GA70-BJPVZ (1988)
Toyota Supra
ILLUST NO. 2 OF 2(8808- )1GGTEU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04175 - GASKET KIT, TURBOCHARGER | ||||
| 04175-70021 |
1GGTEU..GA70 |
1 | ||
| 04176 - SEAL KIT, TURBOCHARGER | ||||
| 04176-70010 |
1GGTEU..GA70 |
2 | ||
| 04176 - SEAL KIT, TURBOCHARGER | ||||
| 04176-70010 |
1GGTEU..GA70 |
2 | ||
| 16347 - GASKET, WATER BY-PASS | ||||
| 16347-28010 |
1GGTEU..GA70 |
2 | ||
| 16347 - GASKET, WATER BY-PASS | ||||
| 16347-28010 |
1GGTEU..GA70 |
2 | ||
| 17021 - HOUSING SUB-ASSY, BEARING | ||||
| 17021-70020 |
1GGTEU..GA70 |
2 | ||
| 17021 - HOUSING SUB-ASSY, BEARING | ||||
| 17021-70020 |
1GGTEU..GA70 |
2 | ||
| 17021A - BOLT, STUD(FOR BEARING HOUSING) | ||||
| 90116-08158 |
1GGTEU..GA70 |
4 | ||
| 17021A - BOLT, STUD(FOR BEARING HOUSING) | ||||
| 90116-08158 |
1GGTEU..GA70 |
4 | ||
| 17021B - BOLT, STUD | ||||
| 90116-06048 |
1GGTEU..GA70 |
4 | ||
| 17021B - BOLT, STUD | ||||
| 90116-06048 |
1GGTEU..GA70 |
4 | ||
| 17021C - RING, HOLE SNAP(FOR BEARING HOUSING) | ||||
| 90521-99035 |
1GGTEU..GA70 |
2 | ||
| 17021C - RING, HOLE SNAP(FOR BEARING HOUSING) | ||||
| 90521-99035 |
1GGTEU..GA70 |
2 | ||
| 17025A - BOLT, STUD(FOR TURBINE HOUSING) | ||||
| 90116-08200 |
1GGTEU..GA70 |
8 | ||
| 17025A - BOLT, STUD(FOR TURBINE HOUSING) | ||||
| 90116-08200 |
1GGTEU..GA70 |
8 | ||
| 17141D - BOLT, STUD(FOR OXYGEN SENSOR) | ||||
| 90116-08187 |
1GG#..GA70 *54 |
2 | ||
| 17141G - BOLT, STUD(FOR TURBOCHARGER) | ||||
| 90116-10129 |
1GGTEU..GA70 |
6 | ||
| 17141G - BOLT, STUD(FOR TURBOCHARGER) | ||||
| 90116-10129 |
1GGTEU..GA70 |
6 | ||
| 17152 - BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||||
| 90116-10058 |
1GG#..GA70 *54 |
3 | ||
| 17201 - TURBOCHARGER SUB-ASSY | ||||
| 17208-70040 |
1GGTEU..GA70 ﾘﾔ |
1 | ||
| 17201-70040 |
1GGTEU..GA70 ﾌﾛﾝﾄ |
1 | ||
| 17201 - TURBOCHARGER SUB-ASSY | ||||
| 17208-70040 |
1GGTEU..GA70 ﾘﾔ |
1 | ||
| 17201-70040 |
1GGTEU..GA70 ﾌﾛﾝﾄ |
1 | ||
| 17224 - HOUSING, COMPRESSOR | ||||
| 17224-70020 |
1GGTEU..GA70 |
2 | ||
| 17224 - HOUSING, COMPRESSOR | ||||
| 17224-70020 |
1GGTEU..GA70 |
2 | ||
| 17224A - UNION(FOR COMPRESSOR HOUSING) | ||||
| 90404-53058 |
1GGTEU..GA70 |
2 | ||
| 17224A - UNION(FOR COMPRESSOR HOUSING) | ||||
| 90404-53058 |
1GGTEU..GA70 |
2 | ||
| 17229 - BAND, V | ||||
| 17229-70010 |
1GGTEU..GA70 |
2 | ||
| 17229 - BAND, V | ||||
| 17229-70010 |
1GGTEU..GA70 |
2 | ||
| 17239 - CLAMP, V, NO.2 | ||||
| 17239-70010 |
1GGTEU..GA70 |
