RY20-JDLHT (1979)

Toyota Toyoace

Production Mar 1979 - Jan 1982
Engine 12R
Transmission
Displacement 2500cc
Power 168 HP (125 kW)

(7903- )

Click highlighted areas on diagram

diagram 74518 74519 74527 74533 74534 74541 74543B 74548 74552 74556 74562 74563 74565 74565 74571 74574 74581
Part # Description Qty Price
74518 - PLATE, MAINTENANCE CAUTION
74518-22021

BY30,JY30,LY20,RY20,31

 1
74519 - PLATE, FUEL CAUTION
74559-14010

RY2#,3#

 1
74541 - PLATE, TIRE PRESSURE CAUTION
74552-25240

RY31..VT;LY20,RY20..WT..125

 1
74562 - PLATE, EMISSION CONTROL SYSTEM INFORMATION
74562-25030

RY20

 1
74565 - PLATE, TIRE CARRIER CAUTION
74544-35050

LY2#,3#,RY2#,3#..WT

 2
74586-25010

JY30,LY2#,3#,RY2#,3#..TR..WT

RR WHEEL

 1
74585-25010

JY30,LY2#,3#,RY2#,3#..TR..WT

FR WHEEL

 1
74565 - PLATE, TIRE CARRIER CAUTION
74544-35050

LY2#,3#,RY2#,3#..WT

 2
74586-25010

JY30,LY2#,3#,RY2#,3#..TR..WT

RR WHEEL

 1
74585-25010

JY30,LY2#,3#,RY2#,3#..TR..WT

FR WHEEL

 1
74571 - PLATE, BRAKE FLUID CAUTION
74571-27011

BY30,JY30,LY20,30,RY2#,3#

 1
75318-95A00

BY3#,JY30,LY2#,3#,RY2#,3#

OUTER

 1
