EE107V-BXKDS (1991)
Toyota Sprinter
(9109-9401)2E,3E
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11011 - WASHER SET, CRANKSHAFT THRUST | ||||
| 11012-11010 |
3E,5EFE..EE103,104,107,108 O/S 0.125 |
1 | ||
| 11011-11010 |
3E,5EFE..EE103,104,107,108 STD |
1 | ||
| 11702 - BEARING SET, CRANKSHAFT | ||||
| 11704-11011 |
3E..EE107,108 U/S 0.25 |
1 | ||
| 11704-11012 |
3E,5EFE..EE103,104,107,108 U/S 0.25 |
1 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-1101105 |
3E..EE107,108 MARK 5 |
5 | ||
| 11701-1101103 |
3E..EE107,108 MARK 3 |
5 | ||
| 11701-1101104 |
3E..EE107,108 MARK 4 |
5 | ||
| 11701-1101101 |
3E..EE107,108 MARK 1 |
5 | ||
| 11701-1101102 |
3E..EE107,108 MARK 2 |
5 | ||
| 11701-1101205 |
3E,5EFE..EE103,104,107,108 MARK 5 |
5 | ||
| 11701-1101202 |
3E,5EFE..EE103,104,107,108 MARK 2 |
5 | ||
| 11701-1101204 |
3E,5EFE..EE103,104,107,108 MARK 4 |
5 | ||
| 11701-1101203 |
3E,5EFE..EE103,104,107,108 MARK 3 |
5 | ||
| 11701-1101201 |
3E,5EFE..EE103,104,107,108 MARK 1 |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-1101105 |
3E..EE107,108 MARK 5 |
5 | ||
| 11701-1101103 |
3E..EE107,108 MARK 3 |
5 | ||
| 11701-1101104 |
3E..EE107,108 MARK 4 |
5 | ||
| 11701-1101101 |
3E..EE107,108 MARK 1 |
5 | ||
| 11701-1101102 |
3E..EE107,108 MARK 2 |
5 | ||
| 11701-1101205 |
3E,5EFE..EE103,104,107,108 MARK 5 |
5 | ||
| 11701-1101202 |
3E,5EFE..EE103,104,107,108 MARK 2 |
5 | ||
| 11701-1101204 |
3E,5EFE..EE103,104,107,108 MARK 4 |
5 | ||
| 11701-1101203 |
3E,5EFE..EE103,104,107,108 MARK 3 |
5 | ||
| 11701-1101201 |
3E,5EFE..EE103,104,107,108 MARK 1 |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-1101105 |
3E..EE107,108 MARK 5 |
5 | ||
| 11701-1101103 |
3E..EE107,108 MARK 3 |
5 | ||
| 11701-1101104 |
3E..EE107,108 MARK 4 |
5 | ||
| 11701-1101101 |
3E..EE107,108 MARK 1 |
5 | ||
| 11701-1101102 |
3E..EE107,108 MARK 2 |
5 | ||
| 11701-1101205 |
3E,5EFE..EE103,104,107,108 MARK 5 |
5 | ||
| 11701-1101202 |
3E,5EFE..EE103,104,107,108 MARK 2 |
5 | ||
| 11701-1101204 |
3E,5EFE..EE103,104,107,108 MARK 4 |
5 | ||
| 11701-1101203 |
3E,5EFE..EE103,104,107,108 MARK 3 |
5 | ||
| 11701-1101201 |
3E,5EFE..EE103,104,107,108 MARK 1 |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-1101105 |
3E..EE107,108 MARK 5 |
5 | ||
| 11701-1101103 |
3E..EE107,108 MARK 3 |
5 | ||
| 11701-1101104 |
3E..EE107,108 MARK 4 |
5 | ||
| 11701-1101101 |
3E..EE107,108 MARK 1 |
5 | ||
| 11701-1101102 |
3E..EE107,108 MARK 2 |
5 | ||
| 11701-1101205 |
3E,5EFE..EE103,104,107,108 MARK 5 |
5 | ||
| 11701-1101202 |
3E,5EFE..EE103,104,107,108 MARK 2 |
5 | ||
| 11701-1101204 |
3E,5EFE..EE103,104,107,108 MARK 4 |
5 | ||
| 11701-1101203 |
3E,5EFE..EE103,104,107,108 MARK 3 |
5 | ||
| 11701-1101201 |
3E,5EFE..EE103,104,107,108 MARK 1 |
5 | ||
| 11711 - BEARING, CRANKSHAFT | ||||
| 11701-1101105 |
3E..EE107,108 MARK 5 |
5 | ||
| 11701-1101103 |
3E..EE107,108 MARK 3 |
5 | ||
| 11701-1101104 |
3E..EE107,108 MARK 4 |
5 | ||
| 11701-1101101 |
3E..EE107,108 MARK 1 |
5 | ||
| 11701-1101102 |
3E..EE107,108 MARK 2 |
5 | ||
| 11701-1101205 |
3E,5EFE..EE103,104,107,108 MARK 5 |
