EP82-AGMVK (1989)
Toyota Starlet
(8912- )4EF#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90999-92002 | ||||
| 90999-92003 | ||||
| 90999-92004 | ||||
| 90999-92006 | ||||
| 90999-92007 | ||||
| 90999-92008 | ||||
(8912-9201)4EF
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-11400 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11430 |
4EF..EP8# NO.1 |
1 | ||
| 17303-11401 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11620 |
4EF..EP8# NO.3 |
1 | ||
| 17303-11810 |
4EF#..EP8# NO.1 |
1 | ||
| 17303-11460 |
4EF..EP8# NO.2 |
1 | ||
| 17303-11401 |
4EF#..EP8# NO.1 |
1 | ||
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-11400 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11430 |
4EF..EP8# NO.1 |
1 | ||
| 17303-11401 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11620 |
4EF..EP8# NO.3 |
1 | ||
| 17303-11810 |
4EF#..EP8# NO.1 |
1 | ||
| 17303-11460 |
4EF..EP8# NO.2 |
1 | ||
| 17303-11401 |
4EF#..EP8# NO.1 |
1 | ||
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-11400 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11430 |
4EF..EP8# NO.1 |
1 | ||
| 17303-11401 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11620 |
4EF..EP8# NO.3 |
1 | ||
| 17303-11810 |
4EF#..EP8# NO.1 |
1 | ||
| 17303-11460 |
4EF..EP8# NO.2 |
1 | ||
| 17303-11401 |
4EF#..EP8# NO.1 |
1 | ||
| 17650 - VALVE ASSY, VACUUM SWITCHING | ||||
| 25860-11160 |
4EF..EP8# NO.4 |
1 | ||
| 25860-11130 |
4EF..EP8# NO.1 |
1 | ||
| 90910-12009 |
4EF..EP8# NO.2 |
1 | ||
| 25860-11150 |
4EF..EP8# NO.3 |
1 | ||
| 17650 - VALVE ASSY, VACUUM SWITCHING | ||||
| 25860-11160 |
4EF..EP8# NO.4 |
1 | ||
| 25860-11130 |
4EF..EP8# NO.1 |
1 | ||
| 90910-12009 |
4EF..EP8# NO.2 |
1 | ||
| 25860-11150 |
4EF..EP8# NO.3 |
1 | ||
| 17650 - VALVE ASSY, VACUUM SWITCHING | ||||
| 25860-11160 |
4EF..EP8# NO.4 |
1 | ||
| 25860-11130 |
4EF..EP8# NO.1 |
1 | ||
| 90910-12009 |
4EF..EP8# NO.2 |
1 | ||
| 25860-11150 |
4EF..EP8# NO.3 |
1 | ||
| 17650 - VALVE ASSY, VACUUM SWITCHING | ||||
| 25860-11160 |
4EF..EP8# NO.4 |
1 | ||
| 25860-11130 |
4EF..EP8# NO.1 |
1 | ||
| 90910-12009 |
4EF..EP8# NO.2 |
1 | ||
| 25860-11150 |
4EF..EP8# NO.3 |
1 | ||
| 21999 - BRACKET, VACUUM SWITCHING VALVE | ||||
| 21999-11070 |
4EF..EP8# NO.2 |
1 | ||
| 21999-10010 |
4EF..EP8# NO.1 |
1 | ||
| 21999 - BRACKET, VACUUM SWITCHING VALVE | ||||
| 21999-11070 |
4EF..EP8# NO.2 |
1 | ||
| 21999-10010 |
4EF..EP8# NO.1 |
1 | ||
| 23262 - VALVE, BIMETAL VACUUM SWITCHING, NO.1 | ||||
| 25820-11040 |
4EF..EP8# |
1 | ||
| 23263 - VALVE, BIMETAL VACUUM SWITCHING, NO.2 | ||||
| 25810-11080 |
4EF..EP8# |
1 | ||
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11027 |
4EF..EP8# |
1 | ||
| 90917-11030 |
4EFE,4EFTE..EP8# |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01101 |
4EF..EP8# NO.2 |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01101 |
4EF..EP8# NO.2 |
1 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10080 |
4EF#..EP8# |
1 | ||
| 90917-10049 |
4EF..EP8# NO.1 |
2 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10080 |
4EF#..EP8# |
1 | ||
| 90917-10049 |
4EF..EP8# NO.1 |
2 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10080 |
