S231E-ZMDF (2000)

Toyota Sparky

Production Sep 2000 - Jun 2002
Engine K3VE
Transmission 5MT MTM
Displacement 2500cc
Power 168 HP (125 kW)

(0009- )

Click highlighted areas on diagram

diagram 78120A 78120G 78123 78180P 78183B 78183C 78183D 78183E 9004386112 9004386112 9004468207 9004541007 9165160614 9165160614 9165160614 9165160614 9415080600
Part # Description Qty Price
78120A - SPRING, COMPRESSION (FOR ACCELERATOR LINK ROD)
78124-97502

S221,231

 1
78124-97504

S221,231

 1
78120G - ROD ASSY, ACCELERATOR PEDAL
78101-97504

S221,231

 1
78101-97506

S221,231

 1
78123 - BRACKET, ACCELERATOR PEDAL SUPPORT
78123-97504

S221,231

 1
78123-97503

S221,231

 1
78180P - CABLE ASSY, ACCELERATOR CONTROL
78180-97512

S221,231

 1
78183B - CLAMP, ACCELERATOR CONTROL CABLE
78183-97510

S221,231

 1
78183C - CLAMP, ACCELERATOR CONTROL CABLE
78183-97512

S221,231

 1
78183D - CLAMP, ACCELERATOR CONTROL CABLE
78183-97513

S221,231

 1
78183E - CLAMP, ACCELERATOR CONTROL CABLE
78183-97511

S221,231

 1
Common parts
90043-86112
90044-68207
90045-41007
91651-60614
94150-80600