5 | ||
| 11701-1101202 |
3E,5EFE..EE103,104,107,108 MARK 2 |
5 | ||
| 11701-1101204 |
3E,5EFE..EE103,104,107,108 MARK 4 |
5 | ||
| 11701-1101203 |
3E,5EFE..EE103,104,107,108 MARK 3 |
5 | ||
| 11701-1101201 |
3E,5EFE..EE103,104,107,108 MARK 1 |
5 | ||
| 13011 - RING SET, PISTON | ||||
| 13011-11090 |
3E..EE107,108 STD |
1 | ||
| 13013-11090 |
3E..EE107,108 O/S 0.50 |
1 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-1101001 |
3E,5EFE..EE103,104,107,108 MARK 1 |
4 | ||
| 13041-1101002 |
3E,5EFE..EE103,104,107,108 MARK 2 |
4 | ||
| 13041-1101003 |
3E,5EFE..EE103,104,107,108 MARK 3 |
4 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-1101001 |
3E,5EFE..EE103,104,107,108 MARK 1 |
4 | ||
| 13041-1101002 |
3E,5EFE..EE103,104,107,108 MARK 2 |
4 | ||
| 13041-1101003 |
3E,5EFE..EE103,104,107,108 MARK 3 |
4 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-1101001 |
3E,5EFE..EE103,104,107,108 MARK 1 |
4 | ||
| 13041-1101002 |
3E,5EFE..EE103,104,107,108 MARK 2 |
4 | ||
| 13041-1101003 |
3E,5EFE..EE103,104,107,108 MARK 3 |
4 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-1101001 |
3E,5EFE..EE103,104,107,108 MARK 1 |
4 | ||
| 13041-1101002 |
3E,5EFE..EE103,104,107,108 MARK 2 |
4 | ||
| 13041-1101003 |
3E,5EFE..EE103,104,107,108 MARK 3 |
4 | ||
| 13041 - BEARING, CONNECTING ROD | ||||
| 13041-1101001 |
3E,5EFE..EE103,104,107,108 MARK 1 |
4 | ||
| 13041-1101002 |
3E,5EFE..EE103,104,107,108 MARK 2 |
4 | ||
| 13041-1101003 |
3E,5EFE..EE103,104,107,108 MARK 3 |
4 | ||
| 13101 - PISTON SUB-ASSY, W/PIN | ||||
| 13101-1108101 |
3E..EE107,108 STD,MARK 1 |
4 | ||
| 13103-11081 |
3E..EE107,108 O/S 0.50 |
4 | ||
| 13101-1108103 |
3E..EE107,108 STD,MARK 3 |
4 | ||
| 13101-1108102 |
3E..EE107,108 STD,MARK 2 |
4 | ||
| 13202 - BEARING SET, CONNECTING ROD | ||||
| 13204-11010 |
3E,5EFE..EE103,104,107,108 U/S 0.25 |
1 | ||
| 13265A - NUT, HEXAGON(FOR CONNECTING ROD BOLT) | ||||
| 90179-08014 |
2E,3E,4EFE,5EFE..EE10# |
8 | ||
| 13405 - FLYWHEEL SUB-ASSY | ||||
| 13405-11041 |
3E,5EFE..EE103,104,107,108..MTM |
1 | ||
| 13405A - PIN, STRAIGHT(FOR FLYWHEEL) | ||||
| 90250-08120 |
2E,3E,4EFE,5EFE..EE10#..MTM 長さ=18,外径=8 |
3 | ||
| 13405B - BOLT, FLYWHEEL SETTING | ||||
| 90105-10138 |
2E,3E,4EFE,5EFE..EE10#..MTM |
6 | ||
| 13411 - CRANKSHAFT | ||||
| 13401-11040 |
3E,5EFE..EE103,104,107,108 |
1 | ||
| 13453 - GEAR, FLYWHEEL RING | ||||
| 13453-10030 |
2E,3E,4EFE,5EFE..EE10#..MTM |
1 | ||
| 13471 - PULLEY, CRANKSHAFT | ||||
| 13408-11012 |
2E,3E,4EFE,5EFE..EE10# |
1 | ||
| 13471C - BOLT(FOR CRANKSHAFT PULLEY SET) | ||||
| 90105-12051 |
2E,3E,4EFE,5EFE..EE10# |
1 | ||
| 13477 - PULLEY, CRANKSHAFT, NO.2 | ||||
| 88451-12050 |
2E..EE106..3FC;3E,4EFE,5EFE..EE101,102,103,104,107,108 |
1 | ||
| 13521A - KEY(FOR CRANKSHAFT TIMING GEAR) | ||||
| 90280-05005 |
2E,3E,4EFE,5EFE..EE10# |
1 | ||
| 95161-20519 |
2E,3E,4EFE..EE10# |
1 | ||
| 13521P - PULLEY, CRANKSHAFT TIMING | ||||
| 13521-11010 |
2E,3E..EE106,107,108 |
1 | ||
| 13566A - GUIDE, TIMING BELT | ||||
| 13566-10011 |
2E,3E..EE106,107,108 |
1 | ||
| Common parts | ||||
| 90119-08200 | ||||
