRIM1# |
1 | ||
| 71603D - PAD SUB-ASSY, REAR SEAT BACK W/COVER, RH | ||||
| 71603-52T91B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52T91B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52T90B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52U10C1 |
NCP131..CVT..RS BLACK,TRIM1# |
1 | ||
| 71603-52U11C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71603-52T91B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52U11C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71603-52U11C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71604D - PAD SUB-ASSY, REAR SEAT BACK W/COVER, LH | ||||
| 71604-52Q20C1 |
NCP131..CVT..RS BLACK,TRIM1# |
1 | ||
| 71604-52Q01B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q01B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q00B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q21C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71604-52Q21C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71604-52Q01B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q21C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72630C - LOCK ASSY, REAR SEAT BACK, RH | ||||
| 72630-52140 |
KSP130,NCP131,NSP13#..CBU |
1 | ||
| 72630-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640A - LOCK ASSY, REAR SEAT BACK, LH | ||||
| 72640-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640-52130 |
NCP131,NSP13#..CBU |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12080 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 73705 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, RH | ||||
| 73705-52180 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| 73706 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, LH | ||||
| 73706-52020 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| Common parts | ||||
| 90105-10496 | ||||
| 90119-10945 | ||||
| 91511-80820 | ||||
| 91553-80820 | ||||
(1110-1205)RS
G'S
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71017 - FRAME SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52621 |
NCP131,NSP13#..CBU |
1 | ||
| 71018 - FRAME SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71018-52501 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52490 |
NCP131,NSP13#..CBU |
1 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-52K60B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71075-52K60B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077S - COVER, REAR SEAT BACK, RH (FOR SEPARATE TYPE) | ||||
| 71077-52L70B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71078S - COVER, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71078-52K00B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s,BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K00B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s,BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s,BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71305A - HINGE SUB-ASSY, REAR SEAT BACK, CENTER | ||||
| 71305-52100 |
NCP131,NSP130..CBU |
1 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71503-52450 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71503-52450 |
NCP131..RS G’s |
1 | ||
| 71651S - PAD, REAR SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71651-52660 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71651-52660 |
NCP131..RS G’s |
1 | ||
| 71651-52660 |
NCP131..RS G’s |
1 | ||
| 71651-52660 |
NCP131..RS G’s |
1 | ||
| 71651-52660 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71651-52660 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652S - PAD, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71652-52630 |
NCP131..RS G’s |
1 | ||
| 71652-52630 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652-52560 |
NCP131..RS G’s |
1 | ||
| 71652-52560 |
NCP131..RS G’s |
1 | ||
| 71652-52560 |
NCP131..RS G’s |
1 | ||
| 71652-52560 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652-52560 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652-52560 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72630C - LOCK ASSY, REAR SEAT BACK, RH | ||||
| 72630-52140 |
KSP130,NCP131,NSP13#..CBU |
1 | ||
| 72630-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640A - LOCK ASSY, REAR SEAT BACK, LH | ||||
| 72640-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640-52130 |
NCP131,NSP13#..CBU |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12080 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 73705 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, RH | ||||
| 73705-52180 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| 73706 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, LH | ||||
| 73706-52020 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| Common parts | ||||
| 90105-10496 | ||||
| 90119-10945 | ||||
| 91511-80820 | ||||
| 91553-80820 | ||||
(1212-1301)F
ｲｯﾀｲｶﾄｳｼｷ(CIEL)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-52K60B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71075-52K60B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71503-52450 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71503-52450 |
NCP131..RS G’s |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71960B - HEADREST ASSY, REAR SEAT, CENTER | ||||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72630C - LOCK ASSY, REAR SEAT BACK, RH | ||||
| 72630-52140 |
KSP130,NCP131,NSP13#..CBU |
1 | ||
| 72630-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640A - LOCK ASSY, REAR SEAT BACK, LH | ||||
