LY50-MDD (1985)
Toyota Toyoace/Dyna
ILLUST NO. 1 OF 2(8508- )TB..ST
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 65026 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, RH | ||||
| 65026-92704 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 65026-92705 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 65027 - BRACKET SUB-ASSY, GATE RUBBER BUMPER, LH | ||||
| 65027-92705 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 65027-92704 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 65240 - CROSSMEMBER, REAR BODY FLOOR, TAIL | ||||
| 65240-92207 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 65303A - FRAME SUB-ASSY, FLOOR SIDE, RH | ||||
| 65303-92209 |
LY50,YY52..15T..ST |
1 | ||
| 65303-92214 |
LY50,YY52..15T..ST |
1 | ||
| 65304A - FRAME SUB-ASSY, FLOOR SIDE, LH | ||||
| 65304-92209 |
LY50,YY52..15T..ST |
1 | ||
| 65304-92215 |
LY50,YY52..15T..ST |
1 | ||
| 65307 - BRACKET SUB-ASSY, GUAD FRAME, RH | ||||
| 65207-92701 |
LY50,60,YY52,61..TB |
1 | ||
| 65308 - BRACKET SUB-ASSY, GUAD FRAME, LH | ||||
| 65208-92701 |
LY50,60,YY52,61..TB |
1 | ||
| 65339 - FRAME, FLOOR, REAR | ||||
| 65339-92701 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 65339-92700 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 66010 - FENDER ASSY, REAR BODY, REAR RH | ||||
| 66210-92705 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 66020 - FENDER ASSY, REAR BODY, REAR LH | ||||
| 66220-92705 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 66210 - FENDER ASSY, REAR BODY, FRONT RH | ||||
| 66010-92701 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 66213 - STAY, REAR FENDER FRONT PLATE | ||||
| 66236-92702 |
LY50,60,YY52,61..TB..ST |
2 | ||
| 66220 - FENDER ASSY, REAR BODY, FRONT LH | ||||
| 66020-92701 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 66223 - STAY, REAR FENDER REAR PLATE | ||||
| 66235-92701 |
LY50,60,YY52,61..TB..ST |
2 | ||
| 66235-92200 |
LY50,60,YY52,61..TB..ST |
2 | ||
| 66241 - MUDGUARD, REAR | ||||
| 66241-92702 |
LY50,60,YY52,61..DYN..TB..ST |
2 | ||
| 66242 - PLATE, REAR MUDGUARD SET RETAINER | ||||
| 66242-92705 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 66271 - STEP, REAR BODY | ||||
| 66271-92701 |
LY50,60,YY52,61..TB..ST |
1 | ||
| 66321 - BUMPER, GATE RUBBER | ||||
| 66321-92200 |
LY50,60,YY52,61..TB..(ST,WT1) SIDE |
4 | ||
| 66321-92704 |
LY50,60,YY52,61..TB..(ST,WT1) RR |
2 | ||
| 66321-92805 |
LY50,60,YY52,61..TB RR |
2 | ||
| 66321 - BUMPER, GATE RUBBER | ||||
| 66321-92200 |
LY50,60,YY52,61..TB..(ST,WT1) SIDE |
4 | ||
| 66321-92704 |
LY50,60,YY52,61..TB..(ST,WT1) RR |
2 | ||
| 66321-92805 |
LY50,60,YY52,61..TB RR |
2 | ||
| 66321 - BUMPER, GATE RUBBER | ||||
| 66321-92200 |
LY50,60,YY52,61..TB..(ST,WT1) SIDE |
4 | ||
| 66321-92704 |
LY50,60,YY52,61..TB..(ST,WT1) RR |
2 | ||
| 66321-92805 |
LY50,60,YY52,61..TB RR |
2 | ||
| Common parts | ||||
| 90119-06323 | ||||
| 90149-80008 | ||||
| 90151-80007 | ||||
| 90159-60281 | ||||
| 91611-40820 | ||||
| 91616-40614 | ||||
| 91621-40614 | ||||
| 91651-40612 | ||||
| 93210-16014 | ||||
| 93580-16016 | ||||
| 94110-40800 | ||||
| 94180-40800 | ||||
ILLUST NO. 2 OF 2(8508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 66311A - HOOK, ROPE, NO.1 | ||||
| 66313-92701 |
LY50,60,YY52,61..TB TYPE C |
10 | ||
| 66312-92702 |
LY50,60,YY52,61..TB TYPE B |
8 | ||
| 66313-92201 |
LY50,60,YY52,61..TB TYPE D |
2 | ||
| 66314-92201 |
LY50,60,YY52,61..TB TYPE E |
2 | ||
| 66315-92201 |
LY50,60,YY52,61..TB..ST TYPE A |
3 | ||
| 66311-92703 |
LY50,60,YY52,61..TB..ST TYPE A |
3 | ||
