GA70-BLPVF (1988)
Toyota Supra
(8908- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69051 - CYLINDER & KEY SET, DOOR LOCK, RH | ||||
| 69051-14140 |
GA70 |
1 | ||
| 69055B - CYLINDER & KEY SET, BACK DOOR LOCK | ||||
| 69055-14311 |
GA70,JZA70,MA70 |
1 | ||
| 69055-14310 |
GA70,MA70 |
1 | ||
| 69388 - SNAP, ROD(FOR DOOR LOCK) | ||||
| 69759-30040 |
GA70,JZA70,MA70 右側 |
1 | ||
| 69759-30050 |
GA70,JZA70,MA70 左側 |
1 | ||
| 69388 - SNAP, ROD(FOR DOOR LOCK) | ||||
| 69759-30040 |
GA70,JZA70,MA70 右側 |
1 | ||
| 69759-30050 |
GA70,JZA70,MA70 左側 |
1 | ||
| 69388 - SNAP, ROD(FOR DOOR LOCK) | ||||
| 69759-30040 |
GA70,JZA70,MA70 右側 |
1 | ||
| 69759-30050 |
GA70,JZA70,MA70 左側 |
1 | ||
| 69503 - CYLINDER SET, LOCK | ||||
| 69005-1462113 |
GA70,JZA70..GT,GTT,GTTR SHADOW GRAY,TRIM1# |
1 | ||
| 69005-1462003 |
GA70 MEDIUM GRAY,TRIM1# |
1 | ||
| 69005-1462002 |
GA70 MAROON,TRIM3# |
1 | ||
| 69005-1462102 |
GA70,MA70..G,GT,GTT MAROON,TRIM3# |
1 | ||
| 69005-1462104 |
GA70,MA70..G,GT,GTT DEEP BLUE,TRIM8# |
1 | ||
| 69005-1462112 |
GA70,JZA70..GT,GTT DEEP RED,TRIM3# |
1 | ||
| 69005-1462004 |
GA70 DEEP BLUE,TRIM8# |
1 | ||
| 69005-1462103 |
GA70,MA70..G,GT,GTT MEDIUM GRAY,TRIM1# |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00094 |
GA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 90999-00106 |
GA70,MA70 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00085 |
GA70,MA70 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00174 |
GA70,JZA70..G,GT,GTT,GTTR ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00153 |
GA70,JZA70,MA70 |
1 | ||
| 90999-00154 |
GA70,JZA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00094 |
GA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 90999-00106 |
GA70,MA70 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00085 |
GA70,MA70 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00174 |
GA70,JZA70..G,GT,GTT,GTTR ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00153 |
GA70,JZA70,MA70 |
1 | ||
| 90999-00154 |
GA70,JZA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 69510 - CYLINDER ASSY, FRONT DOOR LOCK, RH | ||||
| 69510-14052 |
GA70,JZA70..G,GT,GTT,GTTR |
1 | ||
| 69520 - CYLINDER ASSY, FRONT DOOR LOCK, LH | ||||
| 69520-14062 |
GA70,JZA70,MA70 |
1 | ||
| 69550A - CYLINDER ASSY, GLOVE COMPARTMENT DOOR LOCK | ||||
| 69550-14051B0 |
GA70,JZA70,MA70 SHADOW GRAY,TRIM1# |
1 | ||
| 69555 - COVER, KEY | ||||
| 69555-20010 |
GA70,JZA70,MA70 |
1 | ||
| 69570 - CYLINDER ASSY, IGNITION SWITCH LOCK | ||||
| 69570-14050 |
GA70,JZA70..G,GT,GTT,GTTR |
1 | ||
| Common parts | ||||
| 90168-40036 | ||||
| 90179-05042 | ||||
| 91651-40612 | ||||
(8808-8908)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69051 - CYLINDER & KEY SET, DOOR LOCK, RH | ||||
| 69051-14140 |
GA70 |
1 | ||
| 69052 - CYLINDER & KEY SET, DOOR LOCK, LH | ||||
| 69052-14140 |
GA70,MA70 |
1 | ||
| 69055B - CYLINDER & KEY SET, BACK DOOR LOCK | ||||
| 69055-14311 |
GA70,JZA70,MA70 |
1 | ||
| 69055-14310 |
GA70,MA70 |
1 | ||
| 69057A - CYLINDER & KEY SET, IGNITION SWITCH LOCK | ||||
| 69057-14120 |
GA70,MA70 |
1 | ||
| 69062 - CYLINDER & KEY SET, GLOVE COMPARTMENT LOCK | ||||
| 69056-1409004 |
GA70,MA70..G,GT,GTL,GTT DEEP BLUE,TRIM8# |
1 | ||
| 69056-1409002 |
GA70,MA70..G,GT,GTL,GTT MAROON,TRIM3# |
1 | ||
| 69056-1409003 |
GA70,MA70..G,GT,GTL,GTT MEDIUM GRAY METALLIC,TRIM1# |
1 | ||
| 69388 - SNAP, ROD(FOR DOOR LOCK) | ||||
| 69759-30040 |
GA70,JZA70,MA70 右側 |
1 | ||
| 69759-30050 |
GA70,JZA70,MA70 左側 |
1 | ||
| 69388 - SNAP, ROD(FOR DOOR LOCK) | ||||
| 69759-30040 |
GA70,JZA70,MA70 右側 |
1 | ||
| 69759-30050 |
GA70,JZA70,MA70 左側 |
1 | ||
| 69503 - CYLINDER SET, LOCK | ||||
| 69005-1462113 |
GA70,JZA70..GT,GTT,GTTR SHADOW GRAY,TRIM1# |
1 | ||
| 69005-1462003 |
GA70 MEDIUM GRAY,TRIM1# |
1 | ||
| 69005-1462002 |
GA70 MAROON,TRIM3# |
1 | ||
| 69005-1462102 |
GA70,MA70..G,GT,GTT MAROON,TRIM3# |
1 | ||
| 69005-1462104 |
GA70,MA70..G,GT,GTT DEEP BLUE,TRIM8# |
1 | ||
| 69005-1462112 |
GA70,JZA70..GT,GTT DEEP RED,TRIM3# |
1 | ||
| 69005-1462004 |
GA70 DEEP BLUE,TRIM8# |
1 | ||
| 69005-1462103 |
GA70,MA70..G,GT,GTT MEDIUM GRAY,TRIM1# |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00094 |
GA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 90999-00106 |
GA70,MA70 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00085 |
GA70,MA70 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00174 |
GA70,JZA70..G,GT,GTT,GTTR ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00153 |
GA70,JZA70,MA70 |
1 | ||
| 90999-00154 |
GA70,JZA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 69503A - KEY, BLANK | ||||
| 90999-00094 |
GA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 90999-00106 |
GA70,MA70 ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00085 |
GA70,MA70 ﾏｽﾀｰｷｰ |
1 | ||
| 90999-00174 |
GA70,JZA70..G,GT,GTT,GTTR ﾏｽﾀｰｷｰ,*68付き |
1 | ||
| 90999-00153 |
GA70,JZA70,MA70 |
1 | ||
| 90999-00154 |
GA70,JZA70,MA70 ｻﾌﾞｷｰ |
1 | ||
| 69555 - COVER, KEY | ||||
| 69555-20010 |
GA70,JZA70,MA70 |
1 | ||
| Common parts | ||||
| 90168-40036 | ||||
| 90179-05042 | ||||
| 91651-40612 | ||||
(8908- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Linked diagrams | ||||
| 8420 | ||||
