GA70-BLPVF (1986)
Toyota Supra
(8602-8701)1GGEU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17110A - UNION, VACUUM HOSE | ||||
| 90406-04002 |
1GGEU..GA70 |
2 | ||
| 17111 - MANIFOLD, INTAKE | ||||
| 17101-70020 |
1GGEU..GA70 *53 |
1 | ||
| 17111-88303 |
1GGEU..GA70 |
1 | ||
| 17120-88302 |
1GGEU..GA70 *54 |
1 | ||
| 17118 - STAY, MANIFOLD | ||||
| 17118-88302 |
1GGEU..GA70 |
1 | ||
| 17119 - STAY, MANIFOLD, NO.2 | ||||
| 17139-88302 |
1GGEU..GA70 |
1 | ||
| 17139-88304 |
1GGEU..GA70 |
1 | ||
| 17129B - PLUG | ||||
| 96411-11600 |
1GG#..GA70 OD=16 |
1 | ||
| 96411-21600 |
1GG#..GA70 |
1 | ||
| 17129E - UNION, NO.3 | ||||
| 90404-51042 |
1GGEU..GA70 |
1 | ||
| 90404-51026 |
1GGEU..GA70 |
1 | ||
| 17129J - PLUG, TIGHT(FOR INTAKE AIR SURGE TANK) | ||||
| 90331-55001 |
1GGEU..GA70 OD=55,*53 |
1 | ||
| 96411-43000 |
1GGEU..GA70 外径=30,*54 |
2 | ||
| 96411-43500 |
1GGEU..GA70 外径=35,OD=35,*53 |
1 | ||
| 96411-33000 |
1GGEU..GA70 *54 |
2 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17141-88301 |
1GGEU..GA70 |
1 | ||
| 17141D - BOLT, STUD(FOR OXYGEN SENSOR) | ||||
| 90116-08187 |
1GG#..GA70 |
2 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 90116-10058 |
1GEU,1GG#..GA70 L=46.5,S=14&20 |
3 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD*54 |
7 | ||
| 90116-08224 |
1GGEU..GA70 INTAKE MANIFOLD*53 |
7 | ||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD |
7 | ||
| 90116-10063 |
1GG#..GA70 EXHAUST MANIFOLD |
9 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD*54 |
7 | ||
| 90116-08224 |
1GGEU..GA70 INTAKE MANIFOLD*53 |
7 | ||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD |
7 | ||
| 90116-10063 |
1GG#..GA70 EXHAUST MANIFOLD |
9 | ||
| 17167 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.1 | ||||
| 17167-88300 |
1GGEU..GA70 |
1 | ||
| 17168 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.2 | ||||
| 17168-88300 |
1GGEU..GA70 |
1 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88300 |
1GGEU..GA70 |
3 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88300 |
1GGEU..GA70 |
3 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88300 |
1GGEU..GA70 |
3 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17177-88301 |
1GG#..GA70 *54 |
1 | ||
| 17177-88300 |
1GGEU..GA70 *53 |
1 | ||
| 17177-88302 |
1GGEU..GA70 *54 |
1 | ||
| 17179A - GASKET, INTAKE MANIFOLD, NO.2 | ||||
| 17179-88302 |
1GGEU..GA70 |
1 | ||
| 17179-88301 |
1GGEU..GA70 |
1 | ||
| 17300 - VALVE ASSY, INTAKE AIR CONTROL | ||||
| 17300-88300 |
1GGEU..GA70 |
1 | ||
| 17300-88301 |
1GGEU..GA70 |
1 | ||
| Common parts | ||||
| 90116-06028 | ||||
| 90179-06082 | ||||
| 90179-08044 | ||||
| 90179-10037 | ||||
| 90253-11021 | ||||
| 91651-60612 | ||||
| 91651-60820 | ||||
(8701- )1GGEU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17110A - UNION, VACUUM HOSE | ||||
| 90406-04002 |
1GGEU..GA70 |
2 | ||
| 17111 - MANIFOLD, INTAKE | ||||
| 17101-70020 |
1GGEU..GA70 *53 |
