KP61-PHKSS (1978)
Toyota Starlet
(7802-7903) ; (7903-7908)3KHJ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-13020 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27020-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27020-13080 |
4KU..KP61 12V 45A |
1 | ||
| 27020-24063 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27020-13060 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A,12V 40A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 45A |
1 | ||
| 27039-18011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27039-26020 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 40A |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27312-31011 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27212-39050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27310-24071 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27310-24070 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
3KHJ,4K#..KP6# 12V 40A,45A,50A,55A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10114 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 40A |
1 | ||
| 90099-10109 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 45A |
1 | ||
| 90099-10126 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310C - FELT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-02004 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27315 - COVER, ALTERNATOR FELT, INNER NO.1 | ||||
| 27313-31011 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27330-26050 |
4KU..KP61 12V 40A |
1 | ||
| 27330-26050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27330-45020 |
4KU..KP61 12V 45A |
1 | ||
| 27330-33010 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10103 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10111 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 90099-10111 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27330B - RING, SNAP(FOR ALTERNATOR ROTOR) | ||||
| 90099-07048 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 90099-07048 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 90099-07048 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-13020 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27350-24063 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27353-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27356-45080 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27359-44033 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27359-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-26051 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27362-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 45A |
1 | ||
| 27362-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27371-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27371-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27372-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34050 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27410-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27410-38120 |
4KU..KP61 12V 45A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27411-25010 |
3KHJ,4KU..KP6# 12V 40A,50A,W/COOLER |
1 | ||
| 27411-26111 |
4KU..KP61 12V 40A |
1 | ||
| 27411-26111 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27412-44030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27441-34030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| Common parts | ||||
| 27378-45020 | ||||
| 27387-45021 | ||||
| 27447-24061 | ||||
| 90099-00862 | ||||
| 90099-02310 | ||||
| 90099-04259 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 94110-41000 | ||||
| 94511-01000 | ||||
| 94511-01400 | ||||
| 94612-11001 | ||||
(7802-7903) ; (7903-7908)3KHJ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-13020 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27020-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27020-13080 |
4KU..KP61 12V 45A |
1 | ||
| 27020-24063 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27020-13060 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A,12V 40A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 45A |
1 | ||
| 27039-18011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27039-26020 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 40A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27212-39050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27310-24071 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27310-24070 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
3KHJ,4K#..KP6# 12V 40A,45A,50A,55A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10114 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 40A |
1 | ||
| 90099-10109 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 45A |
1 | ||
| 90099-10126 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27330-26050 |
4KU..KP61 12V 40A |
1 | ||
| 27330-26050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27330-45020 |
4KU..KP61 12V 45A |
1 | ||
| 27330-33010 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10103 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10111 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 90099-10111 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-13020 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27350-24063 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27353-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27356-45080 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27359-44033 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27359-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-26051 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27362-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 45A |
1 | ||
| 27362-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27371-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27371-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27372-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34050 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27410-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27410-38120 |
4KU..KP61 12V 45A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27411-25010 |
3KHJ,4KU..KP6# 12V 40A,50A,W/COOLER |
1 | ||
| 27411-26111 |
4KU..KP61 12V 40A |
1 | ||
| 27411-26111 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27412-44030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27441-34030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| Common parts | ||||
| 27378-38040 | ||||
| 27387-45022 | ||||
| 27447-24061 | ||||
| 90099-00912 | ||||
| 90099-02310 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 94110-41000 | ||||
| 94511-01000 | ||||
| 94511-01400 | ||||
| 94612-11001 | ||||
(7903-8208)4KU ; (7908-8201)3KHJ ; (8201- )4KJ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-13020 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27020-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27020-13080 |
4KU..KP61 12V 45A |
1 | ||