| 72640-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640-52130 |
NCP131,NSP13#..CBU |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12080 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 73705 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, RH | ||||
| 73705-52180 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| 73706 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, LH | ||||
| 73706-52020 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| Common parts | ||||
| 90105-10496 | ||||
| 90119-10945 | ||||
| 91551-80835 | ||||
| 91553-80820 | ||||
(1205- )NSP130..U ; (1205- )NSP130..F,JEWL; (1205- )KSP130,NCP131..JEWL,R
6:4ﾌﾞﾝｶﾂ ｶﾄｳｼｷ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71017 - FRAME SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52621 |
NCP131,NSP13#..CBU |
1 | ||
| 71018 - FRAME SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71018-52501 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52490 |
NCP131,NSP13#..CBU |
1 | ||
| 71305A - HINGE SUB-ASSY, REAR SEAT BACK, CENTER | ||||
| 71305-52100 |
NCP131,NSP130..CBU |
1 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71601A - PAD SUB-ASSY, REAR SEAT CUSHION W/COVER | ||||
| 71601-52P00B1 |
NCP131,NSP130..U..CBU GRAY,TRIM1# |
1 | ||
| 71601-52P20C1 |
NCP131..CVT..RS BLACK,TRIM1# |
1 | ||
| 71603D - PAD SUB-ASSY, REAR SEAT BACK W/COVER, RH | ||||
| 71603-52T91B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52T91B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52T90B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52U10C1 |
NCP131..CVT..RS BLACK,TRIM1# |
1 | ||
| 71603-52U11C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71603-52T91B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71603-52U11C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71603-52U11C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71604D - PAD SUB-ASSY, REAR SEAT BACK W/COVER, LH | ||||
| 71604-52Q20C1 |
NCP131..CVT..RS BLACK,TRIM1# |
1 | ||
| 71604-52Q01B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q01B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q00B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q21C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71604-52Q21C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71604-52Q01B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71604-52Q21C1 |
NCP131..RS BLACK,TRIM1# |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71960B - HEADREST ASSY, REAR SEAT, CENTER | ||||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72630C - LOCK ASSY, REAR SEAT BACK, RH | ||||
| 72630-52140 |
KSP130,NCP131,NSP13#..CBU |
1 | ||
| 72630-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640A - LOCK ASSY, REAR SEAT BACK, LH | ||||
| 72640-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640-52130 |
NCP131,NSP13#..CBU |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12080 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 73705 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, RH | ||||
| 73705-52180 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| 73706 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, LH | ||||
| 73706-52020 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| Common parts | ||||
| 90105-10496 | ||||
| 90119-10578 | ||||
| 90119-10945 | ||||
| 91551-80820 | ||||
| 91551-80835 | ||||
| 91553-80820 | ||||
(1205- )KSP130,NCP131,NSP13#..F,GRS,RS
6:4ﾌﾞﾝｶﾂ ｶﾄｳｼｷ(ﾋｮｳﾋﾌﾞﾝﾘﾀｲﾌﾟ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71017 - FRAME SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52620 |
NCP131,NSP13#..CBU |
1 | ||
| 71017-52621 |
NCP131,NSP13#..CBU |
1 | ||
| 71018 - FRAME SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71018-52501 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52500 |
NCP131,NSP13#..CBU |
1 | ||
| 71018-52490 |
NCP131,NSP13#..CBU |
1 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-52K60B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71075-52K60B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077S - COVER, REAR SEAT BACK, RH (FOR SEPARATE TYPE) | ||||
| 71077-52L70B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71077-52L70B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71078S - COVER, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71078-52K00B0 |
NCP131..RS G’s,BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s,BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K00B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DARK GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s,BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s,BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71078-52K01B0 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK/DK.GRAY,TRIM1# |
1 | ||
| 71305A - HINGE SUB-ASSY, REAR SEAT BACK, CENTER | ||||
| 71305-52100 |
NCP131,NSP130..CBU |
1 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71480A - CLIP (FOR REAR SEAT BACK) | ||||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
11 | ||
| 90467-09050 |
NCP131,NSP13#..CBU |
13 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71503-52450 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71503-52450 |
NCP131..RS G’s |
1 | ||
| 71651S - PAD, REAR SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71651-52660 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71651-52660 |
NCP131..RS G’s |
1 | ||
| 71651-52660 |
NCP131..RS G’s |
1 | ||
| 71651-52660 |
NCP131..RS G’s |