4EF#..EP8# |
1 | ||
| 90917-10049 |
4EF..EP8# NO.1 |
2 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10080 |
4EF#..EP8# |
1 | ||
| 90917-10049 |
4EF..EP8# NO.1 |
2 | ||
| 23288 - JET, NO.1 | ||||
| 90925-04029 |
4EF..EP8# |
1 | ||
| 25760 - HOSE ASSY, VACUUM TRANSMITTING | ||||
| 25760-11070 |
4EFE,4EFTE..EP8#..CAN,CANSI,GI,GT,S,SI,SOLL,XLTD NO.1 |
1 | ||
| 25760-11071 |
4EFE..EP8#..CAN,GI,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11120 |
4EFE..EP8# NO.2 |
1 | ||
| 25760-11071 |
4EF#..EP8#..GI,GT,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11100 |
4EF..EP8# |
1 | ||
| 25810 - VALVE ASSY, BIMETAL | ||||
| 90925-05071 |
4EF..EP8# |
1 | ||
| 25860 - VALVE ASSY, VACUUM SWITCHING, NO.1 | ||||
| 89470-10030 |
4EF..EP8# |
1 | ||
| Common parts | ||||
| 87616-22010 | ||||
| 90119-08813 | ||||
| 90339-03002 | ||||
| 90412-06070 | ||||
| 90413-04005 | ||||
| 90413-04008 | ||||
| 90414-04001 | ||||
| 90464-00074 | ||||
| 90464-00082 | ||||
| 90464-00393 | ||||
| 90910-05211 | ||||
| 90999-92001 | ||||
| 90999-92002 | ||||
| 91655-60820 | ||||
| 95413-49928 | ||||
| Linked diagrams | ||||
| 8401 | ||||
(8912- )4EFE,4EFTE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-11400 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11430 |
4EF..EP8# NO.1 |
1 | ||
| 17303-11401 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11620 |
4EF..EP8# NO.3 |
1 | ||
| 17303-11810 |
4EF#..EP8# NO.1 |
1 | ||
| 17303-11460 |
4EF..EP8# NO.2 |
1 | ||
| 17303-11401 |
4EF#..EP8# NO.1 |
1 | ||
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-11400 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11430 |
4EF..EP8# NO.1 |
1 | ||
| 17303-11401 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11620 |
4EF..EP8# NO.3 |
1 | ||
| 17303-11810 |
4EF#..EP8# NO.1 |
1 | ||
| 17303-11460 |
4EF..EP8# NO.2 |
1 | ||
| 17303-11401 |
4EF#..EP8# NO.1 |
1 | ||
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-11400 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11430 |
4EF..EP8# NO.1 |
1 | ||
| 17303-11401 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17303-11620 |
4EF..EP8# NO.3 |
1 | ||
| 17303-11810 |
4EF#..EP8# NO.1 |
1 | ||
| 17303-11460 |
4EF..EP8# NO.2 |
1 | ||
| 17303-11401 |
4EF#..EP8# NO.1 |
1 | ||
| 17343B - HOSE, NO.3(FOR IDLE-UP) | ||||
| 17343-11030 |
4EFE,4EFTE..EP82 NO.2 |
1 | ||
| 17343-11080 |
4EF#..EP8# NO.2 |
1 | ||
| 17343-11080 |
4EFE,4EFTE..EP82 NO.2 |
1 | ||
| 17343-11080 |
4EFE..EP82 NO.2 |
1 | ||
| 17343B - HOSE, NO.3(FOR IDLE-UP) | ||||
| 17343-11080 |
4EFE,4EFTE..EP82 NO.2 |
1 | ||
| 17343-11030 |
4EFE,4EFTE..EP82 NO.2 |
1 | ||
| 17343-11080 |
4EF#..EP8# NO.2 |
1 | ||
| 17343-11080 |
4EFE..EP82 NO.2 |
1 | ||
| 17343C - CLIP, NO.3(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
4EFE,4EFTE..EP82 |
2 | ||
| 17343C - CLIP, NO.3(FOR IDLE-UP HOSE) | ||||
| 96132-30400 |
4EFE,4EFTE..EP82 |
2 | ||
| 17344C - HOSE, NO.4(FOR IDLE-UP) | ||||
| 17344-11030 |
4EFE,4EFTE..EP82 NO.2 |
1 | ||
| 17344-11030 |
4EF#..EP8# NO.2 |
1 | ||
| 17344C - HOSE, NO.4(FOR IDLE-UP) | ||||
| 17344-11030 |
4EFE,4EFTE..EP82 NO.2 |
1 | ||
