EP71-PGKRS (1984)

Toyota Starlet

Production Oct 1984 - Dec 1989
Engine 2ELU
Transmission 4F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8410- )

Click highlighted areas on diagram

diagram 74529 74540 74541 74541B 74542 74544D 74559A 74562 74563 74571 74579
Part # Description Qty Price
74540 - PLATE, FUSE BLOCK CAUTION
82683-10050

EP7#,NP7#

 1
74541 - PLATE, TIRE PRESSURE CAUTION
42661-10061

EP7#,NP7#

 1
42661-10060

EP7#

 1
42661-10060

EP7#,NP7#

 1
74541B - PLATE, COMPACT SPARE TIRE CAUTION
42668-32010

EP71,NP70

 1
74542 - PLATE, REAR WINDOW MARK
74542-20020

EP7#,NP7#

COLD SPEC

 1
74544D - PLATE, TIRE CARRIER CAUTION
74544-10010

EP7#,NP7#

 1
74544-10011

EP7#,NP7#

 1
74559A - PLATE, FUEL CAUTION
74559-14010

EP7#

 1
74562 - PLATE, EMISSION CONTROL SYSTEM INFORMATION
74562-10070

EP71..CBR

 1
74562-11030

EP71..CBR

 1
74563 - PLATE, EMISSION CONTROL DEVICE IDENTIFICATION
74563-10030

EP71..CBR

 1
74571 - PLATE, BRAKE FLUID CAUTION
47288-32010

EP7#,NP7#

 1
74571-27022

EP7#

 1
74579 - PLATE, UNLEADED FUEL CAUTION
74579-30011

EP71

 1
