EP82-AHHDU (1989)
Toyota Starlet
(8912-9201)4EF
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 21015 - HOUSING SUB-ASSY, COIL | ||||
| 21015-11641 |
4EF..EP8#..ATM |
1 | ||
| 21192 - BREAKER | ||||
| 21191-11731 |
4EF..EP8# NO.1 |
1 | ||
| 21192-11741 |
4EF..EP8#..ATM NO.2 |
1 | ||
| 21192 - BREAKER | ||||
| 21191-11731 |
4EF..EP8# NO.1 |
1 | ||
| 21192-11741 |
4EF..EP8#..ATM NO.2 |
1 | ||
| 21209 - FLOAT SUB-ASSY | ||||
| 21209-13310 |
4EF..EP82 |
1 | ||
| 21251 - JET, 1ST MAIN | ||||
| 90999-41103 |
4EF..EP8# |
1 | ||
| 21253 - JET, 2ND MAIN | ||||
| 90999-42141 |
4EF..EP8# |
1 | ||
| 21255 - JET, POWER | ||||
| 90999-44148 |
4EF..EP8# |
1 | ||
| 21271 - SCREW, IDLE ADJUSTING | ||||
| 21271-13271 |
4EF..EP8# |
1 | ||
| 21273 - SCREW, THROTTLE ADJUSTING | ||||
| 21273-24231 |
4EF..EP8#..ATM |
1 | ||
| 21291 - GLASS, LEVEL GAGE | ||||
| 21291-34320 |
4EF..EP8# |
1 | ||
| 21301 - VALVE SUB-ASSY, NEEDLE | ||||
| 21301-11620 |
4EF..EP8# |
1 | ||
| 21313 - BALL, STEEL, NO.1(FOR DISCHARGE WEIGHT) | ||||
| 21313-11020 |
4EF..EP8# |
1 | ||
| 21314 - BALL, STEEL, NO.2(FOR PUMP PLUNGER) | ||||
| 21314-60010 |
4EF..EP8# |
1 | ||
| 21353 - PLUNGER, PUMP | ||||
| 21353-11731 |
4EF..EP8# |
1 | ||
| 21353-11730 |
4EF..EP82 |
1 | ||
| 21414 - SHAFT, CHOKE | ||||
| 21054-11610 |
4EF..EP8# |
1 | ||
| 21538 - RETAINER, BALL CHECK | ||||
| 21538-31010 |
4EF..EP8# |
1 | ||
| 21561 - WEIGHT, PUMP DISCHARGE | ||||
| 21575-11730 |
4EF..EP8# |
1 | ||
| 21576 - CLIP, PUMP STRAINER | ||||
| 21576-27010 |
4EF..EP8# |
1 | ||
| 21609 - DIAPHRAGM SUB-ASSY | ||||
| 21609-11620 |
4EF..EP8# |
1 | ||
| 21611 - GASKET, MAIN JET | ||||
| 21611-22010 |
4EF..EP8# |
2 | ||
| 21611 - GASKET, MAIN JET | ||||
| 21611-22010 |
4EF..EP8# |
2 | ||
| 21614 - GASKET, VENTURI | ||||
| 21614-13430 |
4EF..EP8# 1ST |
1 | ||
| 21614-24580 |
4EF..EP8# 2ND |
1 | ||
| 21614 - GASKET, VENTURI | ||||
| 21614-13430 |
4EF..EP8# 1ST |
1 | ||
| 21614-24580 |
4EF..EP8# 2ND |
1 | ||
| 21617 - GASKET, MAIN PASSAGE PLUG | ||||
| 21617-30010 |
4EF..EP8# |
2 | ||
| 21617 - GASKET, MAIN PASSAGE PLUG | ||||
| 21617-30010 |
4EF..EP8# |
2 | ||
| 21621 - GASKET, UNION NIPPLE | ||||
| 21633-24030 |
4EF..EP8# |
1 | ||
| 21622 - GASKET, AIR HORN | ||||
| 21622-13430 |
4EF..EP8# |
1 | ||
| 21623 - GASKET, BODY FLANGE | ||||
| 21623-11611 |
4EF..EP8# |
1 | ||
| 21625 - GASKET, LEVEL GAGE | ||||
| 21655-60200 |
4EF..EP8# |
1 | ||
| 21627 - GASKET, COIL HOUSING | ||||
| 21627-28090 |
4EF..EP8# |
1 | ||
| 21655 - RING, O(FOR LIFTER ROD) | ||||
| 21655-44101 |
4EF..EP8# |
1 | ||
| 21667 - DIAPHRAGM | ||||
| 21667-11730 |
4EF..EP8# |
1 | ||
| 21679 - POSITIONER | ||||
| 21679-11621 |
4EF..EP8#..ATM |
1 | ||
| 21699 - BOOT(FOR PUMP PLUNGER) | ||||
| 21699-28150 |
4EF..EP8# |
1 | ||
