LY30-QDD (1979)

Toyota Toyoace

Production Mar 1979 - Aug 1983
Engine L
Transmission
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 1 OF 2(7903- )TR

Click highlighted areas on diagram

diagram 65240 65311 6553 66010 66020 66223 66241 66271 66321 9015050005 9017905095 9017906164 9111140614 9152140820 9165140616 9165140616 9165140616
Part # Description Qty Price
65240 - CROSSMEMBER, REAR BODY FLOOR, TAIL
65240-92201

LY2#,3#,RY2#,3#..TB..ST

 1
66010 - FENDER ASSY, REAR BODY, REAR RH
66203-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66020 - FENDER ASSY, REAR BODY, REAR LH
66204-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66223 - STAY, REAR FENDER REAR PLATE
66217-92200

JY30,LY20,30,RY20,31..TB..ST

 2
66241 - MUDGUARD, REAR
66241-92700

JY30,LY20,30,RY2#,3#..TB..ST

 2
Common parts
90150-50005
90179-05095
90179-06164
91111-40614
91521-40820
91651-40616
Linked diagrams
6553

ILLUST NO. 1 OF 2(7903- )T3..TB

Click highlighted areas on diagram

diagram 65240 65240 65301 65357 65357 66010 66010 66010 66020 66020 66020 66210 66210 66213 66213 66220 66220 66223 66223 66223 66241 66241 66241 66271 9011906094 9011906094 9017906158 9017906158 9017908146 9017908146 9017908146 9020106158 9111140614 9111140614 9111140614 9111150820 9111150820 9161640614 9161640614 9161640614 9161640614 9165640616 9165640616 9321018018 9321018018 9331216014 9331216014 9331216064 9354016016 9354016016 9359016016 9359016016 9411040600 9451100600 9451100600 9451100600 9461310600 9461410800 9461410800
Part # Description Qty Price
65240 - CROSSMEMBER, REAR BODY FLOOR, TAIL
65240-92201

LY2#,3#,RY2#,3#..TB..ST

 1
65240 - CROSSMEMBER, REAR BODY FLOOR, TAIL
65240-92201

LY2#,3#,RY2#,3#..TB..ST

 1
66010 - FENDER ASSY, REAR BODY, REAR RH
66203-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66010 - FENDER ASSY, REAR BODY, REAR RH
66203-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66010 - FENDER ASSY, REAR BODY, REAR RH
66203-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66020 - FENDER ASSY, REAR BODY, REAR LH
66204-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66020 - FENDER ASSY, REAR BODY, REAR LH
66204-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66020 - FENDER ASSY, REAR BODY, REAR LH
66204-92701

JY30,LY20,30,RY20,31..TB..ST

 1
66210 - FENDER ASSY, REAR BODY, FRONT RH
66201-92702

JY30,LY2#,3#,RY2#,3#..TB..ST

 1
66210 - FENDER ASSY, REAR BODY, FRONT RH
66201-92702

JY30,LY2#,3#,RY2#,3#..TB..ST

 1
66220 - FENDER ASSY, REAR BODY, FRONT LH
66202-92702

JY30,LY2#,3#,RY2#,3#..TB..ST

 1
66220 - FENDER ASSY, REAR BODY, FRONT LH
66202-92702

JY30,LY2#,3#,RY2#,3#..TB..ST

 1
66223 - STAY, REAR FENDER REAR PLATE
66217-92200

JY30,LY20,30,RY20,31..TB..ST

 2
66223 - STAY, REAR FENDER REAR PLATE
66217-92200

JY30,LY20,30,RY20,31..TB..ST

 2
66223 - STAY, REAR FENDER REAR PLATE
66217-92200

JY30,LY20,30,RY20,31..TB..ST

 2
66241 - MUDGUARD, REAR
66241-92700

JY30,LY20,30,RY2#,3#..TB..ST

 2
66241 - MUDGUARD, REAR
66241-92700

JY30,LY20,30,RY2#,3#..TB..ST

 2
66241 - MUDGUARD, REAR
66241-92700

JY30,LY20,30,RY2#,3#..TB..ST

 2
Common parts
90119-06094
90179-06158
90179-08146
90201-06158
91111-40614
91111-50820
91616-40614
91656-40616
93210-18018
93312-16014
93312-16064
93540-16016
93590-16016
94110-40600
94511-00600
94613-10600
94614-10800