| 17344-11030 |
4EF#..EP8# NO.2 |
1 | ||
| 17344D - CLIP, NO.4(FOR IDLE-UP HOSE) | ||||
| 90467-13036 |
4EFE,4EFTE..EP82 |
2 | ||
| 17344D - CLIP, NO.4(FOR IDLE-UP HOSE) | ||||
| 90467-13036 |
4EFE,4EFTE..EP82 |
2 | ||
| 17630 - VALVE ASSY, AIR CONTROL | ||||
| 17630-11050 |
4EF#..EP8# NO.1 |
1 | ||
| 17630-70020 |
4EFE,4EFTE..EP82 ｱﾘ(ﾊﾟﾜｰｽﾃｱﾘﾝｸﾞ),NO.2 |
1 | ||
| 17630-11050 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17630-11020 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17630-11060 |
4EF#..EP8#..CAN,GI,GT,S,SOLL,XLTD NO.2 |
1 | ||
| 17630 - VALVE ASSY, AIR CONTROL | ||||
| 17630-11050 |
4EF#..EP8# NO.1 |
1 | ||
| 17630-70020 |
4EFE,4EFTE..EP82 ｱﾘ(ﾊﾟﾜｰｽﾃｱﾘﾝｸﾞ),NO.2 |
1 | ||
| 17630-11050 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17630-11020 |
4EFE,4EFTE..EP82 NO.1 |
1 | ||
| 17630-11060 |
4EF#..EP8#..CAN,GI,GT,S,SOLL,XLTD NO.2 |
1 | ||
| 17650 - VALVE ASSY, VACUUM SWITCHING | ||||
| 25860-11160 |
4EF..EP8# NO.4 |
1 | ||
| 25860-11130 |
4EF..EP8# NO.1 |
1 | ||
| 90910-12009 |
4EF..EP8# NO.2 |
1 | ||
| 25860-11150 |
4EF..EP8# NO.3 |
1 | ||
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11027 |
4EF..EP8# |
1 | ||
| 90917-11030 |
4EFE,4EFTE..EP8# |
1 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10080 |
4EF#..EP8# |
1 | ||
| 90917-10049 |
4EF..EP8# NO.1 |
2 | ||
| 25760 - HOSE ASSY, VACUUM TRANSMITTING | ||||
| 25760-11070 |
4EFE,4EFTE..EP8#..CAN,CANSI,GI,GT,S,SI,SOLL,XLTD NO.1 |
1 | ||
| 25760-11071 |
4EFE..EP8#..CAN,GI,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11120 |
4EFE..EP8# NO.2 |
1 | ||
| 25760-11071 |
4EF#..EP8#..GI,GT,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11100 |
4EF..EP8# |
1 | ||
| 25760 - HOSE ASSY, VACUUM TRANSMITTING | ||||
| 25760-11070 |
4EFE,4EFTE..EP8#..CAN,CANSI,GI,GT,S,SI,SOLL,XLTD NO.1 |
1 | ||
| 25760-11071 |
4EFE..EP8#..CAN,GI,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11120 |
4EFE..EP8# NO.2 |
1 | ||
| 25760-11071 |
4EF#..EP8#..GI,GT,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11100 |
4EF..EP8# |
1 | ||
| 25760 - HOSE ASSY, VACUUM TRANSMITTING | ||||
| 25760-11070 |
4EFE,4EFTE..EP8#..CAN,CANSI,GI,GT,S,SI,SOLL,XLTD NO.1 |
1 | ||
| 25760-11071 |
4EFE..EP8#..CAN,GI,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11120 |
4EFE..EP8# NO.2 |
1 | ||
| 25760-11071 |
4EF#..EP8#..GI,GT,S,SOLL,XLTD NO.1 |
1 | ||
| 25760-11100 |
4EF..EP8# |
1 | ||
| 25861 - BRACKET, VACUUM SWITCHING VALVE | ||||
| 25862-11010 |
4EF#..EP8# NO.2 |
1 | ||
| 25861-11030 |
4EF#..EP8# NO.1 |
1 | ||
| 25861 - BRACKET, VACUUM SWITCHING VALVE | ||||
| 25862-11010 |
4EF#..EP8# NO.2 |
1 | ||
| 25861-11030 |
4EF#..EP8# NO.1 |
1 | ||
| Common parts | ||||
| 17341-11230 | ||||
| 90099-92002 | ||||
| 90119-08813 | ||||
| 90339-05012 | ||||
| 90413-04008 | ||||
| 90445-08243 | ||||
| 90445-08284 | ||||
| 90445-08286 | ||||
| 90445-08287 | ||||
| 90445-12158 | ||||
| 90464-00320 | ||||
| 90464-00514 | ||||
| 90467-07016 | ||||
| 90467-10099 | ||||
| 90910-05211 | ||||
| 90910-12121 | ||||
| 91512-60620 | ||||
| 91621-60612 | ||||
| 95411-19904 | ||||
| 95413-49945 | ||||
| 96132-30400 | ||||
| 96132-30600 | ||||
