NCP125-CHXGK (2010)
Toyota Ractis
(1011-1405)NSP120 ; (1011- )NCP120,125
ｱﾘ(SRS ｶｰﾃﾝｼｰﾙﾄﾞ ｴｱﾊﾞｯｸﾞ)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 63310H - CLIP(FOR ROOF HEADLINING) | ||||
| 90467-05164B0 |
NCP125,NSP120..X LT.GRAY,TRIM2#,4#,8# |
2 | ||
| 90467-05164B0 |
NCP120,125,NSP12#..X LT.GRAY,TRIM2# |
2 | ||
| 90467-05164B0 |
NCP12#,NSP120..G LT.GRAY,TRIM2#,4# |
2 | ||
| 63311C - HEADLINING, ROOF | ||||
| 63311-52040B0 |
NCP120,125,NSP120..S,X LT.GRAY,TRIM2# |
1 | ||
| 63311-52050B0 |
NCP120,125,NSP120..S,X LT.GRAY,TRIM2# |
1 | ||
| 63311-52050B0 |
NCP120,125,NSP120..G LT.GRAY,TRIM2#,4# |
1 | ||
| 63311-52040B0 |
NCP120,125,NSP120..G LT.GRAY,TRIM2#,4# |
1 | ||
| 63341 - PAD, ROOF SILENCER, NO.1 | ||||
| 63341-52220 |
NCP120,125,NSP120 |
1 | ||
| 63341G - PAD, ROOF SILENCER | ||||
| 63341-52230 |
NCP120,125,NSP120 |
3 | ||
| 63341G - PAD, ROOF SILENCER | ||||
| 63341-52230 |
NCP120,125,NSP120 |
3 | ||
| 63341G - PAD, ROOF SILENCER | ||||
| 63341-52230 |
NCP120,125,NSP120 |
3 | ||
| 63351B - PAD, ROOF HEADLINING | ||||
| 63351-52110 |
NCP12#,NSP12# |
2 | ||
| 63351B - PAD, ROOF HEADLINING | ||||
| 63351-52110 |
NCP12#,NSP12# |
2 | ||
| 63351C - PAD, ROOF HEADLINING | ||||
| 63351-52120 |
NCP120,125,NSP120 |
2 | ||
| 63351C - PAD, ROOF HEADLINING | ||||
| 63351-52120 |
NCP120,125,NSP120 |
2 | ||
| 63352C - PAD, ROOF HEADLINING, END | ||||
| 63351-52060 |
NCP12#,NSP12# |
2 | ||
| 63352C - PAD, ROOF HEADLINING, END | ||||
| 63351-52060 |
NCP12#,NSP12# |
2 | ||
| 63371C - RETAINER, ROOF HEADLINING, NO.1 RH | ||||
| 63371-52010 |
NCP12#,NSP12# |
1 | ||
| 63377A - RETAINER, ROOF HEADLINING SUPPORT, NO.1 | ||||
| 63374-52010 |
NCP12#,NSP12# |
1 | ||
| 63388A - COVER, ROOF HEADLINING HOLDER | ||||
| 63388-60030B0 |
NCP125,NSP120..G ｳｪﾙｷｬﾌﾞ(ﾌﾚﾝﾄﾞﾏﾁｯｸ取付用専用車 ﾀｲﾌﾟT)&SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ),LT.GRAY,TRIM2#,4# |
2 | ||
| 63388-60030B0 |
NCP125,NSP120..G ｳｪﾙｷｬﾌﾞ(ﾌﾚﾝﾄﾞﾏﾁｯｸ取付用専用車 ﾀｲﾌﾟV)&SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ),LT.GRAY,TRIM2#,4# |
2 | ||
| 63388A - COVER, ROOF HEADLINING HOLDER | ||||
| 63388-60030B0 |
NCP125,NSP120..G ｳｪﾙｷｬﾌﾞ(ﾌﾚﾝﾄﾞﾏﾁｯｸ取付用専用車 ﾀｲﾌﾟT)&SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ),LT.GRAY,TRIM2#,4# |
2 | ||
| 63388-60030B0 |
NCP125,NSP120..G ｳｪﾙｷｬﾌﾞ(ﾌﾚﾝﾄﾞﾏﾁｯｸ取付用専用車 ﾀｲﾌﾟV)&SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ),LT.GRAY,TRIM2#,4# |
2 | ||
| 63399D - CLIP, ROOF HEADLINING | ||||
| 63399-52020 |
NCP120,125,NSP120..X SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 4ｽﾋﾟｰｶ |
2 | ||
| 63399-52020 |
NCP120,125,NSP120 SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ) |
2 | ||
| 63399-52020 |
NCP120,125..G SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 6ｽﾋﾟｰｶ |
2 | ||
| 63399-52020 |
NCP125,NSP120..X SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 4ｽﾋﾟｰｶ |
2 | ||
| 63399-52020 |
NCP120..G;NSP120..X;NCP125..G,X SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ) |
2 | ||
| 63399-52020 |
NCP120,125,NSP120..G,S SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 6ｽﾋﾟｰｶ |
2 | ||
| 63399D - CLIP, ROOF HEADLINING | ||||
| 63399-52020 |
NCP120,125,NSP120..X SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 4ｽﾋﾟｰｶ |
2 | ||
| 63399-52020 |
NCP120,125,NSP120 SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ) |
2 | ||