1 | ||
| 17111-88303 |
1GGEU..GA70 |
1 | ||
| 17120-88302 |
1GGEU..GA70 *54 |
1 | ||
| 17118 - STAY, MANIFOLD | ||||
| 17118-88302 |
1GGEU..GA70 |
1 | ||
| 17119 - STAY, MANIFOLD, NO.2 | ||||
| 17139-88302 |
1GGEU..GA70 |
1 | ||
| 17139-88304 |
1GGEU..GA70 |
1 | ||
| 17125 - STAY, SURGE TANK, NO.1 | ||||
| 17125-88300 |
1GGEU..GA70 |
1 | ||
| 17129 - TANK, INTAKE AIR SURGE | ||||
| 17109-88300 |
1GGEU..GA70 |
1 | ||
| 17129B - PLUG | ||||
| 96411-11600 |
1GG#..GA70 OD=16 |
1 | ||
| 96411-21600 |
1GG#..GA70 |
1 | ||
| 17129E - UNION, NO.3 | ||||
| 90404-51042 |
1GGEU..GA70 |
1 | ||
| 90404-51026 |
1GGEU..GA70 |
1 | ||
| 17129J - PLUG, TIGHT(FOR INTAKE AIR SURGE TANK) | ||||
| 90331-55001 |
1GGEU..GA70 OD=55,*53 |
1 | ||
| 96411-43000 |
1GGEU..GA70 外径=30,*54 |
2 | ||
| 96411-43500 |
1GGEU..GA70 外径=35,OD=35,*53 |
1 | ||
| 96411-33000 |
1GGEU..GA70 *54 |
2 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17141-88301 |
1GGEU..GA70 |
1 | ||
| 17141D - BOLT, STUD(FOR OXYGEN SENSOR) | ||||
| 90116-08187 |
1GG#..GA70 |
2 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 90116-10058 |
1GEU,1GG#..GA70 L=46.5,S=14&20 |
3 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD*54 |
7 | ||
| 90116-08224 |
1GGEU..GA70 INTAKE MANIFOLD*53 |
7 | ||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD |
7 | ||
| 90116-10063 |
1GG#..GA70 EXHAUST MANIFOLD |
9 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD*54 |
7 | ||
| 90116-08224 |
1GGEU..GA70 INTAKE MANIFOLD*53 |
7 | ||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD |
7 | ||
| 90116-10063 |
1GG#..GA70 EXHAUST MANIFOLD |
9 | ||
| 17167 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.1 | ||||
| 17167-88300 |
1GGEU..GA70 |
1 | ||
| 17168 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.2 | ||||
| 17168-88300 |
1GGEU..GA70 |
1 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88300 |
1GGEU..GA70 |
3 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88300 |
1GGEU..GA70 |
3 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88300 |
1GGEU..GA70 |
3 | ||
| 17176 - GASKET, AIR SURGE TANK TO INTAKE MANIFOLD | ||||
| 17176-88300 |
1GGEU..GA70 |
1 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17177-88301 |
1GG#..GA70 *54 |
1 | ||
| 17177-88300 |
1GGEU..GA70 *53 |
1 | ||
| 17177-88302 |
1GGEU..GA70 *54 |
1 | ||
| 17179A - GASKET, INTAKE MANIFOLD, NO.2 | ||||
| 17179-88302 |
1GGEU..GA70 |
1 | ||
| 17179-88301 |
1GGEU..GA70 |
1 | ||
| 17300 - VALVE ASSY, INTAKE AIR CONTROL | ||||
| 17300-88300 |
1GGEU..GA70 |
1 | ||
| 17300-88301 |
1GGEU..GA70 |
1 | ||
| Common parts | ||||
| 90116-06064 | ||||
| 90116-06106 | ||||
| 90116-08245 | ||||
| 90119-06349 | ||||
| 90119-08249 | ||||
| 90119-08590 | ||||
| 90179-06082 | ||||
| 90179-08044 | ||||
| 90179-10037 | ||||
| 90253-11021 | ||||
| 90339-03005 | ||||
| 90929-01137 | ||||
| 91611-60612 | ||||
| 91651-60612 | ||||
| 91651-60820 | ||||
| 92122-60820 | ||||
