SV55G-BWSSK (2000)
Toyota Vista/Vista Ardeo
(9806-0204)SV55
U240F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33621D - LABEL, TRANSAXLE OIL INFORMATION | ||||
| 33621-16060 |
AZV55,SV55 |
1 | ||
| 35111C - HOUSING, TRANSAXLE | ||||
| 35105-32030 |
SV55 |
1 | ||
| 35174 - SEPARATOR, TRANSAXLE HOUSING OIL | ||||
| 35174-32020 |
SV55 |
1 | ||
| 41141H - SEAL, OIL(FOR DIFFERENTIAL SIDE BEARING RETAINER) | ||||
| 90311-49002 |
SV55 |
1 | ||
| 41181E - PLUG (FOR FRONT DIFFERENTIAL DRAIN) | ||||
| 90341-18021 |
SV5#,ZZV50 |
1 | ||
| 41181G - GASKET (FOR FRONT DIFFERENTIAL DRAIN PLUG) | ||||
| 90430-18008 |
SV5#,ZZV50 |
1 | ||
| 41211 - PINION, DIFFERENTIAL DRIVE | ||||
| 41211-32150 |
SV55 |
1 | ||
| 41221 - GEAR, FRONT DIFFERENTIAL RING | ||||
| 41221-32160 |
SV55 |
1 | ||
| 41301P - SCREW(FOR FRONT DIFFERENTIAL CASE) | ||||
| 90105-12303 |
SV55 |
12 | ||
| 41311 - CASE, FRONT DIFFERENTIAL | ||||
| 41301-32090 |
SV55 |
1 | ||
| 41311C - SHIM (FOR FRONT DIFFERENTIAL CASE REAR) | ||||
| 90564-49021 |
SV5#,ZZV50 厚さ=2.95,ﾏｰｸ 1 |
1 | ||
| 90564-49024 |
SV5#,ZZV50 厚さ=3.10,ﾏｰｸ 4 |
1 | ||
| 90564-49023 |
SV5#,ZZV50 厚さ=3.05,ﾏｰｸ 3 |
1 | ||
| 90564-49027 |
SV5#,ZZV50 厚さ=3.25,ﾏｰｸ 7 |
1 | ||
| 90564-49026 |
SV5#,ZZV50 厚さ=3.20,ﾏｰｸ 6 |
1 | ||
| 90564-49022 |
SV5#,ZZV50 厚さ=3.00,ﾏｰｸ 2 |
1 | ||
| 90564-49029 |
SV5#,ZZV50 厚さ=3.35,ﾏｰｸ 9 |
1 | ||
| 90564-49020 |
SV5#,ZZV50 厚さ=2.90,ﾏｰｸ 0 |
1 | ||
| 90564-49030 |
SV5#,ZZV50 厚さ=3.40,ﾏｰｸ A |
1 | ||
| 90564-49028 |
SV5#,ZZV50 厚さ=3.30,ﾏｰｸ 8 |
1 | ||
| 90564-49036 |
SV5#,ZZV50 厚さ=3.70,ﾏｰｸ G |
1 | ||
| 90564-49033 |
SV5#,ZZV50 厚さ=3.55,ﾏｰｸ D |
1 | ||
| 90564-49025 |
SV5#,ZZV50 厚さ=3.15,ﾏｰｸ 5 |
1 | ||
| 90564-49034 |
SV5#,ZZV50 厚さ=3.60,ﾏｰｸ E |
1 | ||
| 90564-49027 |
SV5# 厚さ=3.25,ﾏｰｸ 7 |
1 | ||
| 90564-49024 |
SV5# 厚さ=3.10,ﾏｰｸ 4 |
1 | ||
| 90564-49032 |
SV5#,ZZV50 厚さ=3.50,ﾏｰｸ C |
1 | ||
| 90564-49020 |
SV5# 厚さ=2.90,ﾏｰｸ 0 |
1 | ||
| 90564-49021 |
SV5# 厚さ=2.95,ﾏｰｸ 1 |
1 | ||
| 90564-49038 |
SV5#,ZZV50 厚さ=3.80,ﾏｰｸ J |
1 | ||
| 90564-49028 |
SV5# 厚さ=3.30,ﾏｰｸ 8 |
1 | ||
| 90564-49022 |
SV5# 厚さ=3.00,ﾏｰｸ 2 |
1 | ||
| 90564-49029 |
SV5# 厚さ=3.35,ﾏｰｸ 9 |
1 | ||
| 90564-49037 |
SV5#,ZZV50 厚さ=3.75,ﾏｰｸ H |
1 | ||
| 90564-49025 |
SV5# 厚さ=3.15,ﾏｰｸ 5 |
1 | ||
| 90564-49030 |
SV5# 厚さ=3.40,ﾏｰｸ A |
1 | ||
| 90564-49033 |
SV5# 厚さ=3.55,ﾏｰｸ D |
1 | ||