| 63399-52020 |
NCP120,125..G SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 6ｽﾋﾟｰｶ |
2 | ||
| 63399-52020 |
NCP125,NSP120..X SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 4ｽﾋﾟｰｶ |
2 | ||
| 63399-52020 |
NCP120..G;NSP120..X;NCP125..G,X SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ) |
2 | ||
| 63399-52020 |
NCP120,125,NSP120..G,S SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ)&ｵｰﾃﾞｨｵ(日本向け)−AVN 6ｽﾋﾟｰｶ |
2 | ||
| 66415B - SPACER, SIDE RAIL, REAR NO.2 RH | ||||
| 66415-52070 |
NCP12#,NSP12# SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ) |
1 | ||
| 66415-52070 |
NSP120..X;NCP125..G,X;NCP120,122..G SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ) |
1 | ||
| 66425B - SPACER, SIDE RAIL, REAR NO.2 LH | ||||
| 66425-52070 |
NCP12#,NSP12# SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ&ｶｰﾃﾝ) |
1 | ||
| 66425-52070 |
NSP120..X;NCP125..G,X;NCP120,122..G SRSｴｱﾊﾞｯｸﾞ−有り(運転席&助手席&ｻｲﾄﾞ=運転席のみ&ｶｰﾃﾝ) |
1 | ||
| Linked diagrams | ||||
| 8121 | ||||
| 8202 | ||||
| 8604 | ||||
(1011-1405)NSP120 ; (1011- )NCP120,125
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 63310H - CLIP(FOR ROOF HEADLINING) | ||||
| 90467-05164B0 |
NCP125,NSP120..X LT.GRAY,TRIM2#,4#,8# |
2 | ||
| 90467-05164B0 |
NCP120,125,NSP12#..X LT.GRAY,TRIM2# |
2 | ||
| 90467-05164B0 |
NCP12#,NSP120..G LT.GRAY,TRIM2#,4# |
2 | ||
| 63311C - HEADLINING, ROOF | ||||
| 63311-52040B0 |
NCP120,125,NSP120..S,X LT.GRAY,TRIM2# |
1 | ||
| 63311-52050B0 |
NCP120,125,NSP120..S,X LT.GRAY,TRIM2# |
1 | ||
| 63311-52050B0 |
NCP120,125,NSP120..G LT.GRAY,TRIM2#,4# |
1 | ||
| 63311-52040B0 |
NCP120,125,NSP120..G LT.GRAY,TRIM2#,4# |
1 | ||
| 63339A - COVER, ROOF HEADLINING SERVICE HOLE | ||||
| 63339-52030B0 |
NCP125,NSP120..G ｳｪﾙｷｬﾌﾞ(ﾌﾚﾝﾄﾞﾏﾁｯｸ取付用専用車 ﾀｲﾌﾟV),LT.GRAY,TRIM2#,4# |
2 | ||
| 63339-52030B0 |
NCP125,NSP120..G ｳｪﾙｷｬﾌﾞ(ﾌﾚﾝﾄﾞﾏﾁｯｸ取付用専用車 ﾀｲﾌﾟT),LT.GRAY,TRIM2#,4# |
2 | ||
| 63341 - PAD, ROOF SILENCER, NO.1 | ||||
| 63341-52220 |
NCP120,125,NSP120 |
1 | ||
| 63341G - PAD, ROOF SILENCER | ||||
| 63341-52230 |
NCP120,125,NSP120 |
3 | ||
| 63341G - PAD, ROOF SILENCER | ||||
| 63341-52230 |
NCP120,125,NSP120 |
3 | ||
| 63341G - PAD, ROOF SILENCER | ||||
| 63341-52230 |
NCP120,125,NSP120 |
3 | ||
| 63351B - PAD, ROOF HEADLINING | ||||
| 63351-52110 |
NCP12#,NSP12# |
2 | ||
| 63351B - PAD, ROOF HEADLINING | ||||
| 63351-52110 |
NCP12#,NSP12# |
2 | ||
| 63351C - PAD, ROOF HEADLINING | ||||
| 63351-52120 |
NCP120,125,NSP120 |
2 | ||
| 63351C - PAD, ROOF HEADLINING | ||||
| 63351-52120 |
NCP120,125,NSP120 |
2 | ||
| 63352C - PAD, ROOF HEADLINING, END | ||||
| 63351-52060 |
NCP12#,NSP12# |
2 | ||
| 63352C - PAD, ROOF HEADLINING, END | ||||
| 63351-52060 |
NCP12#,NSP12# |
2 | ||
| 63371C - RETAINER, ROOF HEADLINING, NO.1 RH | ||||
| 63371-52010 |
NCP12#,NSP12# |
1 | ||
| 63377A - RETAINER, ROOF HEADLINING SUPPORT, NO.1 | ||||
| 63374-52010 |
NCP12#,NSP12# |
1 | ||
| 66413B - SPACER, SIDE RAIL, FRONT RH | ||||
| 66413-52280 |
NCP12#,NSP12# |
1 | ||
| 66414A - SPACER, SIDE RAIL, REAR RH | ||||
| 66414-52290 |
NCP12#,NSP12# |
1 | ||
| 66423 - SPACER, SIDE RAIL, FRONT LH | ||||
| 66423-52280 |
NCP12#,NSP12# |
1 | ||
| 66424 - SPACER, SIDE RAIL, REAR LH | ||||
| 66424-52280 |
NCP12#,NSP12# |
1 | ||
| Linked diagrams | ||||
| 8121 | ||||
| 8202 | ||||
| 8604 | ||||