| 27020-24063 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27020-13060 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A,12V 40A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 45A |
1 | ||
| 27039-18011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27039-26020 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 40A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27212-39050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27310-24071 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27310-24070 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
3KHJ,4K#..KP6# 12V 40A,45A,50A,55A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10114 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 40A |
1 | ||
| 90099-10109 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 45A |
1 | ||
| 90099-10126 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27330-26050 |
4KU..KP61 12V 40A |
1 | ||
| 27330-26050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27330-45020 |
4KU..KP61 12V 45A |
1 | ||
| 27330-33010 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10103 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10111 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 90099-10111 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27330B - RING, SNAP(FOR ALTERNATOR ROTOR) | ||||
| 90099-07048 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 90099-07048 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 90099-07048 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
4KU..KP61 12V 40A |
1 | ||
| 27351-38051 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27359-44033 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27359-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-26051 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27362-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 45A |
1 | ||
| 27362-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27371-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27371-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27372-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34050 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27410-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27410-38120 |
4KU..KP61 12V 45A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27411-25010 |
3KHJ,4KU..KP6# 12V 40A,50A,W/COOLER |
1 | ||
| 27411-26111 |
4KU..KP61 12V 40A |
1 | ||
| 27411-26111 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27412-44030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27441-34030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| Common parts | ||||
| 27378-15030 | ||||
| 27378-38040 | ||||
| 27387-45022 | ||||
| 27387-45110 | ||||
| 27447-24061 | ||||
| 90099-00912 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 94110-41000 | ||||
| 94511-01000 | ||||
| 94511-01400 | ||||
| 94612-11001 | ||||
(7908-8005)3KHJ ; (8108- )4KU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-13020 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27020-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27020-13080 |
4KU..KP61 12V 45A |
1 | ||
| 27020-24063 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27020-13060 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A,12V 40A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 45A |
1 | ||
| 27039-18011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27039-26020 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27039-18011 |
4KU..KP61 12V 40A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 27412-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27212-39050 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27212-39050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27310-24071 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27310-24070 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27310-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 27412-31040 |
3KHJ,4K#..KP6# 12V 40A,45A,50A,55A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-10114 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 40A |
1 | ||
| 90099-10109 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10126 |
4KU..KP61 12V 45A |
1 | ||
| 90099-10126 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-45070 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27330-26050 |
4KU..KP61 12V 40A |
1 | ||
| 27330-26050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27330-45020 |
4KU..KP61 12V 45A |
1 | ||
| 27330-33010 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 90099-10103 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 90099-10111 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 90099-10111 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-38051 |
4KU..KP61 12V 40A |
1 | ||
| 27351-38051 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27353-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27356-45080 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27359-44033 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 40A |
1 | ||
| 27359-13050 |
4KU..KP61 12V 45A |
1 | ||
| 27359-13050 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27362 - RECTIFIER ASSY, W/BRUSH | ||||
| 27362-26051 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27362-45081 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27362-15030 |
4KU..KP61 12V 45A |
1 | ||
| 27362-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27371-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27371-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27371-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,50A |
2 | ||
| 27372-31011 |
4KU..KP61 12V 40A |
2 | ||
| 27372-31011 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
2 | ||
| 27372-31011 |
3KHJ,4KU..KP6# 12V 40A,45A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-34050 |
3KHJ,4KU..KP6# 12V 50A |
1 | ||
| 27410-26020 |
3KHJ,4KU..KP6# 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61 12V 40A |
1 | ||
| 27410-15030 |
4KU..KP61..4F..DXA;3KHJ,4K#..KP6#..DLX,S,SE,STD,XL 12V 40A |
1 | ||
| 27410-38120 |
4KU..KP61 12V 45A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-31042 |
3KHJ,4KU..KP6# 12V 40A,50A |
1 | ||
| 27411-25010 |
3KHJ,4KU..KP6# 12V 40A,50A,W/COOLER |
1 | ||
| 27411-26111 |
4KU..KP61 12V 40A |
1 | ||
| 27411-26111 |
3KHJ,4KU..KP6# 12V 40A,45A |
1 | ||
| 27412 - COLLAR, SPACER(FOR ALTERNATOR PULLEY) | ||||
| 27412-44030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27412-44030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-34030 |
3KHJ,4K#..KP6# 12V 40A,50A |
1 | ||
| 27441-34030 |
3KHJ,4KU..KP6# 12V 40A,45A,50A |
1 | ||
| Common parts | ||||
| 27378-38040 | ||||
| 27378-45090 | ||||
| 27387-45022 | ||||
| 27387-45110 | ||||
| 27447-24061 | ||||
| 90099-00912 | ||||
| 90099-04300 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 94110-41000 | ||||
| 94511-01000 | ||||
| 94511-01400 | ||||
| 94612-11001 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