| 90564-49023 |
SV5# 厚さ=3.05,ﾏｰｸ 3 |
1 | ||
| 90564-49038 |
SV5# 厚さ=3.80,ﾏｰｸ J |
1 | ||
| 90564-49035 |
SV5# 厚さ=3.65,ﾏｰｸ F |
1 | ||
| 90564-49034 |
SV5# 厚さ=3.60,ﾏｰｸ E |
1 | ||
| 90564-49031 |
SV5#,ZZV50 厚さ=3.45,ﾏｰｸ B |
1 | ||
| 90564-49032 |
SV5# 厚さ=3.50,ﾏｰｸ C |
1 | ||
| 90564-49036 |
SV5# 厚さ=3.70,ﾏｰｸ G |
1 | ||
| 90564-49037 |
SV5# 厚さ=3.75,ﾏｰｸ H |
1 | ||
| 90564-49035 |
SV5#,ZZV50 厚さ=3.65,ﾏｰｸ F |
1 | ||
| 90564-49031 |
SV5# 厚さ=3.45,ﾏｰｸ B |
1 | ||
| 90564-49026 |
SV5# 厚さ=3.20,ﾏｰｸ 6 |
1 | ||
| 41311E - BEARING, TAPERED ROLLER (FOR FRONT DIFFERENTIAL CASE FR | ||||
| 90366-50045 |
AZV55,SV55 |
1 | ||
| 41311F - BEARING, TAPERED ROLLER (FOR FRONT DIFFERENTIAL CASE RE | ||||
| 90366-44001 |
AZV5#,SV5#,ZZV50 |
1 | ||
| 41331F - GEAR, FRONT DIFFERENTIAL SIDE | ||||
| 41331-32010 |
AZV5#,SV5#,ZZV50 |
2 | ||
| 41331F - GEAR, FRONT DIFFERENTIAL SIDE | ||||
| 41331-32010 |
AZV5#,SV5#,ZZV50 |
2 | ||
| 41341F - PINION, FRONT DIFFERENTIAL | ||||
| 41341-30011 |
AZV5#,SV5#,ZZV50 |
2 | ||
| 41341F - PINION, FRONT DIFFERENTIAL | ||||
| 41341-30011 |
AZV5#,SV5#,ZZV50 |
2 | ||
| 41342A - PIN, STRAIGHT (FOR FRONT DIFFERENTIAL PINION SHAFT) | ||||
| 90250-06058 |
AZV5#,SV5#,ZZV50 |
1 | ||
| 41342F - SHAFT, FRONT DIFFERENTIAL PINION, NO.1 | ||||
| 41342-32030 |
SV55 |
1 | ||
| 41351F - WASHER, FRONT DIFFERENTIAL PINION THRUST | ||||
| 41351-32010 |
AZV5#,SV5#,ZZV50 |
2 | ||
| 41351F - WASHER, FRONT DIFFERENTIAL PINION THRUST | ||||
| 41351-32010 |
AZV5#,SV5#,ZZV50 |
2 | ||
| 41361F - WASHER, FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-17040 |
AZV5#,SV5#,ZZV50 厚さ=1.10 |
2 | ||
| 41361-17010 |
AZV5#,SV5#,ZZV50 厚さ=0.95 |
2 | ||
| 41361-17020 |
AZV5#,SV5#,ZZV50 厚さ=1.00 |
2 | ||
| 41361-17030 |
AZV5#,SV5#,ZZV50 厚さ=1.05 |
2 | ||
| 41361-17050 |
AZV5#,SV5#,ZZV50 厚さ=1.15 |
2 | ||
| 41361-17060 |
AZV5#,SV5#,ZZV50 厚さ=1.20 |
2 | ||
| 41361F - WASHER, FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-17040 |
AZV5#,SV5#,ZZV50 厚さ=1.10 |
2 | ||
| 41361-17010 |
AZV5#,SV5#,ZZV50 厚さ=0.95 |
2 | ||
| 41361-17020 |
AZV5#,SV5#,ZZV50 厚さ=1.00 |
2 | ||
| 41361-17030 |
AZV5#,SV5#,ZZV50 厚さ=1.05 |
2 | ||
| 41361-17050 |
AZV5#,SV5#,ZZV50 厚さ=1.15 |
2 | ||
| 41361-17060 |
AZV5#,SV5#,ZZV50 厚さ=1.20 |
2 | ||
| Common parts | ||||
| 90105-06030 | ||||
| Linked diagrams | ||||
| 4302 | ||||
