LY50-MDBMJ3 (1987)
Toyota Toyoace/Dyna
(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04371 - SPIDER KIT, UNIVERSAL JOINT(FOR PROPELLER SHAFT) | ||||
| 04371-25010 |
LY50,YY51..125 |
2 | ||
| 04371-30021 |
LY50 |
2 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01151 |
LY5#,6#,YY5#,61 12G,長さ=24.9 |
1 | ||
| 90937-01152 |
LY5#,6#,YY5#,61 14G,長さ=29.0 |
1 | ||
| 90937-01150 |
LY5#,6#,YY5#,61 8G,長さ=16.6 |
1 | ||
| 90937-01148 |
LY5#,6#,YY5#,61 4G,厚さ=2.0 |
1 | ||
| 90937-01132 |
LY5#,6#,YY5#,61 10G,長さ=20.7 |
1 | ||
| 90937-01149 |
LY5#,6#,YY5#,61 6G,長さ=12.4 |
1 | ||
| 90937-01147 |
LY5#,6#,YY5#,61 2G,厚さ=2.0 |
1 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01151 |
LY5#,6#,YY5#,61 12G,長さ=24.9 |
1 | ||
| 90937-01152 |
LY5#,6#,YY5#,61 14G,長さ=29.0 |
1 | ||
| 90937-01150 |
LY5#,6#,YY5#,61 8G,長さ=16.6 |
1 | ||
| 90937-01148 |
LY5#,6#,YY5#,61 4G,厚さ=2.0 |
1 | ||
| 90937-01132 |
LY5#,6#,YY5#,61 10G,長さ=20.7 |
1 | ||
| 90937-01149 |
LY5#,6#,YY5#,61 6G,長さ=12.4 |
1 | ||
| 90937-01147 |
LY5#,6#,YY5#,61 2G,厚さ=2.0 |
1 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-26290 |
LY50,YY51..(T1,T3)..125 |
1 | ||
| 37110-26170 |
LY50..T1,T3,TW |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90105-10085 |
LY5#,6#,YY5#,61..ST,WT1 *10−1.00PX27−13 |
4 | ||
| 37110D - NUT (FOR PROPELLER SHAFT) | ||||
| 90179-10059 |
YY61..ATM;LY50,YY5#..10T,125 |
4 | ||
| 90179-10059 |
LY50,YY51..125 |
4 | ||
| 37110E - WASHER (FOR PROPELLER SHAFT) | ||||
| 90204-10002 |
LY50,YY51..125 |
4 | ||
| 90204-10002 |
YY61..ATM;LY50,YY5#..10T,125 |
4 | ||
| 37302 - YOKE SUB-ASSY, UNIVERSAL JOINT SLEEVE | ||||
| 37302-35030 |
LY50 |
1 | ||
| 37302-35010 |
LY50,YY51..125 |
1 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-35040 |
LY50 |
1 | ||
| 37315-35050 |
LY50,YY51..125 |
1 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
YY61..ATM;LY50,YY5#..10T,125 |
1 | ||
| 37331-30010 |
LY50,YY51..125 |
1 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29071 |
LY50,YY51..125 厚さ=2.425−2.475 |
8 | ||
| 90520-26038 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.125,ﾏｰｸ 1 |
8 | ||
| 90521-29070 |
LY50,YY51..125 厚さ=2.375−2.425 |
8 | ||
| 90520-26040 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.175,ﾏｰｸ 2 |
8 | ||
| 90520-26043 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.325,ﾏｰｸ 5 |
8 | ||
| 90520-26045 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.425,ﾏｰｸ 7 |
8 | ||
| 90520-26044 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.375,ﾏｰｸ 6 |
8 | ||
| 90521-29072 |
LY50,YY51..125 厚さ=2.475−2.525 |
8 | ||
| 90520-26046 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.475,ﾏｰｸ 8 |
8 | ||
| 90520-26042 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.275,ﾏｰｸ 4 |
8 | ||
| 90520-26041 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.225,ﾏｰｸ 3 |
8 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29071 |
LY50,YY51..125 厚さ=2.425−2.475 |
8 | ||
| 90520-26038 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.125,ﾏｰｸ 1 |
8 | ||
| 90521-29070 |
LY50,YY51..125 厚さ=2.375−2.425 |