| 21712 - BUSH, SLIDING ROD | ||||
| 21712-38010 |
4EF..EP8# |
1 | ||
| 21722 - SPRING, PUMP DAMPING | ||||
| 21722-22010 |
4EF..EP8# |
1 | ||
| 21723 - SPRING, IDLE ADJUSTING | ||||
| 21723-21030 |
4EF..EP8# |
1 | ||
| 21724 - SPRING, THROTTLE ADJUSTING | ||||
| 21723-38010 |
4EF..EP8#..ATM |
3 | ||
| 21724 - SPRING, THROTTLE ADJUSTING | ||||
| 21723-38010 |
4EF..EP8#..ATM |
3 | ||
| 21725 - SPRING, 2ND THROTTLE BACK | ||||
| 21725-11610 |
4EF..EP82 |
1 | ||
| 21726 - SPRING, 1ST IDLE ADJUSTING | ||||
| 21726-38310 |
4EF..EP8# |
1 | ||
| 21734 - SPRING, POWER PISTON | ||||
| 21734-11730 |
4EF..EP8# |
1 | ||
| 21735 - SPRING, PUMP ARM | ||||
| 21735-21032 |
4EF..EP8# |
1 | ||
| 21751 - UNION, NIPPLE | ||||
| 21751-10050 |
4EF..EP8# |
1 | ||
| 21763 - PIN, FLOAT LEVER | ||||
| 21763-38010 |
4EF..EP8# |
1 | ||
| 21781 - PLUG, MAIN PASSAGE(FOR CARBURETOR JET) | ||||
| 21781-15230 |
4EF..EP8# |
2 | ||
| 21781 - PLUG, MAIN PASSAGE(FOR CARBURETOR JET) | ||||
| 21781-15230 |
4EF..EP8# |
2 | ||
| 21791 - RING, SNAP, NO.1(FOR CARBURETOR LINK) | ||||
| 21791-13011 |
4EF..EP8# TYPE 2 |
2 | ||
| 21791-13011 |
4EF..EP85;4EF..EP82..3FC TYPE 1 |
7 | ||
| 21794 - RING, RETAINER, NO.1(FOR THROTTLE SHAFT) | ||||
| 21794-40070 |
4EF..EP8# |
1 | ||
| 21826 - SCREW, PUMP ARM SET | ||||
| 21826-24470 |
4EF..EP8# |
1 | ||
| 21832 - SCREW(FOR CHOKE LEVER ADAPTER SET) | ||||
| 21832-15320 |
4EF..EP8# |
1 | ||
| 21833 - SCREW, SET, NO.1(FOR CARBURETOR BODY SET) | ||||
| 21835-40010 |
4EF..EP8#..3FC,4F,5F |
1 | ||
| 21834 - SCREW, SET, NO.2(FOR CARBURETOR BODY SET) | ||||
| 21834-31010 |
4EF..EP8# |
1 | ||
| 21850 - SCREW, THROTTLE SWITCH ADJUSTING | ||||
| 21272-11730 |
4EF..EP8# |
1 | ||
| 21864 - SPRING(FOR 1ST THROTTLE ARM) | ||||
| 21864-24230 |
4EF..EP8#..ATM |
1 | ||
| 21864A - SPRING(FOR PUMP DISCHARGE WEIGHT) | ||||
| 21864-11730 |
4EF..EP8# |
1 | ||
| 21869 - SPRING(FOR MAIN JET) | ||||
| 21869-11610 |
4EF..EP8# |
1 | ||
| 21934 - SOLENOID, THROTTLE VALVE | ||||
| 21062-11610 |
4EF..EP8# |
1 | ||
| 21934E - RING, O(FOR SOLENOID VALVE) | ||||
| 21655-44101 |
4EF..EP8# |
1 | ||
| 21934F - GASKET | ||||
| 21649-38010 |
4EF..EP8# |
1 | ||
| Common parts | ||||
| 21673-13280 | ||||
| 21795-30010 | ||||
| 21821-13080 | ||||
| 21821-15010 | ||||
| 21821-15060 | ||||
| 21821-15320 | ||||
| 21821-25010 | ||||
| 21821-31140 | ||||
| 21821-34370 | ||||
| 21821-34380 | ||||
| 21842-11611 | ||||
| 21842-33010 | ||||
| 21885-26040 | ||||
| 21887-38010 | ||||
| 90079-13005 | ||||
| 90079-13006 | ||||
| 90079-21001 | ||||
| 90079-30001 | ||||
| 90339-03002 | ||||
| 90523-07014 | ||||
| 90999-43100 | ||||
| 90999-92002 | ||||
| 91111-40612 | ||||
| 93119-13010 | ||||
| 94110-40800 | ||||
| 94511-00800 | ||||
| 94512-00600 | ||||
| Linked diagrams | ||||
| 8401 | ||||