2 | ||
| 17239 - CLAMP, V, NO.2 | ||||
| 17239-70010 |
1GGTEU..GA70 |
2 | ||
| 17279 - GASKET, TURBINE OUTLET ELBOW | ||||
| 17279-88340 |
1GGTEU..GA70 |
2 | ||
| 17279 - GASKET, TURBINE OUTLET ELBOW | ||||
| 17279-88340 |
1GGTEU..GA70 |
2 | ||
| 17291 - ELBOW, TURBINE OUTLET | ||||
| 17291-88340 |
1GGTEU..GA70 |
1 | ||
| 17294 - HOSE, ACTUATOR | ||||
| 90445-12151 |
1GGTEU..GA70 RR TURBO |
1 | ||
| 90445-12172 |
1GGTEU..GA70 FR TURBO |
1 | ||
| 17294 - HOSE, ACTUATOR | ||||
| 90445-12151 |
1GGTEU..GA70 RR TURBO |
1 | ||
| 90445-12172 |
1GGTEU..GA70 FR TURBO |
1 | ||
| 17294A - CLIP(FOR ACTUATOR HOSE) | ||||
| 96132-30600 |
1GGTEU..GA70 |
4 | ||
| 17294A - CLIP(FOR ACTUATOR HOSE) | ||||
| 96132-30600 |
1GGTEU..GA70 |
4 | ||
| 17294A - CLIP(FOR ACTUATOR HOSE) | ||||
| 96132-30600 |
1GGTEU..GA70 |
4 | ||
| 17294A - CLIP(FOR ACTUATOR HOSE) | ||||
| 96132-30600 |
1GGTEU..GA70 |
4 | ||
| 17296 - PLATE, BEARING HOUSING, SIDE | ||||
| 17296-28010 |
1GGTEU..GA70 |
2 | ||
| 17296 - PLATE, BEARING HOUSING, SIDE | ||||
| 17296-28010 |
1GGTEU..GA70 |
2 | ||
| Common parts | ||||
| 90179-08012 | ||||
| 90179-08082 | ||||
| 90254-03013 | ||||
| 91651-B0820 | ||||
| 91655-G0620 | ||||
ILLUST NO. 1 OF 2(8808- )1GGTEU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 15471 - GASKET, TURBO OIL INLET | ||||
| 15471-88341 |
1GGTEU..GA70 |
2 | ||
| 15471 - GASKET, TURBO OIL INLET | ||||
| 15471-88341 |
1GGTEU..GA70 |
2 | ||
| 15472 - GASKET, TURBO OIL OUTLET, NO.1 | ||||
| 15472-88340 |
1GGTEU..GA70 |
2 | ||
| 15472 - GASKET, TURBO OIL OUTLET, NO.1 | ||||
| 15472-88340 |
1GGTEU..GA70 |
2 | ||
| 15473 - GASKET, TURBO OIL OUTLET, NO.2 | ||||
| 15473-88340 |
1GGTEU..GA70 |
1 | ||
| 15474 - PIPE, TURBO OIL OUTLET | ||||
| 15474-88341 |
1GGTEU..GA70 |
1 | ||
| 15481 - PIPE, TURBO OIL, NO.1 | ||||
| 15481-88341 |
1GGTEU..GA70 |
1 | ||
| 15481A - BOLT, UNION, NO.1 | ||||
| 90401-12025 |
1GGTEU..GA70 |
1 | ||
| 15481B - GASKET(FOR UNION BOLT NO.1) | ||||
| 90430-12110 |
1GGTEU..GA70 |
2 | ||
| 15481B - GASKET(FOR UNION BOLT NO.1) | ||||
| 90430-12110 |
1GGTEU..GA70 |
2 | ||
| 15482 - PIPE, TURBO OIL, NO.2 | ||||
| 15482-88341 |
1GGTEU..GA70 |
1 | ||
| 15482A - BOLT, UNION, NO.2 | ||||
| 90401-12025 |
1GGTEU..GA70 |
1 | ||
| 15482B - GASKET(FOR UNION BOLT NO.2) | ||||
| 90430-12110 |
1GGTEU..GA70 |
2 | ||
| 15482B - GASKET(FOR UNION BOLT NO.2) | ||||
| 90430-12110 |
1GGTEU..GA70 |
2 | ||
| 17110A - UNION, VACUUM HOSE | ||||
| 90405-04002 |
