LY50-MDPMJ (1987)
Toyota Toyoace/Dyna
(8708-8808)2L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-54440 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54510 |
2L,3L..LY50,61..TW |
1 | ||
| 23301-54120 |
2L..LY50,60..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23380-54650 |
2L,3L..LY50,61..TW |
1 | ||
| 23380-54590 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54110 |
2L..LY50,60..TW |
1 | ||
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-54440 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54510 |
2L,3L..LY50,61..TW |
1 | ||
| 23301-54120 |
2L..LY50,60..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23380-54650 |
2L,3L..LY50,61..TW |
1 | ||
| 23380-54590 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54110 |
2L..LY50,60..TW |
1 | ||
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-54440 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54510 |
2L,3L..LY50,61..TW |
1 | ||
| 23301-54120 |
2L..LY50,60..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23380-54650 |
2L,3L..LY50,61..TW |
1 | ||
| 23380-54590 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54110 |
2L..LY50,60..TW |
1 | ||
| 23303 - ELEMENT SUB-ASSY, FUEL FILTER | ||||
| 23303-64010 |
2L,3L..LY5#,6# |
1 | ||
| 23322 - PLUG, DRAIN(FOR FUEL FILTER) | ||||
| 23322-64010 |
2L,3L..LY5#,6# |
1 | ||
| 23322A - RING, O(FOR DRAIN PLUG) | ||||
| 23344-54010 |
2L,3L..LY5#,6# |
1 | ||
| 23338 - GASKET(FOR WARNING SWITCH) | ||||
| 23344-64010 |
2L,3L..LY5#,6# |
1 | ||
| 23921 - SUPPORT, FUEL FILTER | ||||
| 23921-54220 |
2L,3L..LY50,6#..TW |
1 | ||
| 23921 - SUPPORT, FUEL FILTER | ||||
| 23921-54220 |
2L,3L..LY50,6#..TW |
1 | ||
| Common parts | ||||
| 23338-54020 | ||||
| 23344-54030 | ||||
| 90179-08038 | ||||
| 90179-10015 | ||||
| 90560-09012 | ||||
| 91611-60840 | ||||
| 91611-61020 | ||||
| 91655-40820 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(8808- )2L,3L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-54440 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54510 |
2L,3L..LY50,61..TW |
1 | ||
| 23301-54120 |
2L..LY50,60..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23380-54650 |
2L,3L..LY50,61..TW |
1 | ||
| 23380-54590 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54110 |
2L..LY50,60..TW |
1 | ||
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-54440 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54510 |
2L,3L..LY50,61..TW |
1 | ||
| 23301-54120 |
2L..LY50,60..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23380-54650 |
2L,3L..LY50,61..TW |
1 | ||
| 23380-54590 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54110 |
2L..LY50,60..TW |
1 | ||
| 23301A - CAP ASSY, FUEL FILTER | ||||
| 23301-54440 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54510 |
2L,3L..LY50,61..TW |
1 | ||
| 23301-54120 |
2L..LY50,60..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23380-54650 |
2L,3L..LY50,61..TW |
1 | ||
| 23380-54590 |
2L,3L..LY50,61..TW ｱﾘ(ﾌﾕ-ｴﾙ ﾋ-ﾀ) |
1 | ||
| 23301-54110 |
2L..LY50,60..TW |
1 | ||
| 23303 - ELEMENT SUB-ASSY, FUEL FILTER | ||||
| 23303-64010 |
2L,3L..LY5#,6# |
1 | ||
| 23322 - PLUG, DRAIN(FOR FUEL FILTER) | ||||
| 23322-64010 |
2L,3L..LY5#,6# |
1 | ||
| 23322A - RING, O(FOR DRAIN PLUG) | ||||
| 23344-54010 |
2L,3L..LY5#,6# |
1 | ||
| 23338 - GASKET(FOR WARNING SWITCH) | ||||
| 23344-64010 |
2L,3L..LY5#,6# |
1 | ||
| 23910B - HEATER ASSY, FUEL | ||||
| 23910-54050 |
2L,3L..LY5#,61 |
1 | ||
| 23910-64010 |
2L..LY50 |
1 | ||
| 23921 - SUPPORT, FUEL FILTER | ||||
| 23921-54220 |
2L,3L..LY50,6#..TW |
1 | ||
| 23921 - SUPPORT, FUEL FILTER | ||||
| 23921-54220 |
2L,3L..LY50,6#..TW |
1 | ||
| Common parts | ||||
| 23347-54010 | ||||
| 90179-08009 | ||||
| 90179-10015 | ||||
| 90560-09012 | ||||
| 91611-60840 | ||||
| 91611-61016 | ||||
| 91655-40820 | ||||
| 93319-15008 | ||||
| Linked diagrams | ||||
| 8401 | ||||