8 | ||
| 90520-26040 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.175,ﾏｰｸ 2 |
8 | ||
| 90520-26043 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.325,ﾏｰｸ 5 |
8 | ||
| 90520-26045 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.425,ﾏｰｸ 7 |
8 | ||
| 90520-26044 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.375,ﾏｰｸ 6 |
8 | ||
| 90521-29072 |
LY50,YY51..125 厚さ=2.475−2.525 |
8 | ||
| 90520-26046 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.475,ﾏｰｸ 8 |
8 | ||
| 90520-26042 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.275,ﾏｰｸ 4 |
8 | ||
| 90520-26041 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.225,ﾏｰｸ 3 |
8 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25010 |
LY50,YY51..125 |
8 | ||
| 37402-25020 |
LY50,YY51..125 RED PAINTED |
8 | ||
| 37402-30011 |
YY52..15T;LY5#,61,YY61..MTM |
8 | ||
| 37402-30021 |
YY52..15T;LY5#,61,YY61..MTM RED PAINTED |
8 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25010 |
LY50,YY51..125 |
8 | ||
| 37402-25020 |
LY50,YY51..125 RED PAINTED |
8 | ||
| 37402-30011 |
YY52..15T;LY5#,61,YY61..MTM |
8 | ||
| 37402-30021 |
YY52..15T;LY5#,61,YY61..MTM RED PAINTED |
8 | ||
| 37434 - SEAL, UNIVERSAL JOINT SPIDER BEARING | ||||
| 37434-25010 |
LY50,YY51..125 |
8 | ||
| 37434 - SEAL, UNIVERSAL JOINT SPIDER BEARING | ||||
| 37434-25010 |
LY50,YY51..125 |
8 | ||
(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04371 - SPIDER KIT, UNIVERSAL JOINT(FOR PROPELLER SHAFT) | ||||
| 04371-25010 |
LY50,YY51..125 |
2 | ||
| 04371-30021 |
LY50 |
2 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01151 |
LY5#,6#,YY5#,61 12G,長さ=24.9 |
1 | ||
| 90937-01152 |
LY5#,6#,YY5#,61 14G,長さ=29.0 |
1 | ||
| 90937-01150 |
LY5#,6#,YY5#,61 8G,長さ=16.6 |
1 | ||
| 90937-01148 |
LY5#,6#,YY5#,61 4G,厚さ=2.0 |
1 | ||
| 90937-01132 |
LY5#,6#,YY5#,61 10G,長さ=20.7 |
1 | ||
| 90937-01149 |
LY5#,6#,YY5#,61 6G,長さ=12.4 |
1 | ||
| 90937-01147 |
LY5#,6#,YY5#,61 2G,厚さ=2.0 |
1 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01151 |
LY5#,6#,YY5#,61 12G,長さ=24.9 |
1 | ||
| 90937-01152 |
LY5#,6#,YY5#,61 14G,長さ=29.0 |
1 | ||
| 90937-01150 |
LY5#,6#,YY5#,61 8G,長さ=16.6 |
1 | ||
| 90937-01148 |
LY5#,6#,YY5#,61 4G,厚さ=2.0 |
1 | ||
| 90937-01132 |
LY5#,6#,YY5#,61 10G,長さ=20.7 |
1 | ||
| 90937-01149 |
LY5#,6#,YY5#,61 6G,長さ=12.4 |
1 | ||
| 90937-01147 |
LY5#,6#,YY5#,61 2G,厚さ=2.0 |
1 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-26290 |
LY50,YY51..(T1,T3)..125 |
1 | ||
| 37110-26170 |
LY50..T1,T3,TW |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90105-10085 |
LY5#,6#,YY5#,61..ST,WT1 *10−1.00PX27−13 |
4 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90105-10085 |
LY5#,6#,YY5#,61..ST,WT1 *10−1.00PX27−13 |
4 | ||
| 37110D - NUT (FOR PROPELLER SHAFT) | ||||
| 90179-10059 |
YY61..ATM;LY50,YY5#..10T,125 |
4 | ||
| 90179-10059 |
LY50,YY51..125 |
4 | ||
| 37110D - NUT (FOR PROPELLER SHAFT) | ||||
| 90179-10059 |
YY61..ATM;LY50,YY5#..10T,125 |
4 | ||
| 90179-10059 |
LY50,YY51..125 |
4 | ||
| 37110E - WASHER (FOR PROPELLER SHAFT) | ||||