1 | ||
| 71651-52660 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71651-52660 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652S - PAD, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71652-52630 |
NCP131..RS G’s |
1 | ||
| 71652-52630 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652-52560 |
NCP131..RS G’s |
1 | ||
| 71652-52560 |
NCP131..RS G’s |
1 | ||
| 71652-52560 |
NCP131..RS G’s |
1 | ||
| 71652-52560 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652-52560 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71652-52560 |
NCP131..RS G’s&SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA) |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71960B - HEADREST ASSY, REAR SEAT, CENTER | ||||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72630C - LOCK ASSY, REAR SEAT BACK, RH | ||||
| 72630-52140 |
KSP130,NCP131,NSP13#..CBU |
1 | ||
| 72630-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640A - LOCK ASSY, REAR SEAT BACK, LH | ||||
| 72640-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640-52130 |
NCP131,NSP13#..CBU |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12080 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 73705 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, RH | ||||
| 73705-52180 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| 73706 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, LH | ||||
| 73706-52020 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| Common parts | ||||
| 90105-10496 | ||||
| 90119-10578 | ||||
| 90119-10945 | ||||
| 91551-80820 | ||||
| 91551-80835 | ||||
| 91553-80820 | ||||
(1301- )5F..RS ; (1301- )JEWL..HTWCB ; (1301- )KSP130,NCP131..F,GRS,JEWL
ｲｯﾀｲｶﾄｳｼｷ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71601A - PAD SUB-ASSY, REAR SEAT CUSHION W/COVER | ||||
| 71601-52P00B1 |
NCP131,NSP130..U..CBU GRAY,TRIM1# |
1 | ||
| 71601-52P20C1 |
NCP131..CVT..RS BLACK,TRIM1# |
1 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71931A - SUPPORT, REAR SEAT HEADREST | ||||
| 71931-47010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
2 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71930-44020C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
2 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71990-52010C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ付,BLACK,TRIM1# |
3 | ||
| 71970-52030C0 |
NCP131,NSP13#..(RS,U)..CBU ﾛｯｸ無,BLACK,TRIM1# |
3 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940A - HEADREST ASSY, REAR SEAT | ||||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..CVT..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C20B2 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
2 | ||
| 71940-52C40B1 |
NCP131..RS DARK GRAY,TRIM1# |
2 | ||
| 71960B - HEADREST ASSY, REAR SEAT, CENTER | ||||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52580B3 |
NCP131..RS DARK GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 71960-52830B1 |
NCP131,NSP13#..U..CBU GRAY,TRIM1# |
1 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72601B - STRIKER SUB-ASSY, REAR SEAT BACK LOCK | ||||
| 72601-52220 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72630C - LOCK ASSY, REAR SEAT BACK, RH | ||||
| 72630-52140 |
KSP130,NCP131,NSP13#..CBU |
1 | ||
| 72630-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU |
1 | ||
| 72630-52141 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640A - LOCK ASSY, REAR SEAT BACK, LH | ||||
| 72640-52170 |
KSP130,NCP131,NSP13#..CBU PNC 72661C=TYPE B |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU PNC 72661C=TYPE A |
1 | ||
| 72640-52130 |
NCP131,NSP13#..CBU |
1 | ||
| 72640-52131 |
NCP131,NSP13#..CBU |
1 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72646 - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-33010C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE A |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,PNC 72661C=TYPE B |
2 | ||
| 72646-33010C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72646-33010C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72661C - BUTTON, REAR SEAT BACK LOCK RELEASE | ||||
| 72661-32030C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72661-32030C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE A:ｲﾗｽﾄ参照 |
2 | ||
| 72661-52050C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1#,TYPE B:ｲﾗｽﾄ参照 |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12080 |
KSP130,NCP131,NSP13#..CBU |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996A - COVER, REAR SEAT BACK | ||||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS SRSｴｱﾊﾞｯｸﾞ−有り(*DRS & *PAS & ｻｲﾄﾞ & *CUSA),BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..U..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131..RS BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 72996-12320C0 |
NCP131,NSP13#..(RS,U)..CBU BLACK,TRIM1# |
2 | ||
| 73705 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, RH | ||||
| 73705-52180 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| 73706 - BRACKET SUB-ASSY, CHILD RESTRAINT SEAT ANCHOR, LH | ||||
| 73706-52020 |
KSP130,NCP131,NSP130..CBU |
1 | ||
| Common parts | ||||
| 90105-10496 | ||||
| 90119-10578 | ||||
| 90119-10945 | ||||
| 91551-80820 | ||||
| 91551-80835 | ||||
| 91553-80820 | ||||
(1012- )
ｼｰﾄｶﾊﾞｰｴｯｼﾞﾜｲﾔ & ﾎｸﾞﾘﾝｸﾞ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 71149-30050 | ||||
| 90468-16019 | ||||
| 90468-18008 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
