YY61-MDPGTJ3 (1985)

Toyota Toyoace/Dyna

Production Aug 1985 - Aug 1987
Engine 3Y
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 1 OF 2(8508- )T1

Click highlighted areas on diagram

diagram 65100 65240 65311 66210 66220 66241 66242 66321 9011906094 9015050005 9017905095 9017906164 9165140616
Part # Description Qty Price
66210 - FENDER ASSY, REAR BODY, FRONT RH
66010-92202

LY50,60,YY52,61..TB..WT1

 1
66220 - FENDER ASSY, REAR BODY, FRONT LH
66020-92202

LY50,60,YY52,61..TB..WT1

 1
66241 - MUDGUARD, REAR
66241-92205

LY50,60,YY52,61..TOY..TB..WT1

RH

 1
66241-92204

LY50,60,YY52,61..TOY..TB..WT1

LH

 1
66242 - PLATE, REAR MUDGUARD SET RETAINER
66242-92202

LY50,60,YY52,61..TB..WT1

RH

 1
66242-92201

LY50,60,YY52,61..TB..WT1

LH

 1
66321 - BUMPER, GATE RUBBER
66321-92200

LY50,60,YY52,61..TB..(ST,WT1)

SIDE

 4
66321-92704

LY50,60,YY52,61..TB..(ST,WT1)

RR

 2
66321-92805

LY50,60,YY52,61..TB

RR

 2
Common parts
90119-06094
90150-50005
90179-05095
90179-06164
91651-40616

ILLUST NO. 1 OF 2(8508- )LY60,YY61..125..WT1

Click highlighted areas on diagram

diagram 65026 65027 65241 65303A 65304A 65307 65307A 65308 65635B 66010 66020 66210 66213 66220 66223 66241 66242 66321 66321 66321 7554 9014980008 9014980008 9015180007 9015180007 9017906070 9017908024 9020108019 9161640614 9161640614 9162140616 9162140855 9165140612 9165640616 9321016014 9321016014 9321016014 9358016016 9358016016 9418040800 9418040800
Part # Description Qty Price
65026 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, RH
65026-92801

LY50,60,YY52,61..TB..(WT1,WT2)

 1
65026-92203

LY50,60,YY52,61..TB..(WT1,WT2)

 1
65027 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, LH
65027-92801

LY50,60,YY52,61..TB..(WT1,WT2)

 1
65027-92203

LY50,60,YY52,61..TB..(WT1,WT2)

 1
65241 - SILL, REAR CROSS
65241-92206

LY50,60,YY52,61..TB..(WT1,WT2)

 1
65303A - FRAME SUB-ASSY, FLOOR SIDE, RH
65303-92213

LY60,YY61..125..WT1

 1
65304A - FRAME SUB-ASSY, FLOOR SIDE, LH
65304-92214

LY60,YY61..125..WT1

 1
65307 - BRACKET SUB-ASSY, GUAD FRAME, RH
65207-92701

LY50,60,YY52,61..TB

 1
65307A - FRAME SUB-ASSY, FLOOR, REAR
65307-92203

LY50,60,YY52,61..TB..WT1

 1
65307-92204

LY50,60,YY52,61..TB..WT1

 1
65308 - BRACKET SUB-ASSY, GUAD FRAME, LH
65208-92701

LY50,60,YY52,61..TB

 1
65635B - BOLT, COUNTER SUNK HEAD SQUARE NECK
65635-92830

LY50,60,YY52,61..TB..(WT1,WT2)

 8
66010 - FENDER ASSY, REAR BODY, REAR RH
66210-92203

LY50,60,YY52,61..TB..WT1

 1
66020 - FENDER ASSY, REAR BODY, REAR LH
66220-92202

LY50,60,YY52,61..TB..WT1

 1
66210 - FENDER ASSY, REAR BODY, FRONT RH
66010-92202

LY50,60,YY52,61..TB..WT1

 1
66213 - STAY, REAR FENDER FRONT PLATE
66236-92202

LY50,60,YY52,61..TB..WT1

 2
66236-92200

LY50,60,YY61..TB..(WT1,WT2)

 2
66220 - FENDER ASSY, REAR BODY, FRONT LH
66020-92202

LY50,60,YY52,61..TB..WT1

 1
66223 - STAY, REAR FENDER REAR PLATE
66235-92201

LY50,60,YY52,61..TB..WT1

 2
66235-92202

LY50,60,YY52,61..TB..(WT1,WT2)

 2
66241 - MUDGUARD, REAR
66241-92205

LY50,60,YY52,61..TOY..TB..WT1

RH

 1
66241-92204

LY50,60,YY52,61..TOY..TB..WT1

LH

 1
66242 - PLATE, REAR MUDGUARD SET RETAINER
66242-92202

LY50,60,YY52,61..TB..WT1

RH

 1
66242-92201

LY50,60,YY52,61..TB..WT1

LH

 1
66321 - BUMPER, GATE RUBBER
66321-92200

LY50,60,YY52,61..TB..(ST,WT1)

SIDE

 4
66321-92704

LY50,60,YY52,61..TB..(ST,WT1)

RR

 2
66321-92805

LY50,60,YY52,61..TB

RR

 2
66321 - BUMPER, GATE RUBBER
66321-92200

LY50,60,YY52,61..TB..(ST,WT1)

SIDE

 4
66321-92704

LY50,60,YY52,61..TB..(ST,WT1)

RR

 2
66321-92805

LY50,60,YY52,61..TB

RR

 2
66321 - BUMPER, GATE RUBBER
66321-92200

LY50,60,YY52,61..TB..(ST,WT1)

SIDE

 4
66321-92704

LY50,60,YY52,61..TB..(ST,WT1)

RR

 2
66321-92805

LY50,60,YY52,61..TB

RR

 2
Common parts
90149-80008
90151-80007
90179-06070
90179-08024
90201-08019
91616-40614
91621-40616
91621-40855
91651-40612
91656-40616
93210-16014
93580-16016
94180-40800
Linked diagrams
7554

ILLUST NO. 2 OF 2(8508- )

Click highlighted areas on diagram

diagram 66311A
Part # Description Qty Price
66311A - HOOK, ROPE, NO.1
66313-92701

LY50,60,YY52,61..TB

TYPE C

 10
66312-92702

LY50,60,YY52,61..TB

TYPE B

 8
66313-92201

LY50,60,YY52,61..TB

TYPE D

 2
66314-92201

LY50,60,YY52,61..TB

TYPE E

 2
66315-92832

LY50,60,YY52,61..TB..(WT1,WT2)

TYPE F

 3
