AE70-FCMXS (1979)
Toyota Sprinter
Production
Mar 1979
-
Apr 1983
Engine
3AU
Transmission
5F MTM
Displacement
2500cc
Power
168 HP (125 kW)
(7903-8108)
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55518 - PLATE, REMOTE CONTROL MIRROR NAME | ||||
| 55518-12010 |
AE70,TE7#..2D |
1 | ||
| 75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL) | ||||
| 75311-19835 |
AE70,TE70..SR SR |
1 | ||
| 75311-80014 |
AE70,KE70..2D SPRINTER |
1 | ||
| 75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL) | ||||
| 75311-19835 |
AE70,TE70..SR SR |
1 | ||
| 75311-80014 |
AE70,KE70..2D SPRINTER |
1 | ||
| 75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL) | ||||
| 75311-19835 |
AE70,TE70..SR SR |
1 | ||
| 75311-80014 |
AE70,KE70..2D SPRINTER |
1 | ||
| 75441 - PLATE, REAR NAME, NO.1 | ||||
| 75441-12240 |
AE70,KE70,TE7#..2D TOYOTA |
1 | ||
| 75461 - PLATE, REAR NAME, NO.2 (MODEL MARK) | ||||
| 75442-12740 |
AE70,KE70,TE7#..2D SPRINTER |
1 | ||
| 75462 - PLATE, REAR NAME, NO.3 (DISPLACEMENT) | ||||
| 75444-12040 |
AE70..2D 1.5 |
1 | ||
| 75463 - PLATE, REAR NAME, NO.4 (GRADE MARK) | ||||
| 75443-12240 |
AE70,KE70..SR SR |
1 | ||
| 75443-12240 |
AE70,TE70..SR SR |
1 | ||
| Common parts | ||||
| 90164-50051 | ||||
| 90202-05009 | ||||
| 90468-05015 | ||||
(8108- )
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL) | ||||
| 75311-19835 |
AE70,TE70..SR SR |
1 | ||
| 75311-80014 |
AE70,KE70..2D SPRINTER |
1 | ||
| 75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL) | ||||
| 75311-19835 |
AE70,TE70..SR SR |
1 | ||
| 75311-80014 |
AE70,KE70..2D SPRINTER |
1 | ||
| 75311 - EMBLEM, RADIATOR GRILLE (OR FRONT PANEL) | ||||
| 75311-19835 |
AE70,TE70..SR SR |
1 | ||
| 75311-80014 |
AE70,KE70..2D SPRINTER |
1 | ||
| 75441 - PLATE, REAR NAME, NO.1 | ||||
| 75441-12240 |
AE70,KE70,TE7#..2D TOYOTA |
1 | ||
| 75461 - PLATE, REAR NAME, NO.2 (MODEL MARK) | ||||
| 75442-12740 |
AE70,KE70,TE7#..2D SPRINTER |
1 | ||
| 75462 - PLATE, REAR NAME, NO.3 (DISPLACEMENT) | ||||
| 75444-12040 |
AE70..2D 1.5 |
1 | ||
| 75463 - PLATE, REAR NAME, NO.4 (GRADE MARK) | ||||
| 75443-12240 |
AE70,KE70..SR SR |
1 | ||
| 75443-12240 |
AE70,TE70..SR SR |
1 | ||
| 75485 - PLATE, BACK WINDOW NAME | ||||
| 75485-12030 |
AE70 POWER STEERING |
1 | ||
| Common parts | ||||
| 90164-50051 | ||||
| 90183-03033 | ||||
| 90202-05007 | ||||
| 90202-05009 | ||||
| 90430-03001 | ||||
| 90468-05015 | ||||