1GGTEU..GA70 |
3 | ||
| 17111 - MANIFOLD, INTAKE | ||||
| 17120-88340 |
1GGTEU..GA70 |
1 | ||
| 17118 - STAY, MANIFOLD | ||||
| 17118-88341 |
1GGTEU..GA70 |
1 | ||
| 17119 - STAY, MANIFOLD, NO.2 | ||||
| 17139-88341 |
1GGTEU..GA70 |
1 | ||
| 17125 - STAY, SURGE TANK, NO.1 | ||||
| 17125-88341 |
1GGTEU..GA70 |
1 | ||
| 17126 - STAY, SURGE TANK, NO.2 | ||||
| 17126-88341 |
1GGTEU..GA70 |
1 | ||
| 17129B - PLUG | ||||
| 96411-21600 |
1GG#..GA70 *54 |
1 | ||
| 17129J - PLUG, TIGHT(FOR INTAKE AIR SURGE TANK) | ||||
| 96411-34000 |
1GFE,1GGTEU..GA70 外径=40 |
2 | ||
| 17141 - MANIFOLD, EXHAUST | ||||
| 17141-88341 |
1GGTEU..GA70 |
1 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD |
7 | ||
| 90116-10063 |
1GFE,1GG#..GA70 EXHAUST MANIFOLD |
9 | ||
| 17159 - BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||||
| 90116-08186 |
1GG#..GA70 INTAKE MANIFOLD |
7 | ||
| 90116-10063 |
1GFE,1GG#..GA70 EXHAUST MANIFOLD |
9 | ||
| 17167 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.1 | ||||
| 17167-88340 |
1GGTEU..GA70 |
1 | ||
| 17168 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.2 | ||||
| 17168-88340 |
1GGTEU..GA70 |
1 | ||
| 17169 - INSULATOR, EXHAUST MANIFOLD HEAT, NO.3 | ||||
| 17169-88341 |
1GGTEU..GA70 |
1 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88340 |
1GGTEU..GA70 |
3 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88340 |
1GGTEU..GA70 |
3 | ||
| 17173 - GASKET, EXHAUST MANIFOLD TO HEAD | ||||
| 17173-88340 |
1GGTEU..GA70 |
3 | ||
| 17177 - GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||||
| 17177-88301 |
1GGTEU..GA70 |
1 | ||
| 17179A - GASKET, INTAKE MANIFOLD, NO.2 | ||||
| 17179-88340 |
1GGTEU..GA70 |
1 | ||
| 17271 - INSULATOR, TURBO, NO.1 | ||||
| 17271-88340 |
1GGTEU..GA70 |
1 | ||
| 17272 - INSULATOR, TURBO, NO.2 | ||||
| 17272-88340 |
1GGTEU..GA70 |
1 | ||
| 17278 - GASKET, TURBO TO EXHAUST MANIFOLD | ||||
| 17278-88340 |
1GGTEU..GA70 |
2 | ||
| 17278 - GASKET, TURBO TO EXHAUST MANIFOLD | ||||
| 17278-88340 |
1GGTEU..GA70 |
2 | ||
| 17300 - VALVE ASSY, INTAKE AIR CONTROL | ||||
| 17300-88340 |
1GGTEU..GA70 |
1 | ||
| Common parts | ||||
| 90105-10112 | ||||
| 90116-08206 | ||||
| 90119-08628 | ||||
| 90179-08082 | ||||
| 90179-08150 | ||||
| 90179-10037 | ||||
| 90179-10094 | ||||
| 90253-11021 | ||||
| 90339-03017 | ||||
| 90405-06005 | ||||
| 90461-08647 | ||||
| 91611-60820 | ||||
| 91611-F0814 | ||||
| 91651-61022 | ||||
| 91651-F0820 | ||||
| 91651-F0825 | ||||