| 90204-10002 |
LY50,YY51..125 |
4 | ||
| 90204-10002 |
YY61..ATM;LY50,YY5#..10T,125 |
4 | ||
| 37110E - WASHER (FOR PROPELLER SHAFT) | ||||
| 90204-10002 |
LY50,YY51..125 |
4 | ||
| 90204-10002 |
YY61..ATM;LY50,YY5#..10T,125 |
4 | ||
| 37302 - YOKE SUB-ASSY, UNIVERSAL JOINT SLEEVE | ||||
| 37302-35030 |
LY50 |
1 | ||
| 37302-35010 |
LY50,YY51..125 |
1 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-35040 |
LY50 |
1 | ||
| 37315-35050 |
LY50,YY51..125 |
1 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-35040 |
LY50 |
1 | ||
| 37315-35050 |
LY50,YY51..125 |
1 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
YY61..ATM;LY50,YY5#..10T,125 |
1 | ||
| 37331-30010 |
LY50,YY51..125 |
1 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29071 |
LY50,YY51..125 厚さ=2.425−2.475 |
8 | ||
| 90520-26038 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.125,ﾏｰｸ 1 |
8 | ||
| 90521-29070 |
LY50,YY51..125 厚さ=2.375−2.425 |
8 | ||
| 90520-26040 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.175,ﾏｰｸ 2 |
8 | ||
| 90520-26043 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.325,ﾏｰｸ 5 |
8 | ||
| 90520-26045 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.425,ﾏｰｸ 7 |
8 | ||
| 90520-26044 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.375,ﾏｰｸ 6 |
8 | ||
| 90521-29072 |
LY50,YY51..125 厚さ=2.475−2.525 |
8 | ||
| 90520-26046 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.475,ﾏｰｸ 8 |
8 | ||
| 90520-26042 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.275,ﾏｰｸ 4 |
8 | ||
| 90520-26041 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.225,ﾏｰｸ 3 |
8 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29071 |
LY50,YY51..125 厚さ=2.425−2.475 |
8 | ||
| 90520-26038 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.125,ﾏｰｸ 1 |
8 | ||
| 90521-29070 |
LY50,YY51..125 厚さ=2.375−2.425 |
8 | ||
| 90520-26040 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.175,ﾏｰｸ 2 |
8 | ||
| 90520-26043 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.325,ﾏｰｸ 5 |
8 | ||
| 90520-26045 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.425,ﾏｰｸ 7 |
8 | ||
| 90520-26044 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.375,ﾏｰｸ 6 |
8 | ||
| 90521-29072 |
LY50,YY51..125 厚さ=2.475−2.525 |
8 | ||
| 90520-26046 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.475,ﾏｰｸ 8 |
8 | ||
| 90520-26042 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.275,ﾏｰｸ 4 |
8 | ||
| 90520-26041 |
YY52..15T;LY5#,61,YY61..MTM 厚さ=2.225,ﾏｰｸ 3 |
8 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25010 |
LY50,YY51..125 |
8 | ||
| 37402-25020 |
LY50,YY51..125 RED PAINTED |
8 | ||
| 37402-30011 |
YY52..15T;LY5#,61,YY61..MTM |
8 | ||
| 37402-30021 |
YY52..15T;LY5#,61,YY61..MTM RED PAINTED |
8 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25010 |
LY50,YY51..125 |
8 | ||
| 37402-25020 |
LY50,YY51..125 RED PAINTED |
8 | ||
| 37402-30011 |
YY52..15T;LY5#,61,YY61..MTM |
8 | ||
| 37402-30021 |
YY52..15T;LY5#,61,YY61..MTM RED PAINTED |
8 | ||
| Common parts | ||||
| 96451-00600 | ||||
