EP82-AGKNU (1989)
Toyota Starlet
(8912- )EP82,NP80
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04474 - CYLINDER KIT, REAR WHEEL | ||||
| 04474-16020 |
EP8#,NP80..CBR,DSL,EFI |
2 | ||
| 04495 - SHOE KIT, REAR BRAKE | ||||
| 04495-10110 |
EP82,NP80..CBR,DSL,EFI ﾏｰｸ NBK LN511 |
1 | ||
| 04497-10090 |
EP82,NP80..CBR,DSL,EFI REBUILT |
1 | ||
| 04906 - CUP KIT, REAR WHEEL CYLINDER | ||||
| 04906-16020 |
EP8#,NP80..CBR,DSL,EFI |
1 | ||
| 47043 - PLATE SUB-ASSY, BRAKE BACKING, REAR RH | ||||
| 47043-10060 |
EP82..CANSI,GI,S,SI,X ｱﾘ(ABS) |
1 | ||
| 47043-10060 |
EP82..CBR,EFI ｱﾘ(ABS) |
1 | ||
| 47043-10050 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47043G - BOLT (FOR BACKING PLATE TO REAR AXLE BEAM SETTING) | ||||
| 90119-10365 |
EP82,NP80..CBR,DSL,EFI |
8 | ||
| 47044 - PLATE SUB-ASSY, BRAKE BACKING, REAR LH | ||||
| 47044-10060 |
EP82..CBR,EFI ｱﾘ(ABS) |
1 | ||
| 47044-10050 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47044-10060 |
EP82..CANSI,GI,S,SI,X ｱﾘ(ABS) |
1 | ||
| 47061 - STRUT SET, PARKING BRAKE SHOE, RH | ||||
| 47061-10020 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47062 - STRUT SET, PARKING BRAKE SHOE, LH | ||||
| 47062-10020 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47430E - SPRING, TENSION(FOR REAR BRAKE SHOE RETURN) | ||||
| 90506-18014 |
EP82,NP80..CBR,DSL,EFI |
2 | ||
| 47430G - SPRING, TENSION(FOR REAR BRAKE AUTOMATIC ADJUST LEVER) | ||||
| 90507-12020 |
EP82,NP80..CBR,DSL,EFI |
2 | ||
| 47447G - PIN, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47447-30020 |
EP82,NP80..CBR,DSL,EFI |
4 | ||
| 47449B - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30030 |
EP82,NP80..CBR,DSL,EFI |
8 | ||
| 47449B - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30030 |
EP82,NP80..CBR,DSL,EFI |
8 | ||
| 47457B - SPRING, COMPRESSION(FOR REAR SHOE HOLD DOWN SPRING PIN) | ||||
| 90501-14086 |
EP82,NP80..CBR,DSL,EFI |
4 | ||
| 47547-20010 |
EP82..CANSI,GI,S,SI,X ｱﾘ(ABS) |
4 | ||
| 47459C - CLIP(FOR SHOE RETURN SPRING) | ||||
| 90468-05063 |
EP82,NP80..CBR,DSL,EFI |
2 | ||
| 47459R - SPRING, SHOE RETURN(FOR REAR BRAKE) | ||||
| 47459-16020 |
EP82,NP80..CBR,DSL,EFI |
2 | ||
| 47492B - PLUG, SHOE INSPECTION(FOR REAR BRAKE) | ||||
| 47492-32010 |
EP8#,NP80..CBR,DSL,EFI |
2 | ||
| 47496 - PLUG, HOLE(FOR REAR BRAKE) | ||||
| 47491-20011 |
EP8#,NP80..CBR,DSL,EFI |
2 | ||
| 47547R - PLUG, BLEEDER(FOR DRUM BRAKE, REAR) | ||||
| 47547-20010 |
EP82,NP80..CBR,DSL,EFI |
2 | ||
| 47548R - CAP, BLEEDER PLUG(FOR DRUM BRAKE, REAR) | ||||
| 31478-30010 |
EP8#,NP80..CBR,DSL,EFI |
2 | ||
| 47550 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, FRONT OR UPPER) | ||||
| 47550-20120 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47550C - SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER) | ||||
| 90501-07006 |
EP82,NP80..CBR,DSL,EFI |
2 | ||
| 47570 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, FRONT OR UPPER) | ||||
| 47570-20030 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47601C - WASHER, C(FOR REAR BRAKE) | ||||
| 90213-06013 |
EP8#,NP80..CBR,DSL,EFI 厚さ=1.2 |
2 | ||
| 47601E - RING, E(FOR REAR BRAKE) | ||||
| 96160-00600 |
EP82,NP80..CBR,DSL,EFI |
2 | ||
| 47611C - LEVER, PARKING BRAKE SHOE, RH | ||||
| 47611-10030 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47612A - LEVER, PARKING BRAKE SHOE, LH | ||||
| 47612-10030 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47643A - LEVER, REAR BRAKE AUTOMATIC ADJUST, RH | ||||
| 47643-10020 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| 47644A - LEVER, REAR BRAKE AUTOMATIC ADJUST, LH | ||||
| 47644-10020 |
EP82,NP80..CBR,DSL,EFI |
1 | ||
| Common parts | ||||
| 90119-06084 | ||||
