J210E-GMGF (2008)
Toyota Rush
Production
Nov 2008
-
Feb 2013
Engine
3SZVE
Transmission
5F MTM
Displacement
2500cc
Power
168 HP (125 kW)
(0601-1605)
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 51441D - COVER, ENGINE UNDER | ||||
| 51441-B4010 |
J200,210 |
1 | ||
| Common parts | ||||
| 90041-19260 | ||||
(0601-1605)
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 51022 - MEMBER SUB-ASSY, ENGINE REAR SUPPORT | ||||
| 51022-B4010 |
J200,210 |
1 | ||
| 51022-B4010 |
J200,210 |
1 | ||
| 51201 - CROSSMEMBER SUB-ASSY, FRONT SUSPENSION | ||||
| 51210-B4020 |
J200,210 |
1 | ||
| 51210-B4010 |
J200,210 |
1 | ||
| 51202D - CROSSMENBER SUB-ASSY, FRONT SUSPENSION, LOWER | ||||
| 51202-B4010 |
J200,210 |
1 | ||
| 51202-B4010 |
J200,210 |
1 | ||
| 51204C - DAMPER SUB-ASSY, ENGINE REAR SUPPORT MEMBER | ||||
| 51204-B4010 |
J200,210 |
1 | ||
| 51296 - BOLT, FRONT SUSPENSION MEMBER MOUNTING | ||||
| 51296-87402 |
J200,210 |
4 | ||
| Common parts | ||||
| 12341-87501 | ||||
| 57264-B4010 | ||||
| 57265-B4010 | ||||
| 90041-20207 | ||||
| 90041-79334 | ||||
| 91553-81070 | ||||
| Linked diagrams | ||||
| 1702 | ||||
